VEST AND CROSS
GB
VEST
Mount the fixlocks in the back.
The vest and cross vest can be opened and
closed by using the buckles and the zipper.
* Mount the shoulder straps in the belt fittings
on the upper back. (A)
* Mount the upper straps in the sides in the belt
fittings on the back (B).
* Mount the lower straps in the sidest in the belt
fittings on the lower back (C).
Take care that all the fixations and adjust-
ments are placed and fitted correctly and
check it on a regular basis.

STERNUM BELT

GB
Mount the fixlocks in the back.
The sternum belt can be opened and closed by
using the buckles.
* Mount the shoulder straps in the belt fittings
on the upper back. (A)
* Mount the upper straps in the sides in the belt
fittings on the back (B).
* Mount the lower straps in the sidest in the belt
fittings on the lower back (C).
Take care that all the fixations and adjust-
ments are placed and fitted correctly and
check it on a regular basis.
A
B
C
A
B
C
