INSTALLATION & OPERATING MANUAL
#942 DIRECT VENT
DESIGN-CERTIFIED TO:
DECORATIVE & WALL FURNACE ANSI PERFORMANCE & SAFETY STANDARDS
U.S. PATENTS:
#5.931.154,
#5,967,139
#6,004,493
IMPORTANT:
READ INSTRUCTIONS CAREFULLY BEFORE
INSTALLATION. FAILURE TO INSTALL THIS
FIREPLACE CORRECTLY CAN CAUSE SERIOUS
STRUCTURAL AND FIRE HAZARDS AND
MAY VOID YOUR WARRANTY.
www.kozyheat.com
June 2007
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for kozy heat 942
Summary of Contents for kozy heat 942
-
Page 1: Direct Vent
INSTALLATION & OPERATING MANUAL #942 DIRECT VENT DESIGN-CERTIFIED TO: DECORATIVE & WALL FURNACE ANSI PERFORMANCE & SAFETY STANDARDS U.S. PATENTS: #5.931.154, #5,967,139 #6,004,493 IMPORTANT: READ INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. FAILURE TO INSTALL THIS FIREPLACE CORRECTLY CAN CAUSE SERIOUS STRUCTURAL AND FIRE HAZARDS AND MAY VOID YOUR WARRANTY. -
