SmartNode 5200 User Manual
SmartNode 5200 rear panel
The SmartNode 5200 is a compact VoIP Gateway Router that supports 32 simultaneous SIP sessions. The
SmartNode 5200 rear panel ports are described in
Model SN5200
Port
WAN ETH 0/0
LAN (ETH 0/1) 1–4 Switched Auto-MDX Fast-Ethernet ports, RJ-45 (see
5V DC, 1.0A
Reset
SmartNode 5200 overview
WAN ETH 0/0
Ethernet port
Figure 2. SmartNode 5200 rear panel
Table 2. Rear panel ports
Auto-MDX Fast-Ethernet port, RJ-45 (see
device (for example, a cable modem, DSL modem, or fiber modem).
net LAN (for example, a PC, printer, or wireless bridge).
The Model 5200 has a 5V DC power input (see
The reset button (see
figure 2
Restart the unit with the current startup configuration—Press (for less than 1 second)
•
and release the Reset button to restart the unit with the current startup configuration.
Restart the unit with factory default configuration—Press the Reset button for
•
5 seconds until the Power LED (see
the unit with factory default configuration.
•
Restart the unit in bootloader mode (to be used only by trained SmartNode tech-
nicians)—Starting with the unit powered off, press and hold the Reset button as
you apply power to the unit. Release the Reset button when the Power LED starts
blinking so the unit will enter bootloader mode.
table
2.
LAN (ETH 0/1)
Ethernet ports 1–4
Description
), connects the unit to an Ethernet WAN
figure 2
figure 2
) has three functions:
on page 17) starts blinking to restart
figure 3
1 • General information
), connect the unit to an Ether-
figure 2
).
16
