MOUNTING
GB
ADJUSTABLE FIX-
LOCKS
* Remove the back cushion.
* Place the fix-lock (A) in the slot (B) at the rear
of the back.
Note that the fix-lock has been cut our to fit the
back.
* Fit the screw (C) in the fix-lock from the inside
of the back.
The fix-lock can be adjusted up and down by
loosening the screw (C).
B
21
A
C
G
B
