Direct vent see-thru / pier gas fireplace
Hide thumbs Also See for 944:
Table of Contents

Advertisement

Quick Links

See also: Instruction and Installation Manual
Quality Fireplaces for Life

DIRECT VENT

SEE-THRU / PIER GAS FIREPLACE
WARNING
: This product must be installed by
a licensed plumber or gas fitter when installed
in the Commonwealth of Massachusetts.
IMPORTANT: Installation of a CO detector is
required in the fireplace room when installed in
the Commonwealth of Massachusetts.
WARNING:
If the information in these instructions are not followed exactly, a fire or
explosion may result, causing property damage, personal injury or loss of life.
◙
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
IF YOU SMELL GAS:
◙ Do not light any appliance.
◙ Do not touch any electrical switch: do not use any phone in your building.
◙ Immediately call gas supplier from a neighbors phone. Follow the gas supplier instructions.
◙ If you cannot reach your gas supplier, call the fire department.
◙ Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type (s) of gas indicated on
the rating plate. A conversion kit is supplied with the appliance.
Report No. 216-F-17-4
OPERATION MANUAL
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
www.kozyheat.com
INSTALLATION
AND
PIER MODEL SHOWN
944 NOVEMBER2010-REV-08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 944 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for kozy heat 944

Summary of Contents for kozy heat 944

  • Page 1: Direct Vent

    This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes. This appliance is only for use with the type (s) of gas indicated on the rating plate. A conversion kit is supplied with the appliance. www.kozyheat.com Report No. 216-F-17-4 944 NOVEMBER2010-REV-08...

  • Page 2: Table Of Contents

    INDEX INTRODUCTION………………………………………………………………………………………….1 SAFETY REQUIREMENTS ..................... 3-4 SPECIFICATIONS ........................5 VENTING & CLEARANCE REQUIREMENTS ................6 PREPARE THE FIREPLACE ..................... 7 POSITION THE FIREPLACE ..................... 7 ROUGH-IN DIMENSIONS ....................... 8-9 VENTING REQUIREMENTS ....................10-14 Horizontal / Vertical Requirements ......10-11 Restrictor Installation Instructions ......12 Horizontal Venting Instructions ......

  • Page 3: Introduction

    Please retain this owner’s manual for future reference. CONGRATULATIONS! We welcome you as a new owner of a Kozy Heat gas fireplace. Kozy Heat products are designed with superior components and materials and assembled by trained craftsmen who take pride in their work. The burner and valve assembly are 100% test-fired and the complete fireplace is thoroughly inspected before packaging to ensure that you receive a quality product.

  • Page 4: Safety Requirements

    SAFETY INFORMATION This fireplace has been tested to and complies with ANSI Z21.88b-2008·CSA 2.33b-2008M02“VENTED GAS FIREPLACE HEATERS” by OMNI-Test Laboratories, Portland, OR. Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSAB149.1 Installation and repair should be done only by a qualified service person.
  • Page 5 COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE: The following requirements reference various Massachusetts and national codes not contained in this manual. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS...

  • Page 6: Specifications

    SPECIFICATIONS Figure 1A Height: 32 1/4" Width: 36" Depth: 20" Flue Size: 4" exhaust 7" intake Pier Model Shown This fireplace is factory-shipped as a see-thru fireplace. A pier conversion kit is available from your dealer. MASONRY APPLICATIONS - The following lintel irons are available for masonry applications: Pier installations: Part #788-C See-thru installations: Part #617 If masonry is used on both sides of a see-thru installation, a...

  • Page 7: Venting & Clearance Requirements

    VENT SYSTEMS: IMPORTANT: THIS FIREPLACE IS APPROVED FOR USE ONLY WITH ONE OF THE FOLLOWING DIRECT VENT SYSTEMS: KOZY HEAT #700 SERIES DIRECT VENT CHIMNEY SYSTEM: Horizontal terminations: #745 DIRECT VENT TERMINATION KIT— for terminations 4' or less. #718 DIRECT VENT TERMINATION KIT— for terminations greater than 4' but less than 8'.

  • Page 8: Prepare The Fireplace

    PREPARE THE FIREPLACE Note: This fireplace is shipped as a standard see-thru model. When a pier model is desired, a pier conversion kit is used and installed later in this manual. Follow the instructions below for glass assemblies, regardless of which model you are installing: REMOVE THE GLASS ASSEMBLY: Figure 2.

  • Page 9: Rough-In Dimensions

    HORIZONTAL TERMINATIONS: 1. Determine width & depth of the hearth (optional). 2. Determine the vent run and termination cap location. If possible, place the fireplace in such a manner that the piping will be placed between two studs so additional framing is not necessary. NOTE: Allow a minimum of 18"...
  • Page 10 PIER INSTALLATIONS: Refer to Figures 4A & 4B. Rough opening dimensions are 36 1/4" wide x 32 1/2" high (above the height of the optional hearth). Depth is determined by the thickness of facing materials being used. IMPORTANT! The fireplace depth is 20". Figure 4B Figure 4A Pier model shown in above figures...

  • Page 11: Venting Requirements

    VENTING REQUIREMENTS HORIZONTAL & VERTICAL VENTING CHART HORIZONTAL TERMINATIONS: Minimum horizontal run: 15" (18" length of pipe) (This is directly off the collars on the fireplace running at a 45-degree angle.) Maximum horizontal run: 20 Ft. Total run cannot exceed 20 Ft. The first 15"...
  • Page 12 TERMINATION VENT CAP LOCATION This gas appliance must not be connected to a chimney serving any other appliance. Terminations against vinyl siding must use a vinyl siding protector. Follow instructions included. DO NOT RECESS TERMINATION KIT INTO OUTSIDE BUILDING MATERIALS - i.e.: brick, stone, siding, etc. If necessary, extend framing so that termination kit will be exposed once building materials are installed.

  • Page 13: Restrictor Installation Instructions

    / wall materials first. The firestop or wall thimble from the chimney system is then attached to the firestop adaptor. Refer to Figure 4C, page 9. KOZY HEAT 700 SERIES DIRECT VENT SYSTEM...
  • Page 14 INSTALLATION OF THE #700 SERIES HORIZONTAL DIRECT VENT TERMINATION KIT(S) NOTE: THE FLEX PIPE IS PERMANENTLY ATTACHED TO THE EXTERIOR WALL PLATE. DO NOT ATTACHED THE #745 OR #718 TER- MINATION KIT TO THE FIREPLACE (OR EXTENSION KIT) UNTIL IT HAS PASSED THROUGH THE WALL. THE TERMINATION PLATES SHOULD ALL BE INSTALLED ON THE EXTERIOR OF THE OUTSIDE WALL.

  • Page 15: Vertical Venting Instructions

    VERTICAL VENTING REQUIREMENTS MAXIMUM VERTICAL RISE: 40 Ft. Vertically position the chimney by connecting (1) 45-degree elbow onto the #923-C vent adaptor. Connect the adaptor to the stacks on the fireplace and seal with the sealant provided MINIMUM CLEARANCE FROM CHIMNEY SYSTEM TO COMBUSTIBLES: 1" ELBOWS: ) Included within maximum vent runs - For each additional 90 elbow, the maximum horizontal run allowed...

  • Page 16: Rotating The Control Valve

    ROTATE THE GAS CONTROL VALVE - OPTIONAL IMPORTANT: THE CONTROL VALVE MAY BE ROTATED SO THAT IT IS ACCESSIBLE FROM THE OPPOSITE SIDE FROM WHICH IT WAS MANUFACTURED. THIS MUST BE DONE PRIOR TO CONNECTING THE GAS LINE. FOLLOW THE INSTRUCTIONS BELOW TO ROTATE THE CONTROL VALVE ASSEMBLY: NOTE: Although not necessary, it may be easier to rotate the control valve if the millivolt board is removed first.

  • Page 17: Fan Installation

    FAN INSTALLATION KIT (OPTIONAL INSTALLATION OF THIS FAN SHOULD BE DONE ONLY BY A QUALIFIED INSTALLER. This following items are included with this fan kit: (1) Left fan assembly with wire harness and fan cord attached. (1) Right fan assembly (1) Temperature control switch already wired (1) Electrical / Speed control box.

  • Page 18: Wiring Instructions

    Figure 11A WIRING INSTRUCTIONS: IMPORTANT: The electrical / speed control box is mounted to the left side of the gas valve bracket and secured with (2) phillips head screws. The electrical wiring should be sufficiently run to allow ample wire for proper connection to the electrical / speed control box once secured to the bracket.

  • Page 19: Minimum / Maximum Gas Supply Pressure / Run The Gas Line

    CAUTION: Installation of the gas line must only be done by a qualified person in accordance with local building codes. NOTE: This fireplace is equipped with a 3/8" flexible gas connection, 18" long. NOTE: The gas line should be run to the point of connection where the shut-off valve and flexible gas line will connect. CAUTION: The manual shut-off valve or flexible gas tubing must not extend outside of the fireplace cavity.

  • Page 20: Millivolt Board Removal / Installation

    MILLIVOLT BOARD REMOVAL / INSTALLATION. See Figures 12A & 12B. NOTE: The fireplace is equipped with the millivolt board already installed. Follow these procedures should the millivolt board need replacing or is removed for servicing. The control valve is reversible and may be installed so it is accessible from the opposite side from which it is factory-installed. See page #15 for instructions.

  • Page 21: Log Installation

    LOG INSTALLATION. See Figures 13A & 13B. This #944-500 log set includes: (2) L-Logs (2) AU-Logs (2) G-Logs (1) S-Log (1) D-Log(1) AK-Log (1) AL-Log (1) A-Log (2) Rockwool embers pkg. (1) Klinker pkg. LOG GRATE: Base Logs Place the log grate into position around the burner / cover assembly.

  • Page 22: Thermostat, Wall Switch, Remote Control Installation

    THERMOSTAT / WALL SWITCH / REMOTE CAUTION: DO NOT CONNECT HIGH VOLTAGE NOTE: INSTALLATION OF THERMOSTAT OR WALL SWITCH (115V) WIRE TO THE GAS VALVE! SHOULD ONLY BE DONE BY A QUALIFIED INSTALLER. If desired, a thermostat (wireless style also available), wall switch, or remote control assembly may be used to turn the fireplace „OFF‟...

  • Page 23: Pier Conversion

    Pier Model Installations: This kit includes: (1) 14 ½" x 17" glass with gasket (1) Arched valance with screen & grills installed. Remove the end panel: Loosen, but do not remove, the nuts securing the end panel from inside the upper grill opening.

  • Page 24: Complete The Installation

    COMPLETE THE INSTALLATION COMPLETE THE FIREPLACE WALLS AND THE UNIT FACING. SECURE THE FIREPLACE: Note: Nailing flanges are attached to the fireplace vented end and nailing tabs are at the top of the non-vented end. Vented end: 1. Loosen but do not remove the screws securing the nailing flanges on the vented end of the fireplace and remove the flanges. 2.

  • Page 25: Replace The Glass Assemblies

    THIS STEP SHOULD ONLY BE DONE BY A QUALIFIED INSTALLER OR SERVICE TECHNICIAN: Perform lighting and shutdown procedures as described on pages #26-27. This should be done prior to replacing the glass so that any necessary adjustments can be made and proper operation verified. Replace the front &...

  • Page 26: Lighting And Shutdown

    LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air.
  • Page 27 LIGHTING AND SHUTDOWN (cont.) LIGHTING 5 MINUTES Set thermostat to the lowest setting, if installed. Turn off all electrical power to the appliance. (Fan). Open lower grill to access the gas valve & controls. A. Push gas control knob in slightly and turn clockwise to “OFF”.
  • Page 28 LIGHTING AND SHUTDOWN (cont.) TURN BURNER OFF G. To turn the burner „OFF‟, depress the ON/OFF rocker switch to „OFF‟, flip „off‟ wall switch or adjust setting on the thermostat or remote control. NOTE: The pilot will stay lit. TURN PILOT OFF H.

  • Page 29: Pressure Testing

    PRESSURE TESTING IMPORTANT NOTICE: Pressure check taps for the manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked „OUT‟ measures outgoing pressure and the pressure tap marked „IN‟ measures incoming pressure. Follow instructions below for proper testing procedures. NOTE: The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of ½...

  • Page 30: Maintenance Requirements

    MAINTENANCE The appliance is required to be inspected at least once a year by a MILLIVOLT BOARD SYSTEM professional service person. The compartment below the firebox (behind the lower grill) must be cleaned Annual cleaning of the burner system is required. at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials.

  • Page 31: Troubleshooting

    TROUBLESHOOTING CAUTION: THE FOLLOWING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN. NO SPARK FROM ELECTRODE TO PILOT WHEN PIEZO BUTTON IS TRIGGERED. A. Check wiring at back of piezo for proper connection. B. Check wiring at electrode for proper connection. C.
  • Page 32 TROUBLESHOOTING BURNER WILL NOT LIGHT A. Gas control knob not turned to „ON‟. B. „ON‟/„OFF‟ switch not turned on. C. Remote, wall switch or thermostat not turned „ON‟. D. Plugged main burner orifice. E. Remote, wall switch ,thermostat or „ON/ OFF‟ switch wires defective. ♦...

  • Page 33: Replacement Parts

    REPLACEMENT PARTS LIST Replacement parts are available through your local dealer. Contact them for availability and pricing. 944 MILLIVOLT BOARD AND PARTS 944-770 MTK Millivolt Board - Nat Gas 700-094 Pilot Orifice - Natural Gas 944-771 MTK Millivolt Board - LP Gas...

  • Page 34: Warranty Policy

    PAGE 33...
  • Page 35 PAGE 34...
