R82 Serval User Manual

Hide thumbs Also See for Serval:
Table of Contents

Advertisement

Quick Links

Download this manual
serval
English user manual
© 2010 R82 A/S. All rights reserved.
The R82 logo and the Serval are registered trademarks of R82 A/S.
06.2012
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Serval and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for R82 Serval

Summary of Contents for R82 Serval

  • Page 1 English user manual © 2010 R82 A/S. All rights reserved. The R82 logo and the Serval are registered trademarks of R82 A/S. 06.2012...

  • Page 2: Table Of Contents

    Adjusting the push brace ..................6 Serval wheels ......................7 Reversible seat ......................8 Panda and x:panda seat on Serval frame ............... 9 (continued)Panda and x:panda seat on Serval frame ........... 10 Mount a foot support....................11 Back and seat angling ....................11 Back and Seat width ....................

  • Page 3: Serval

    Pat. pend. SERVAL Congratulations on choosing the Serval as your new pushchair. It is a high quality R82 product and we are convinced that it will fully live up to your expecta tions. ½ - 5 y The Serval is a unique pushchair for disabled children from ½ up to aprox 5 years of age.

  • Page 4: Safety

    SAFETY The Serval has erned the CE-mark. This certifies that it meets all relevant European safety requirements. Further the Serval is approved according to ISO 7176/19-2001, EN 12182. The durability of this product is 5 years when it is used on a daily basis. Hereafter the product must be renovated (by R82 personnel) to extend the lifetime.

  • Page 5: Warranty

    TOOLS In the rucksack mounted on the Serval, there is a small bag with an 4 mm Allen key. This tool is used to perform some of the adjustments described in this man ual. In the rucksack there is also a pump for the tyres.

  • Page 6: Serval Ready For Use

    SERVAL READY FOR USE Serval is folded, when delivered, but is unfolded very easily: 1) The frame is folded out by lifting the push brace. Fold out until the lock fitting (A) "clicks" into place on either side of of the frame.

  • Page 7: Serval Wheels

    The frame can be delievered with either solid tires (rubber) or air tires. The Serval has good suspension, which make it easy to drive, even on broken ground. The air pressure in the tires must be 36 PSI/ 2,5 bar.

  • Page 8: Reversible Seat

    REVERSIBLE SEAT The Serval seat is reversible 180 . The easiest way is as follows: Remove the child before turning the seat around. * Pull the handle (A) on the back, and the alu- minium fitting (B) to release the seat from the frame.

  • Page 9: Panda And X:panda Seat On Serval Frame

    Serval frame. This requires an interface between frame and seat. Click the interface on to the frame (A) and ensure that safety lock (B) is engaged. If the Serval seat need to be dismounted, please see the section "Reversible seat".

  • Page 10: (Continued)Panda And X:panda Seat On Serval Frame

    10 cm forward and backward (A) to obtain the correct centre of gravity and good stability for the Serval. Adjust the interface by removing the 4 screws with 4 mm. allen key and a 10 mm. spanner. Move the interface to the wanted posi- tion and fasten the 4 screws again.

  • Page 11: Mount A Foot Support

    MOUNT A FOOT SUPPORT Loosen the screws (A) with a 5 mm allen key and the foot support is mounted by placing the bars in the interface. Then refasten the screws (A). For adjusting the foot support, please see sec- tion "Foot support".

  • Page 12: Back And Seat Width

    BACK AND SEAT WIDTH The seatwidth can be adjusted by placing an extra cushion at both sides below the seat cushion (A). Please be careful not to get fingers caught between the side frame and the plate. SEAT DEPTH To adjust the seatdepth loosen the Allen screws (B) below the seat cushion.

  • Page 13: Brakes And Directional Stabilizer

    BRAKES AND DIRECTIONAL STABILIZER Activate the brakes on the Serval (A). With the directional stabilizer the wheels can be locked in the driving position (B). RUCKSACK Mount the rucksack by mounting the upper straps in the fixlocks (A). Then mount the lower straps with the velcro (B).

  • Page 14: Back Extension

    BACK EXTENSION The Serval can be equipped with a removable and heightadjustable back extension (A). Tighten the fingerscrews (A). Make sure that the back extension is se- curely mounted. HEADREST CUSHION To mount the headrest cushion: Without back extension: The straps (A) are attached to the fixlocks (B) at the top back.

  • Page 15: Head Rest

    HEAD REST Mounting and height adjustment: Loosen the handle (A). Angle adjustment: Loosen the screws (B) with a spanner. Sideways adjustment: Loosen the screw (C). Fasten all screws at the desired position. Mount the cover on the head support.

  • Page 16: Side Supports

    SIDE SUPPORTS Remove the back cushion and mount the side supports in the slots in the back. A) The swing away side supports can, when mounted be adjusted both in hight and width. To ease the placement of the child, swing the side supports away.

  • Page 17: Folding Top

    Place the fittings for the folding top in the back of the chair and tightened (A). Push the folding top into the fittings. Now mount the back extention in the same fit- tings again. Do not grap hold of the folding top, when lifting the Serval.

  • Page 18: Footrest

    FOOTREST The footrest should support the child and prevent the child from sliding out of the chair. Do not use the footrest as treadle. Squeeze the two handles (A) together and adjust the height. Turn the handle (B) to angle the footplate. To angle the footrest bar, pull out the black strap below the seat (C).

  • Page 19: Pommel

    POMMEL Mount the fittings to the seat under the seat cushion (A). Pull downwards on the handle (B) and lead the abduction block through the hole in the cushion, into the fittings.

  • Page 20: Tray

    TRAY Mount the fittings on the sides and fasten with the fin ger screws (A). Mount the tray afterwards (B). Use the Allen key to loosen below the plate and the tray is depthadjustable (C). Max. weight on the tray is 5 kg. HAND BRACE Place the hand brace in the fittings on both sides and fasten with the finger screws (D).

  • Page 21: Mounting Adjustable Fix-Locks

    MOUNTING ADJUSTABLE FIX- LOCKS * Remove the back cushion. * Place the fix-lock (A) in the slot (B) at the rear of the back. Note that the fix-lock has been cut our to fit the back. * Fit the screw (C) in the fix-lock from the inside of the back.
  • Page 22 Use this drawing together with the descriptions on the following pages.

  • Page 23: Vest And Cross Vest

    VEST AND CROSS VEST Mount the fixlocks in the back. The vest and cross vest can be opened and closed by using the buckles and the zipper. * Mount the shoulder straps in the belt fittings on the upper back. (A) * Mount the upper straps in the sides in the belt fittings on the back (B).

  • Page 24: 5-Point Belt

    5-POINT BELT Mount the fixlocks in the back. The 5-point belt can be opened and closed by using the buckles. * Mount the straps (E) in the fix-locks in the seat (D). * Place the user in the chair, sitting on the "tri- angle"...

  • Page 25: Hip Belt

    HIP BELT The hip belt can be opened and closed by using the buckles. * Mount the straps in the belt fittings in seat (D). Take care that all the fixations and adjust- ments are placed and fitted correctly and check it on a regular basis.

  • Page 26: Pelvis Harness

    PELVIS HARNESS * Open the buckles (G). * Mount the straps (D) in the belt fittings under the seat (D). * Place the user on the harness and close the buckles (G) over the thighs. Take care that all the fixations and adjust- ments are placed and fitted correctly and check it on a regular basis.

  • Page 27: B Foot Straps

    FOOT STRAPS The foot straps can be opened and closed by using the velcro or the buckle (A). Follow the instructions below for mounting. * Open the straps and pull them (A) through the slides in the foot plates. * Close the straps around the users foot. Take care that all the fixations and adjust- ments are placed and fitted correctly and check it on a regular basis.

  • Page 28: Transportation Belt

    TRANSPORTATION BELT The belt goes around the persons chest and around the back of the chair. Use the velcro for closing the belt and lock with the metal lock. Take care that all the fixations and adjust- ments are placed and fitted correctly and check it on a regular basis.

  • Page 29: Thermo Bag

    THERMO BAG * Place the thermo bag in the chair. * Unzip the bag in the sides and place the user in it. * Zip it again. There is velcro slides in the sides of the bag, which make it possible also to use a hip belt. Take care that all the fixations and adjust- ments are placed and fitted correctly and check it on a regular basis.

  • Page 30: Shopping Basket

    SHOPPING BASKET A) Place the shopping on the frame under the seat. B) Attach the shopping basket to the frame by fastening with velcro around the crossbar. SHOPPING NET Attach the shopping net to the push brace frame by fastening the rubber fittings. Any load attached to the push brace affects the stability of the push chair.

  • Page 31: Folding The Serval

    SERVAL The Serval is folded/unfolded very easily and therefore easy to bring anywhere. There are two ways to fold the Serval: 1) with the seat on the frame 2) the seat is dismounted before folding With the seat on the frame: A) Pull out the black strap and tip the footsupport into a horizontal position.

  • Page 32: Transportation In Motor Vehicles

    The Serval is approved for transporting children in motor vehicles, when the wheelchair is placed in forward-facing position. The Serval is not delivered with hip-belt ne- eded to secure the user in the pushchair. The approval is not valid on special made Restraints should chairs.

  • Page 33: Prepare The Serval For Transport

    (A) with nuts, bolts and a 4 mm allen key.   Back angling: * Angle the back of Serval by pulling lightly in the strap back on the chair (C). Hold onto the back to prevent it from sud- denly erking when the strap is pulled.

  • Page 34: Secure The Serval In The Vehicle

    SECURE THE SERVAL IN THE VEHICLE 30° * Mount the 4-point strap-type tiedown system 45° 75° in the vehicle. (Follow the manufacture in- structions) * Secure the pushchair to the vehicle, using 15° 15° the4-point strap-type tiedown system. Use either a hook or a strap in the fitting.

  • Page 35: Secure The Child In The Serval

    SECURE THE CHILD IN THE SERVAL * Mount the two fittings (A), for the approved hip-belt (B), in the pre drilled holes on the back of the Serval. * Mount the approved hip-belt (B) in the fittings (A) and fasten the user in the puchchair.

  • Page 36: Product Identification

    PRODUCT IDENTIFICATION A) Serial number The label is placed in the middle, on the throug-going bar, below the seat. B) Manufacturer The label is placed to the left, on the throug- going bar on the frame. Dato: 31-01-02 Belast: 0840-01-111878-001 Varenr: 880003 5707292...

  • Page 37: Measurements

    Max. load / user weight 35 kg 50 kg Max. load / user weight at transportation 35 kg 43 kg Angles Footrest bar - 42 Back - 65 Seat - 31 Further information regarding max. load/user weight and transportation: www.R82.com/archive/Publications/Pdf/Chart_transport.pdf...

  • Page 38: Technical Data

    TECHNICAL DATA Frame: Chrome or powder lacquered steel Plastic parts: Fibre glass strengthened polyprolene Cushion: Fire-resistant foam Fabric: Fire-resistant microfibre DISTRIBUTOR PRODUCER R82 A/S Parallelvej 3 DK- 8751 Gedved www.R82.com Please find your distributor on www.R82.com...

  • Page 39: Stain Removal Guide

    STAIN REMOVAL GUIDE The Serval cushion is removable and can be washed at max. 30 . It is important to keep the frame clean to maintain the validity of the chair. BLOOD Wasoff blood with cold water. If this fails to help, add a neutral kitchen detergent.
