Page 1 ® xSeries 232 User’s Reference...
Page 3 IBM xSeries 232 User’s Reference IBM Confidential...
Page 4 Before using this information and the product it supports, be sure to read the general information in Appendix A, “Product warranties and notices,” on page 139. Second Edition (July 2001) © Copyright International Business Machines Corporation 2001. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
Page 5: Table Of Contents
What your IBM xSeries 232 offers ........
Page 6 Handling static-sensitive devices ........39 Safety information .
Page 7 IBM Statement of Limited Warranty ........139...
Page 8 Book Title...
Page 9: Safety
Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. © Copyright IBM Corp. 2001...
Page 10 Antes de instalar este producto lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. viii IBM xSeries 232: User’s Reference...
Page 11 Statement 1 Danger Electrical current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: • Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. • Connect all power cords to a properly wired and grounded electrical outlet.
Page 12 Statement 2 CAUTION: When replacing the lithium battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.
Page 13 Statement 4 ≥18 kg (39.7 lbs) ≥32 kg (70.5 lbs) ≥55 kg (121.2 lbs) CAUTION: Use safe practices when lifting. Statement 5 CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord.
Page 14 Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components. If you suspect a problem with one of these parts, contact a service technician. IBM xSeries 232: User’s Reference...
Page 15: Chapter 1. Introduction
Your IBM xSeries 232 server comes with a three-year limited warranty and 90-Day IBM Start Up Support. If you have access to the World Wide Web, you can obtain up- to-date information about your server and other IBM server products at the following World Wide Web address: http://www.ibm.com/eserver/xseries/...
Page 16: Features And Specifications
— Two ISM RJ-45 connectors mode — One System management Serial C port Table 1. Features and Specifications. *KB equals approximately 1000 bytes. MB equals approximately 1000000 bytes. GB equals approximately 1000000000 bytes. IBM xSeries 232: User’s Reference...
Page 17: Notices And Statements Used In This Book
Notices and statements used in this book The caution and danger statements also appear in the multilingual Safety Information book provided on the IBM xSeries Documentation CD that comes with your xSeries product. Each statement is numbered for easy reference to the corresponding statements in the safety book.
Page 18: What Your Ibm Xseries 232 Offers
• IBM Intergrated System Management (ISM) Processor The IBM Integrated System Management Processor provides environmental monitoring for your server. This system environmental monitor supports the Automatic Server Restart (ASR) feature, and it can issue system alerts using the Alert on LAN features of the integrated Ethernet controller.
Page 19: Reliability, Availability, And Serviceability Features
The addition of an optional digital linear tape drive (DLT) allows quick backup of large amounts of data. • IBM ServerGuide™ CDs The ServerGuide CDs that are included with your server provide programs to help you set up your server and install the network operating system (NOS). The ServerGuide program detects the hardware options that are installed, and provides the correct configuration programs and device drivers.
Page 20: Server Controls And Indicators
Serial number Rack model Operator Cover information release panel latch Power control button shield (if installed) Power control button Reset button Hard disk Hard disk Serial drive status drive activity number light (amber) light (green) IBM xSeries 232: User’s Reference...
Page 21 Power-control button shield: You can install this circular disk over the power-control button to prevent accidental manual power-off. This disk is provided with your server. Power-control button: Press this button to manually shutdown the server. Reset button: Press this button to reset the server and run the power-on self-test (POST).
Page 22: Operator Information Panel
Ethernet port during typical operation. When the system is powered off, the LED might remain green. Ethernet transmit/receive activity light: This green LED lights when there is transmit or receive activity to or from the server. IBM xSeries 232: User’s Reference...
Page 23: Turning On The Server
Turning on the server After you plug the power cord of your server into the power supply and an electrical outlet you can start, the server in several ways: • You can press the power-control button on the front of the server to start the server.
Page 24: Turning Off The Server
You can disconnect the server power cords from the electrical outlets to shut off all power to the server. Note: After disconnecting the power cords, wait approximately 15 seconds for your system to stop running. Watch for the power-on light to stop blinking. IBM xSeries 232: User’s Reference...
Page 25: Chapter 2. Arranging Your Workspace
The monitor lets hot air escape through vents. Blocking the air vents can cause overheating, which might result in a malfunction or damage. Place the server and monitor so that nothing blocks the air vents; usually, 15 cm (6 © Copyright IBM Corp. 2001...
Page 26: Electrical Outlets And Cable Lengths
Keep power cords and cables neatly routed away from walkways and other areas where they might get kicked accidentally. For more information about power cords, refer to the power cord information in this on- line publication. IBM xSeries 232: User’s Reference...
Page 27: Chapter 3. Configuring Your Server
ServerGuide CDs The ServerGuide CDs include software setup and installation tools specifically designed for IBM xSeries servers. You can use these CDs during the initial installation of your server to configure the server hardware and simplify your network operating system installation. The ServerGuide CDs also contain a collection of application programs, which you can install after your server is up and running.
Page 28: Choices Available From The Configuration/Setup Main Menu
1. You can press F1 to display Help information for a selected menu item. 2. The menu choices might differ depending on the types of passwords set for your system and IBM system management adapters, or in the version of BIOS code installed on your server.
Page 29 — System Card Data Select this choice to view vital product data (VPD) for some server components. • Product Data Select this choice to view system information, such as the machine type and model, the server serial number, and the revision level or issue date of the BIOS code stored in the flash electrically erasable programmable ROM (EEPROM).
Page 30 — Core Chipset Control Select this choice to modify settings that control features of the core chip set on the system board. Attention: Do not make changes here unless directed to do so by an IBM authorized service representative. — System Partition Visibility Select this choice to choose whether the System Partition is visible or hidden.
Page 31: Using Passwords
Select this choice to set the system cache type for all microprocessors. — PCI BUS Control Select this choice to view and identify system resources used by PCI devices. PCI devices automatically communicate with the server configuration information. This usually results in automatic configuration of a PCI device. Attention: You must use the menu selections to save custom settings for the PCI Slot/Device Information choice.
Page 32: Remote-Control Security Settings
Enter a number of failed login attempts. Once this number is reached, the server locks up. You can also set the server to lock up if no password is entered for a set number of minutes. IBM xSeries 232: User’s Reference...
Page 33: Using The Scsiselect Utility Program
Using the SCSISelect utility program o g r a m e c t u t i l i t y p r U s i n g t h e S C S I S e l SCSISelect is a built-in, menu-driven configuration utility program that you can use to: •...
Page 34: Using The Pxe Boot Agent Utility Program
3. Use the arrow keys or press Enter to select a choice from the menu. • Press Esc to return to the previous menu. • Press the F4 key to exit. 4. Follow the instructions on the screen to change the settings of the selected items; then, press Enter. IBM xSeries 232: User’s Reference...
Page 35: Choices Available From The Pxe Boot Agent Utility Menu
Choices available from the PXE Boot Agent Utility menu The following choices appear on the PXE Boot Agent Utility menu: • Network Boot Protocol PXE is the default value for this menu item. Note: Do not change this value. There are no other network boot protocols supported.
Page 36 IBM xSeries 232: User’s Reference...
Page 37: Chapter 4. Using The Serverguide Cds
Chapter 4. Using the ServerGuide CDs The ServerGuide CDs include easy-to-use software setup and installation tools that are specifically designed for your IBM server. The ServerGuide Setup and Installation program detects the server model and hardware options that are installed and uses that information during setup to configure the hardware.
Page 38: Features At A Glance
Where device drivers for most adapters applicable, you can run and devices. executable files directly from the CD or unzip files to any drive on your server or another server on your network. IBM xSeries 232: User’s Reference...
Page 39: Setup And Configuration Overview
When you use the Setup and Installation CD, you do not need setup diskettes. You can use the CD to configure any supported IBM server model. The setup program checks your system BIOS, service processors, and other system hardware to determine if system updates are available.
Page 40: System Partition
You can modify information on the diskettes as you use them to set up or update other servers. Note: Availability and function can vary by server model and by the hardware that is installed. IBM xSeries 232: User’s Reference...
Page 41: Installing Your Nos Without Serverguide
If you have already configured the server hardware and you decide not to use ServerGuide to install your NOS, download the latest NOS installation instructions: 1. Go to http://www.ibm.com/pc/support 2. Click Servers. 3. From the Family field, select your server model.
Page 42 ServerGuide setup and configuration program and ensure that the setup is complete. System Updates Action and Applications Get "time out" or Ensure that you have access to the Internet through FTP directly. "Unknown host" errors. IBM xSeries 232: User’s Reference...
Page 43: Chapter 5. Installing Options
The following illustration shows the locations of major components in your server. Note: The illustrations in this document might differ slightly from your hardware. Microprocessor Terminator card Memory module Power supply Adapter retention bracket Adapter support bracket Fan (blower) © Copyright IBM Corp. 2001...
Page 44: System Board
DIMM 1 (J1) Microprocessor 2 (U69) PCI Slot 1 32-bit (J44) PCI Slot 2 64-bit (J41) PCI Slot 3 64-bit (J42) Battery (BH1) PCI Slot 4 64-bit (J29) PCI Slot 5 64-bit (J30) VRM 2 connector (J38) IBM xSeries 232: User’s Reference...
Page 45: System Board Internal Cable Connectors
System board internal cable connectors The following illustration identifies system-board connectors for internal cables. Note: The illustrations in this document might differ slightly from your hardware. Fan 3 Main power Power backplane (J55) signal connector (J43) connector (J19) Fan 1 (Unused) (J28) Operator information...
Page 46: System Board External Port Connectors
(J52) Video port (J36) Future releases of the Integrated System Management (ISM) firmware code will enable the Integrated System Management processor to send or forward alerts to IBM system management adapters using the ISM ports. IBM xSeries 232: User’s Reference...
Page 47: System Board Switches And Jumpers
System board switches and jumpers The following illustration identifies the switches and jumpers on the system board. Note: The illustrations in this document might differ slightly from your hardware. System board Switch block (SW1) Flash boot block recovery jumper (J16) Note: Any jumper blocks on the system board that are not shown in the illustration are reserved.
Page 48 When On, overrides the power-on switch and forces power-on mode. The system will always start without the use of the power-on switch. Note: When power-on switch is set to the On position you can not power down from the front panel. Table 2. Switches 1-8. IBM xSeries 232: User’s Reference...
Page 49: System Board Led Locations
System board LED locations The following illustration identifies LEDs on the system board. You might need to refer to this figure when solving problems with the server. Note: The illustrations in this document might differ slightly from your hardware. DIMM 4 error LED (CR15) DIMM 2 error LED (CR17)
Page 50: Light Path Diagnostic Panel
A VRM failure occured. This LED is turned on by the hardware when either of the two LightPath LED’s located near the appropriate VRM is turned on by the Integrated System Management Processor. Table 3. Diagnostics panel LEDs. IBM xSeries 232: User’s Reference...
Page 51 Diagnostic Description panel LED DASD Hot-swap SCSI system board or HD failure, or removed on either standard or optional expansion hot-swap bay DASD backplane over temperature (in this case TEMP/System error LEDs will be on also). Table 3. Diagnostics panel LEDs. Chapter 5.
Page 52: Remind Button
• Have a small, flat-blade screwdriver available. • For a list of supported options for your server, refer to http://www.ibm.com/pc/us/compat on the World Wide Web. System reliability considerations To help ensure proper cooling and system reliability, make sure: • Each of the drive bays has either a drive or a filler panel installed.
Page 53: Handling Static-Sensitive Devices
— On a tower model, leave approximately 127 mm (5 inches) of space around the front and rear of the server. — On a rack model, refer to the documentation that comes with the rack. • A removed hot-swap drive is replaced within two minutes of removal. •...
Page 54: Safety Information
Vor der Installation dieses Produkts die Sicherheitshinweise lesen. Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet. Antes de instalar este produto, leia as Informações sobre Segurança. IBM xSeries 232: User’s Reference...
Page 55 Antes de instalar este producto lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. Chapter 5. Installing Options...
Page 56 First, attach all cables to devices. First, remove power cords from outlet. Attach signal cables to connectors. Remove signal cables from connectors. Attach power cords to outlet. Remove all cables from devices. Turn device ON. IBM xSeries 232: User’s Reference...
Page 57 Statement 2 CAUTION: When replacing the lithium battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer.
Page 58 The device also might have more than one power cord. To remove all electrical current from the device, ensure that all power cords are disconnected from the power source. IBM xSeries 232: User’s Reference...
Page 59 Statement 8 CAUTION: Never remove the cover on a power supply or any part that has the following label attached. Hazardous voltage, current, and energy levels are present inside any component that has this label attached. There are no serviceable parts inside these components.
Page 60: Removing The Cover, Door, And Bezel
Attention: For proper cooling and airflow, replace the cover before turning on the server. Operating the server for extended periods of time (over 30 minutes) with the cover removed might damage server components. IBM xSeries 232: User’s Reference...
Page 61: Removing The Cover (Rack Model)
Removing the cover (rack model) r ( r a c k m o d e l ) R e m o v i n g t h e c o v e Notes: 1. To remove or install a hot-swap hard disk drive or hot-swap power supply, it is not necessary to remove the cover.
Page 62: Removing The Server Door And Bezel (Tower Model)
1. Push blue bezel-release lever in the direction shown in the illustration. 2. Lift the bezel tabs out of the slots, and pull the bezel away from the server front. Store the bezel in a safe place. IBM xSeries 232: User’s Reference...
Page 63: Removing The Bezel (Rack Model)
Removing the bezel (rack model) R e m o v i n g t h e b e z e Note: The illustrations in this document might differ slightly from your hardware. Bezel-release lever Bezel To remove the bezel: 1. Move the blue bezel-release lever, in the direction shown in the illustration. 2.
Page 64: Adapter Considerations
PCI interrupts. • The optional IBM Remote Supervisor Adapter must be installed in PCI slot 1 only. The ribbon cable that ships with the adapter is required to connect the adapter to the system board. The external power adapter that ships with the adapter is not required with this server.
Page 65: Installing An Adapter
• The system scans PCI slot 1, the system board Ethernet, PCI slots 2-5, and then the system board SCSI channels A and B, if you have not changed the boot precedence from the default. You can use the Configuration/Setup Utility program to change the boot precedence for your server.
Page 66 Note: The illustrations in this document might differ slightly from your hardware. SCSI connector A SCSI adapter New connector location SCSI cable 11. If you have other options to install or remove, do so now; otherwise, go to “Installing the cover” on page 73. IBM xSeries 232: User’s Reference...
Page 67: Installing Internal Drives
Installing internal drives n a l d r i v e s I n s t a l l i n g i n t e r Different types of drives enable your system to read multiple types of media and store more data.
Page 68: Hot-Swap Drives
If you are installing a SCSI device with a 50-pin connector in one of the empty non-hot-swap bays (bays A–B), you need a 68-pin to 50-pin converter. To order the converter, contact your IBM reseller or IBM marketing representative. Note: The server electromagnetic interference (EMI) integrity and cooling are both protected by having bays A and B covered or occupied.
Page 69: Preinstallation Steps (All Bays)
drive, save the filler panel from the bay, in case you later remove the drive and do not replace it with another. Preinstallation steps (all bays) Before you install drives in your server, verify that you have all the cables and any other equipment specified in the documentation that comes with the internal drive.
Page 70: Installing A Hot-Swap Drive
— When the amber light flashes rapidly (three flashes per second), the controller is identifying the drive. Note: If your server has a RAID adapter installed, refer to the information provided with the RAID adapter for information about adding a drive. IBM xSeries 232: User’s Reference...
Page 71: Replacing A Drive In A Hot-Swap Bay
Replacing a drive in a hot-swap bay You do not have to turn off the server to remove or install the hot-swap drives. Attention: 1. Before you remove a hot-swap hard disk drive that is not defective, back up all important data.
Page 72: Installing A Non-Hot-Swap Drive
(see “Removing the cover, door, and bezel” on page 46 for details). 3. Remove the filler panel from the bay opening by pulling the filler panel away from the server. You do not need the filler panel when you have a drive installed in the bay. IBM xSeries 232: User’s Reference...
Page 73 4. If the drive that you are installing is a laser product, observe the following safety precaution: Statement 3 CAUTION: When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are installed, note the following: • Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation.
Page 74: Installing An Xseries 3-Pack Ultra160 Hot-Swap Expansion Kit
46.) 3. Release the sidelights to remove the filler panels from the bays below the CD- ROM drive. 4. Refer to the documentation provided with the option to assemble the hot-swap expansion option. IBM xSeries 232: User’s Reference...
Page 75: Installing Memory Modules
You must install the DIMMs in pairs of the same size. Place pair 1 in slots 1 and 4 and pair 2 in slots 2 and 3. Refer to the ServerProven® list on the World Wide Web at http://www.ibm.com/pc/compat for information about memory modules for use with your server.
Page 76 Attention: To avoid breaking the retaining clips or damaging the DIMM connectors, handle the clips gently. 4. Install the DIMM: a. Turn the DIMM so that the pins and keys align correctly with the connector. IBM xSeries 232: User’s Reference...
Page 77: Installing A Microprocessor
DIMM 3 DIMM 2 DIMM 4 DIMM 1 b. Insert the DIMM into the connector by pressing on one edge of the DIMM and then on the other edge of the DIMM. Be sure to press straight into the connector. Be sure that the retaining clips snap into the closed position. c.
Page 78 See the ServerProven list at http://www.ibm.com/pc/compat for a list of microprocessors for use with your server. IBM xSeries 232: User’s Reference...
Page 79 Note: The illustrations in this document might differ slightly from your hardware. Fan sink (Remove themal tape Terminator liner on installation) card Microprocessor 2 VRM 2 Microprocessor 1 location VRM 1 Microprocessor release lever To install an additional microprocessor: 1. Review the safety precautions in Statement 1 and Statement 5 in “Safety information”...
Page 80: Installing Or Removing A Power Supply
The 385-watt power-supply configuration can be upgraded with an optional backplane that will enable you to install up to three power supplies, which enables redundancy and will make the power supplies hot-swappable. Each power supply has two status IBM xSeries 232: User’s Reference...
Page 81 indicators; see the following illustration for information about the status indicators and power-supply bay locations. Note: The illustrations in this document might differ slightly from your hardware. Power supply bay 3 Power supply bay 2 Power supply Filler panel Power supply bay 1 DC power DC power...
Page 82: Adding A Hot-Swap Power Supply
Notes: 1. You do not need to turn off the power to the server to install hot-swap power supplies. 2. The illustrations in this document might differ slightly from your hardware. IBM xSeries 232: User’s Reference...
Page 83: Removing A Hot-Swap Power Supply
Filler panel Power supply Power supply backplane option Power supply handle (in open position) Cable-restraint bracket To install a hot-swap power supply: 1. Remove the filler panel from the empty power supply bay by inserting your finger into the depression on the filler panel and pulling it away from the server. Save the filler panel in case you remove the power supply at a later time.
Page 84 2. Unplug the power cord from the power outlet. 3. Unplug the power cord from the power supply. CAUTION: Be careful when you remove the power supply; the power supply might be too hot to handle comfortably. IBM xSeries 232: User’s Reference...
Page 85: Installing Redundant Power Supply
Statement 12 CAUTION: The following label indicates a hot surface nearby. 4. Remove the power supply. 5. Install a replacement power supply. 6. Plug the power cord for the power supply into the power cord connector. Then, plug other end of the cord into a properly grounded outlet. 7.
Page 86: Replacing A Fan Assembly
8. Verify that the FAN LED on the diagnostic panel is not lit. If the FAN LED is lit, reseat the fan. 9. If you have other options to install or remove, do so now; otherwise, go to “Installing the cover” on page 73. IBM xSeries 232: User’s Reference...
Page 87: Installing The Cover
Installing the cover o v e r I n s t a l l i n g t h e c If you have a tower model, continue with “Installing the cover (tower)”. If you have a rack model, go to “Installing the cover (rack)” on page 75. Installing the cover (tower) Note: The illustrations in this document might differ slightly from your hardware.
Page 88: Installing The Bezel And Front Door
Then, release the flange. 3. Close and lock the server door. Attention: Be sure to maintain a clearance of at least 127 mm (5 inches) on the front and rear of the server to allow for air circulation. IBM xSeries 232: User’s Reference...
Page 89: Installing The Cover (Rack)
Installing the cover (rack) Note: The illustrations in this document might differ slightly from your hardware. Flange Top cover Flange Side latches To install the server top cover: 1. Align the top cover with the top of the server, approximately 25mm (1inch) from the front of the server;...
Page 90: Installing The Bezel
1. Place the tabs on the left side of the bezel in the slots at the left front of the server. 2. Press the right end of the bezel toward the server until the bezel clicks into place. IBM xSeries 232: User’s Reference...
Page 91: Connecting External Options
Connecting external options a l o p t i o n s C o n n e c t i n g e x t e r n If you install a SCSI adapter, you can attach a SCSI storage expansion enclosure to your server.
Page 92: Input/Output Ports
D-shell serial-port connector, serial C. Future releases of the Integrated System Management (ISM) firmware code will enable the Integrated System Management processor to communicate using a modem and this dedicated serial port. IBM xSeries 232: User’s Reference...
Page 93: Universal Serial Bus Ports
Future releases of the Integrated System Management (ISM) firmware code will enable the Integrated System Management processor to send or forward alerts to IBM system management adapters using the ISM ports. Note: For this function to work properly, one of the servers must have the Remote Supervisor Adapter installed.
Page 94: Usb-Port Connectors
Ethernet controllers. However, you must install a device driver to enable your operating system to address the Ethernet controllers. The device drivers are provided on the ServerGuide CDs. IBM xSeries 232: User’s Reference...
Page 95: High Performance Ethernet Modes
Priority Packet information is available on the IBM Networking Web site at: http://www.ibm.com/networking/support. Priority Packet prioritizes traffic based on priority filters. These are parameters you assign to outgoing (transmit) packets.
Page 96 802.1p. • The adapters on these devices must support 802.1p. The Ethernet controller in your server, all IBM Netfinity 10/100 Ethernet Security Adapters, and IBM 10/100 Ethernet Server Adapters support 802.1p. • The adapter cannot be assigned to an adapter team.
Page 97: Ethernet Port Connector
Notes: 1. Windows NT versions prior to 4.0 do not support VLANs. 2. VLANs require NT 4.0 with Service Pack 3.0 and the NDIS driver from Microsoft. 3. In Windows NT, VLANs cannot be implemented on controllers that have been configured for teaming options.
Page 98: Auxiliary-Device (Pointing Device) Port
Serial port C, which is dedicated for use by the Integrated System Management Processor. (See “Integrated System management ports” on page 78.) The operating system can use both serial ports, Serial port A and Serial port B. IBM xSeries 232: User’s Reference...
Page 99: Viewing Or Changing The Serial-Port Assignments
Some application programs require specific ports, and some modems function properly only at certain communication port addresses. You might need to use the Configuration/Setup Utility program to change communication port address assignments to prevent or resolve address conflicts. Viewing or changing the serial-port assignments To view or change the serial-port assignments: 1.
Page 100: Scsi Cabling Requirements
SCSI cabling requirements If you plan to attach external SCSI devices, you must order additional SCSI cables. To select and order the correct cables for use with external devices, contact your IBM reseller or IBM marketing representative. For information about the maximum length of SCSI cable between the terminated ends of the cable, refer to the American National Standards Institute (ANSI) SCSI standards.
Page 101: Scsi Connector Pin-Number Assignments
SCSI connector pin-number assignments The following table shows the pin-number assignments for the 68-pin SCSI connectors. Signal Signal +Data 12 -Data 12 +Data 13 -Data 13 +Data 14 -Data 14 +Data 15 -Data 15 +Data P1 -Data P1 +Data 0 -Data 0 +Data1 -Data 1...
Page 102: Cabling The Server
Future releases of the Integrated System Management (ISM) firmware code will enable the Integrated System Management processor to send or forward alerts to IBM system management adapters using the ISM ports. Future releases of the Integrated System Management (ISM) firmware code will enable the Integrated System Management processor to send or communicate using a modem and this dedicated serial port.
Page 103 Routing cables through cable-management assembly Note: The illustrations in this document might differ slightly from your hardware. Cable straps Chapter 5. Installing Options...
Page 104 IBM xSeries 232: User’s Reference...
Page 105: Chapter 6. Solving Problems
After you register and profile your xSeries products, you can diagnose problems using the IBM Online Assistant and you can participate in the IBM discussion forum. For more detailed information about registering and creating a customized profile for your IBM products, visit the following addresses on the Web: —...
Page 106: Server Support
Register and profile your server properly? After you register and profile, you will be able to: • Diagnose problems using the IBM Online Assistant • Participate in the IBM discussion forum • Receive e-mail notifications of technical updates related to your profiled products...
Page 107: Post
POST P O S T W hen you turn on the server, it performs a series of tests to check the operation of server components and some of the options installed in the server. This series of tests is called the power-on self-test, or POST. If POST finishes without detecting any problems, a single beep sounds, the first screen of your operating system or application program appears, and the System POST Complete (OK) light is illuminated on the operator information panel.
Page 108 All other beep Verify that the system memory modules are installed correctly. codes Turn off the server; then, restart the server. If the problem remains, call for service. Table 11. POST beep code descriptions. IBM xSeries 232: User’s Reference...
Page 109: Post Beep Codes
Post beep codes In addition to the beep codes that are described on page 95, your computer might emit beep codes that are described in the following table. For example, a 1-2-3 beep code is one beep, a pause, two consecutive beeps, another pause, and three more consecutive beeps.
Page 110: Post Error Messages
Cache Control selection in the Advanced Setup menu of the Configuration/Setup Utility program to enable the caches. If the problem persists, call for service. When the problem is corrected, be sure to enable the caches. Table 13. POST error messages. IBM xSeries 232: User’s Reference...
Page 111 POST message Description 101 102 106 An error occurred during the system board and microprocessor test. Action: Call for service. An adapter read-only memory (ROM) error occurred. Action: Remove the options. If you can start the server without the options installed, reinstall each option one at a time and retest after each is reinstalled.
Page 112 Note: If you just connected a new mouse or other pointing device, turn off the server and disconnect that device. Wait at least 5 seconds; then, turn on the server. If the error message goes away, replace the device. Table 13. POST error messages. IBM xSeries 232: User’s Reference...
Page 113 POST message Description Invalid diskette boot record. Action: 1. Replace the diskette. If the problem persists, make sure that the diskette drive cables are correctly and securely connected. If the problem remains, replace the diskette drive. If the problem persists, call for service. An error occurred during a diskette drive test.
Page 114 If the problem persists, call for service. 5962 An IDE CD-ROM configuration error occurred. Action: Check the signal and power cable connections to the CD-ROM drive. If the problem persists, call for service. Table 13. POST error messages. IBM xSeries 232: User’s Reference...
Page 115 POST message Description 8603 An error occurred during the mouse (pointing device) controller test. The addition or removal of a mouse, or a failing system board can cause this error. Note: This error also can occur if electrical power was lost for a very brief period and then restored.
Page 116 The ECC checking hardware test failed. Action: Call for service. 01298001 No update data is available for processor 1. Action: Update the system BIOS to a level that supports the microprocessors installed in the server. Table 13. POST error messages. IBM xSeries 232: User’s Reference...
Page 117: Error Logs
POST. The System Error Log contains all error mes- sages issued during POST and all system status messages from both the system environmental monitor subsystem and the optional IBM Remote Supervisor Adapter, if installed. To view the contents of the error logs, start the Configuration/Setup Utility program;...
Page 118: Diagnostic Programs And Error Messages
Hardware Maintenance Man- ual.) date is the date that the diagnostic test was run and the error recorded. is the check value that is used to verify the validity of the informa- tion. IBM xSeries 232: User’s Reference...
Page 119: Text Messages
text message is the diagnostic message that indicates the reason for the prob- lem. Text messages The diagnostic text message format is as follows: Function Name: Result (test specific string) where: Function Name is the name of the function being tested when the error occurred. This corresponds to the function code (fff) given in the previous list.
Page 120: Viewing The Test Log
Important: If diagnostic error messages appear that are not listed in the following tables, make sure that your server has the latest levels of BIOS, System Management processor, ServeRAID, and diagnostics microcode installed. IBM xSeries 232: User’s Reference...
Page 121 Code Function Result Text message Action Core system Failed Processor board, ECC Test Call for service. System board Video port Processor and system boards Serial port Integrated serial port USB interface Aborted Can NOT test USB interface while it is 1.
Page 122 (where n is the slot number of the service. adapter and m is the SCSI ID of the drive) Power supply Failed Voltage sensed by the system is out of Call for service. range Table 14. Diagnostic error messages. IBM xSeries 232: User’s Reference...
Page 123 Code Function Result Text message Action Microprocessor Failed Invalid microprocessor in slot xyz or 1. Check the system error log BIOS setup problem for the related error messages. (where xyz identifies the 2. If your server does not have microprocessor that is causing the the latest level BIOS error message) installed, update the BIOS.
Page 124 BIOS installed, update the BIOS to the latest Test setup error: Corrupt DMI BIOS, level. information in BIOS is not as expected If the problem persists, call for service. Table 14. Diagnostic error messages. IBM xSeries 232: User’s Reference...
Page 125 Code Function Result Text message Action System cache Aborted Test setup error: BIOS cannot access If your server does not have the VPD information latest level BIOS code installed, update the BIOS code to the Test setup error: Corrupt DMI BIOS. latest level and run the Information in BIOS is not as expected diagnostic program again.
Page 126 If the problem persists, (where n is the PCI slot number in call for service. which the failing Ethernet adapter is installed) On system board Call for service. Table 14. Diagnostic error messages. IBM xSeries 232: User’s Reference...
Page 127 Code Function Result Text message Action Analog/digital No modem was detected 1. Verify that the modem is modem applicable properly attached to the server. 2. If the problem remains, replace the modem. If the problem persists, call for service. PCI modem detected but not enabled 1. Change the configuration to enable the modem.
Page 128: Recovering Bios Code
Use the ServerGuide program to make a BIOS flash diskette. • Download a BIOS flash diskette from the World Wide Web. Go to http://www.ibm.com/pc/support, select IBM Server Support, and make the selections for your server. • Contact your IBM service representative.
Page 129: Identifying Problems Using Status Leds
The Recovery Boot screen will appear. A progress report, Loading data from diskette xx%, is displayed. When programming is underway, a further progress report, Programming block n of 7 yy%, is displayed. When the procedure com- plete, the message Recovery complete, remove the diskette and return boot block switch to the off position before rebooting is displayed.
Page 130: Diagnostics Panel
The following illustration shows the LEDs on the diagnostics panel on the system board. See “Light Path Diagnostics table” on page 117 for information on identifying problems using these LEDs. PCI A PCI B PCI C OVER DASD TEMP REMIND IBM xSeries 232: User’s Reference...
Page 131: Light Path Diagnostics Table
Light Path Diagnostics table The System Error LED on the operator information panel is lit when certain system errors occur. If the System Error LED on your server is lit, use the following table to help determine the cause of the error and the action you should take. Lit LED on diagnostics panel...
Page 132 PCI bus C (PCI slots 4 and 5) and restarting the server after each adapter is removed. If the problem persists, have the system serviced. Table 16. Light path diagnostics. IBM xSeries 232: User’s Reference...
Page 133: Troubleshooting Charts
Lit LED on diagnostics panel Cause Action One of the VRMs on the system Check the VRM failure LEDs on the board has failed. system board. • If the either VRM1 or VRM2 Failure LED is on: • If the VRM2 Failure LED is on: Turn off the server, reseat the respective VRM, and restart the server.
Page 134 Verify that the mouse or pointing-device cable is securely connected and the device device does not work. drivers are installed correctly. Try using another mouse or pointing device. If the problem remains, call for service. Table 17. Troubleshooting charts. IBM xSeries 232: User’s Reference...
Page 135 POST. Monitor Some IBM monitors have their own self-tests. If you suspect a problem with your monitor, refer to the information that comes with the monitor for adjusting and testing instructions. Testing the monitor. If you still cannot find the problem, call for service.
Page 136 Non-IBM monitor cables might cause unpredictable problems. An enhanced monitor cable with additional shielding is available for the 9521 and 9527 monitors. For information about the enhanced monitor cable, see your IBM reseller or IBM marketing representative. If the problem remains, call for service.
Page 137 The printer does not work. The printer signal cable is connected to the correct port on the server. Note: Non-IBM printer cables might cause unpredictable problems. You have assigned the printer port correctly in your operating system or application program.
Page 138: Troubleshooting The Ethernet Controller
Make sure that the device drivers on the client and system are using the same protocol. • Test the Ethernet controller. The way you test the Ethernet controller depends on which operating system you are using (see the Ethernet controller device driver README file). IBM xSeries 232: User’s Reference...
Page 139: Ethernet Controller Troubleshooting Chart
Ethernet controller troubleshooting chart You can use the following troubleshooting chart to find solutions to 10/100 Mbps Ethernet controller problems that have definable symptoms. Table 18. Ethernet troubleshooting chart. Ethernet controller Suggested action problem The server stops running The PCI BIOS interrupt settings are incorrect. when loading device drivers.
Page 140: Ethernet Controller Messages
Make sure that you have loaded LAN bind command can be issued. drivers after loading AFT.NLM. Action: Load the driver for the supported adapter and try loading the AFT module again. If the problem persists, contact your network supplier. IBM xSeries 232: User’s Reference...
Page 141 Table 19. NetWare driver messages for the Ethernet controller. Message Description Insufficient number of arguments Explanation: The appropriate or expected number of parameters was not specified. entered in a command. Action: Check the parameters required for the given command. If the problem persists, contact your network supplier.
Page 142 Please unload all LAN drivers before Explanation: An attempt was made to unload the AFT.NLM module before unloading AFT.NLM. unloading the adapter driver. Action: Unload the adapter driver before unloading the AFT module. IBM xSeries 232: User’s Reference...
Page 143: Ndis 4.0 (Windows Nt) Driver Messages
Explanation: Could not allocate enough memory for transmit queues. Action: From the Windows NT desktop, select Start → Control Panel → Networks → Adapters. Select your IBM Ethernet adapter from the list. Select Properties → Advanced. Lower the resource values that apply to the transmit queue.
Page 144 Explanation: Single adapter found, but multiple instances tried to load. Action: Using the Configuration/Setup Utility program, make sure that Ethernet is enabled, and that the slot containing the IBM xSeries 300 10/100 Ethernet Adapter or the IBM 10/100 EtherJet PCI adapter is enabled.
Page 145: Ethernet Teaming Messages
Ethernet teaming messages This section displays the messages associated with Ethernet teaming. Table 21. NDIS (Windows NT) driver teaming messages for the Ethernet controller. Event ID Type Description Error Explanation: Team name and physical adapter name are the same. This is an invalid configuration.
Page 146: Replacing The Battery
R e p l a c i n g t h e b a t IBM has designed this product with your safety in mind. The lithium battery must be handled correctly to avoid possible danger. If you replace the battery, you must adhere to the following instructions.
Page 147 Statement 2 CAUTION: When replacing the lithium battery, use only IBM Part Number 33F8354 or an equivalent type battery recommended by the manufacturer. If your system has a module containing a lithium battery, replace it only with the same module type made by the same manufacturer.
Page 148: Getting Information, Help, And Service
If you need help, service, or technical assistance or just want more information about IBM products, you will find a wide variety of sources available from IBM to assist you. This section contains information about where to go for additional information about IBM and IBM products, what to do if you experience a problem with your computer, and whom to call for service should it be necessary.
Page 149: Getting Information By Fax
(LANs). You can call the IBM Automated Fax System 24 hours a day, 7 days a week. Follow the recorded instructions, and the requested information will be sent to your fax machine.
Page 150 6:00 p.m. Note: Response time will vary depending on the number and complexity of incoming calls. In addition, you are eligible for IBM Start Up Support for 90 days after installation. This service provides assistance for: • Setting up your network operating system •...
Page 151: Purchasing Additional Services
U.S.A. and Puerto Rico U.S.A. and Puerto Rico 1-800-772-2227 In all other countries, contact your IBM reseller or IBM marketing representative. Purchasing additional services During and after the warranty period, you can purchase additional services, such as support for IBM and non-IBM hardware, operating systems, and application programs;...
Page 152 IBM xSeries 232: User’s Reference...
Page 153: Appendix A. Product Warranties And Notices
Country-unique Terms. The terms of Part 2 replace or modify those of Part 1. The warranties provided by IBM in this Statement of Limited Warranty apply only to Machines you purchase for your use, and not for resale, from IBM or your reseller. The term "Machine" means an IBM machine, its features, conversions, upgrades, elements, or accessories, or any combination of them.
Page 154 WITHOUT WARRANTIES OF ANY KIND. Warranty Service To obtain warranty service for a Machine, contact IBM or your reseller. If you do not register your Machine with IBM, you may be required to present proof of purchase.
Page 155 IBM or your reseller of changes in a Machine's location. IBM is responsible for loss of, or damage to, your Machine while it is 1) in IBM's possession or 2) in transit in those cases where IBM is responsible for the transportation charges.
Page 156: Part 2 - Country-Unique Terms
Limitation of Liability: The following is added to this Section: Where IBM is in breach of a condition or warranty implied by the Trade Practices Act 1974 or other similar legislation, IBM's liability is limited to the repair or replacement of the goods or the supply of equivalent goods.
Page 157 2. as to any other actual damage arising in any situation involving nonperformance by IBM pursuant to, or in any way related to the subject of this Statement of Limited Warranty, IBM's liability will be limited to the charge paid by you for the individual Machine that is the subject of the claim.
Page 158 PEOPLE'S REPUBLIC OF CHINA (PRC) Governing Law: The following replaces this Section: Both you and IBM consent to the application of the laws of the State of New York (except when local law requires otherwise) to govern, interpret, and enforce all your and IBM’s rights, duties, and obligations arising from, or relating in any manner to, the...
Page 159 The minimum warranty period for Machines is six months. In case IBM or your reseller is unable to repair an IBM Machine, you can alternatively ask for a partial refund as far as justified by the reduced value of the unrepaired Machine or ask for a cancellation of the respective agreement for such Machine and get your money refunded.
Page 160 Applicability of suppliers and resellers (unchanged). The following paragraph is added at the end of this Section: IBM's entire liability and your sole remedy, whether in contract or in tort, in respect of any default shall be limited to damages.
Page 161: Notices
The following item is added to this paragraph: 3. breach of IBM's obligations implied by Section 12 of the Sale of Goods Act 1979 or Section 2 of the Supply of Goods and Services Act 1982.
Page 162: Edition Notice
Contract with IBM Corp. Processing date data This IBM hardware product and IBM software products that might be packaged with it have been designed, when used in accordance with their associated documentation, to process date data correctly within and between the 20th and 21st centuries, provided all other products (for example, software, hardware, and firmware) used with these products properly exchange accurate date data with them.
Page 163: Important Notes
IBM. Unless otherwise stated, IBM makes no representations or warranties with respect to non-IBM products. Support (if any) for the non-IBM products is provided by the third party, not IBM. Some software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Page 164: Australia And New Zealand Class A Statement
This product is in conformity with the protection requirements of EU Council Directive 89/336/EEC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a nonrecommended modification of the product, including the fitting of non-IBM option cards.
Page 165: Power Cords
Power cords For your safety, IBM provides a power cord with a grounded attachment plug to use with this IBM product. To avoid electrical shock, always use the power cord and plug with a properly grounded outlet. IBM power cords used in the United States and Canada are listed by Underwriter's Laboratories (UL) and certified by the Canadian Standards Association (CSA).
Page 166 Islands, Colombia, Costa Rica, Dominican Republic, Ecuador, El Salvador, Guatemala, Guyana, Haiti, Honduras, Jamaica, Japan, Korea (South), Liberia, Mexico, Netherlands Antilles, Nicaragua, Panama, Peru, Philippines, Saudi Arabia, Suriname, Taiwan, Trinidad (West Indies), United States of America, Venezuela IBM xSeries 232: User’s Reference...
Page 167: Index
SCSISelect utility 13, 19 ServeRAID programs 13 ServerGuide CDs 13 with ServerGuide 25 Configuration/Setup Utility 13 configuring Ethernet 80 connectors, external 77 controls and indicators 6 cover installing 73, 75 cover, removing 46, 47 creating VLAN 83 © Copyright IBM Corp. 2001...
Page 168 81 troubleshooting information 124 VLAN 82 Windows NT error messages 129 Ethernet port 80 expansion bays 2 slots 2 fan, replacing 72 FCC Class A notice 149 features 2 ServerGuide 24 filters priority 81 IBM xSeries 232: User’s Reference...
Page 169 IBM Confidential glare and lighting 11 hard disk drive, See hot-swap drive heat output 2 high priority queue 81 hot-swap drive installing 56 specifications 54 I/O ports 78, 88 IEEE 802.1p tagging 81 important notes 149 information label 1 information panel, See operator information panel...
Page 170 68 installing or removing 66 removing 69 specifications 2 power supply backplane option 66 power, redundant 4 power-on password 17 priority filters 81 levels 81 packet mode 81 problem network connection 124 product IBM xSeries 232: User’s Reference...
Page 171 IBM Confidential notices 149 PXE Boot Agent Utility 13 rack installation 88 RAID See adapter safety information electrical ix hazardous voltage 68 laser x lifting xi SCSI cabling requirements 86 RAID 86 setting IDs 86 SCSISelect utility 13, 19 ServeRAID programs 13...
Page 172 United States FCC Class A notice 149 video controller disabling 49 specifications 2 virtual LAN (VLAN) 82 virtual LAN mode (VLAN) 82 VLAN creating 83 voltage regulator module, installing 65 VRM, installing 65 Web site ServerGuide 23 weight 2 IBM xSeries 232: User’s Reference...
Page 174 IBM@ 24P2874 File Number: Printed in the United States of America on recycled paper containing 10% recovered post-consumer fiber.
