  • Page 1 Laser Barcode Scanner User’s Manual...

  • Page 2: Fcc Compliance

    FCC Compliance This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 3: Table Of Contents

    Table of Contents INTRODUCTION………………………………………………………………………………..….2~3 INSTALLATION………………………………………………………………………………..…..4 SET UP FROM BAR CODE LABEL………………………………………………………….……..7 Multi-interface Functions……….………………………………………………………..8~9 Interface-KBW………………………………………………………………………………….10 Interface-Serial……..……………………………………………………………………11~12 Symbologies On/Off…………………………………………………………………….13~15 Symbologies Set Up…………………………………………………………………….16~21 Edit Setup Bar Codes……………………………………….……………….………..…… 22 Macro/Special Keys Setup Bar Codes………………………………………………….23 Termination String Setup Bar Codes…………………………………………………..24 APPENDIX A: TROUBLESHOOTING AND ERROR BEEPS……..………………….25~29...

  • Page 4: Introduction

    Introduction...
  • Page 5 Our 1D Laser barcode scanner combines the best scanning performance and value. The device provides an accurate, easy, and fast method of data entry and data storage for computerized information systems. It is easy to install and does not require Software or drivers to operate. Our laser barcode scanner can compatible several interfaces (USB, K/B, RS-232,) and numerous configurations, is a powerful and reliable handheld scanner without compromise.

  • Page 6: Installation

    Installation Insert the plug on the free end of the Communications Cable into the appropriate connector on the host as below described: 1. USB cable Connection: Connect with PC Reset Configuration to Defaults If you are unsure of the scanner configuration or have scanned the incorrect codes, please scan the “Reset Configuration to Defaults”...
  • Page 7 Reset Configuration to Defaults If you are unsure of the scanner configuration or have scanned the incorrect codes, please scan the “Reset Configuration to Defaults” barcode. This will reset the scanner to its factory defaults settings in PS/2 interface. 3. RS232 cable Connection: Connect with PC Require adapter for power supply NOTE: for Serial port (RS232 cable), please plug the power connector of 5V power...
  • Page 8 4. Auto-sensing setup For some scanners have auto-sensing function. There is an auto-sensing function button shown on below photo. Default is ON. *Auto-sensing normally is ON. Press once is OFF, Press once again is ON. Auto-sensing button Operation Be sure that Host computer is turned OFF. Ensure that all connections are secure.

  • Page 9: Setup From Bar Code Label

    Maintenance Cleaning the scan window is the only maintenance required. A dirty window may affect scanning accuracy. Wipe the scanner window gently with a lens tissue or other material suitable for cleaning optical material. Do not spray water or other cleaning liquids directly onto the window. Setup from Bar Code Label...

  • Page 10: Multi-Interface Functions

    Multi-Interface Functions – 1 OUTPUT FIRMWARE VERSION RESET CONFIGURATION TO DEFAULTS OUTPUT OUTPUT MODE – KEYBOARD / USB OUTPUT MODE - SERIAL MODE BUZZER / GOOD READ BEEP TONE – NONE GOOD READ BEEP TONE - RESET IMAGE DECODE OPTIONS REVERSE IMAGE – DECODE OPTIONS REVERSE IMANGE ENABLE - DISABLE...

  • Page 11: Multi-Interface Functions

    Multi-Interface Functions – 2 READING SCAN MODE – SINGLE SCAN SCAN MODE – SINGLE SCAN NO MODE TRIGGER SCAN MODE – MULTISCAN SCAN MODE – MULTISCAN NO TRIGGER SCAN MODE - PULSE LASER/CCD TIMEOUT – 5 SECONDS LASER/CCD TIMEOUT – 2 SECONDS LASER/CCD PULSE RATE - 7 LASER/CCD PULSE RATE - 3...

  • Page 12: Interface-Kbw

    Interface – KBW Communication WEDGE MODE - AUTODETECT WEDGE MODE – SCAN SET 2 PASS THRU TRANSMIT TRANSMIT SPEED - 0 TRANSMIT SPEED - 25 SPEED...
  • Page 13 Keyboard Language DENMARK FINLAND FRANCE GERMANY ITALY LATIN AMERICA NETHERLANDS NORWAY POLAND SPAIN SWITZERLAND SWITZERLAND (FRENCH) (GERMAN) SWEDEN UNITED KINGDOM UNIVERSAL UNITED STATES *As a general rule, the following characters are not supported by the scanner for countries other than the United States: @ | $ # { } [ ] = / ‘...

  • Page 14: Interface-Serial

    Interface – Serial - 1 BAUD RATE SERIAL BAUD RATE - 2400 SERIAL BAUD RATE - 4800 SERIAL BAUD RATE - 9600 SERIAL BAUD RATE - 19200 HAND SHAKE SERIAL HANDSHAKE – XON/XOFF SERIAL HANDSHAKE - NONE SERIAL HANDSHAKE – RTS/CTS SERIAL HANDSHAKE –...
  • Page 15 Interface – Serial - 2 PARAMETERS SERIAL DATA BITS - 8 SERIAL DATA BITS - 7 SERIAL STOP BITS - 2 SERIAL STOP BITS - 1 SERIAL PARITY - NONE SERIAL PARITY - ODD SERIAL PARITY - EVEN SERIAL PARITY - MARK SERIAL PARITY - SPACE SERIAL PARITY - RESET...

  • Page 16: Symbologies On/Off

    Symbologies On/Off - 1 CODE 11 CODE 11 - ENABLE CODE 11 - DISABLE CODE 39 CODE 39 ENABLE CODE 39 DISABLE FULL ASCII ENABLE FULL ASCII DISABLE...
  • Page 17 Symbologies On/Off - 2 CODE 93 CODE 93 - ENABLE CODE 93 - DISABLE CODE 128 CODE 128 - DISABLE CODE 128 - ENABLE CODE 128 ISBT - DISABLE CODE 128 ISBT - ENABLE CODABAR CODABAR - ENABLE CODABAR - DISABLE INTERLEAVED 2 OF 5 I2OF5 - ENABLE...
  • Page 18 Symbologies On/Off - 3 MSI - ENABLE MSI - DISABLE UPC/EAN UPC-A DISABLE UPC-A ENABLE UPC-E DISABLE UPC-E ENABLE EAN-13 ENABLE EAN-13 DISABLE EAN-8 ENABLE EAN-8 DISABLE...

  • Page 19: Symbologies Set Up

    Symbologies Set Up - 1 CODE 11 CODE 11 ID CHARACTER – “m” CODE 11 ID CHARACTER – “Z” CODE 11 DOUBLE CHECK - ENABLE CODE 11 DOUBLE CHECK - DISABLE CODE 39 CODE 39 SS CHAR - NONE CODE 39 SS CHAR ‛+’ CODE 39 SEND START/STOP CHARS CODE 39 SEND START/STOP CHARS ENABLE...
  • Page 20 Symbologies Set Up – 2 CODE 93 CODE 93 ID CHARACTER – “h” CODE 93 ID CHARACTER – “Z” CODE 93 DOUBLE CHECK - ENABLE CODE 93 DOUBLE CHECK - DISABLE CODE 128 CODE 128 ID CHARACTER – ‛g’ CODE128 ID CHARACTER - ‛Z’ CODE 128 DOUBLE CHECK - ENABLE CODE 128 DOUBLE CHECK - DISABLE CODABAR...
  • Page 21 Symbologies Set Up – 3 CODABAR CODABAR ID CHARACTER –‛k’ CODABAR ID CHARACTER –‛Z’ CODABAR DOUBLE CHECK - ENABLE CODABAR DOUBLE CHECK - DISABLE Interleaved 2 of 5 I2OF5 CHECK DIGIT - DISABLE I2OF5 CHECK DIGIT - ENABLE I2OF5 ID CHARACTER – ‛i’ I2OF5 ID CHARACTER –...
  • Page 22 Symbologies Set Up – 4 ID2OF5 DOUBLE CHECK - ENABLE ID2OF5 DOUBLE CHECK - DISABLE MSI CHECK DIGIT – MOD 10 MSI CHECK DIGIT –RESET MSI ISBN ID CHARACTER –‛f’ MSI ISBN ID CHARACTER –‛Z’ MSI DOUBLE CHECK - ENABLE MSI DOUBLE CHECK - DISABLE UPC/EAN EXPAND UPC-E TO UPC-A ENABLE...
  • Page 23 Symbologies Set Up – 5 SEND UPC-A CHECK DIGIT ENABLE SEND UPC-A CHECK DIGIT DISABLE SEND UPC-E CHECK DIGIT ENABLE SEND UPC-E CHECK DIGIT DISABLE SEND EAN-13 CHECK DIGIT ENABLE SEND EAN-13 CHECK DIGIT DISABLE SEND EAN-8 CHECK DIGIT ENABLE SEND EAN-8 CHECK DIGIT DISABLE UPC-A ID CHARACTER ‛b’...
  • Page 24 Symbologies Set Up – 6 EAN-8 ID CHARACTER ‛d’ EAN-8 ID CHARACTER ‛Z’ UPC/EAN ISBN ID CHARACTER ‛f’ ISBN ID CHARACTER ‛Z’ UPC/EAN SUPPLEMENTS - DISABLE UPC/EAN SUPPLEMENTS – 2 DIGIT ONLY UPC/EAN SUPPLEMENTS – 5 DIGIT ONLY UPC/EAN SUPPLEMENTS – 2 & 5 DIGIT UPC/EAN DOUBLE CHECK ENABLE UPC/EAN DOUBLE CHECK DISABLE...

  • Page 25: Edit Setup Bar Codes

    EDIT SETUP BAR CODES EDIT #1 – STRIP 1 LEADING CHARACTER EDIT #1 - OFF ON ALL BAR CODES THAT START WITH ‛12345’ EDIT #2 – STRIP 1 TRAILING CHARACTER EDIT #2 – OFF EDIT #1 – FILTER LEADING SPACES EDIT #1 - OFF EDIT –...

  • Page 26: Macro/Special Keys Setup Bar Codes

    MACRO/SPECIAL KEYS SETUP BAR CODES MACRO #1 – FIND ‛1’ AND REPLACE WITH MACRO #1 - DISABLED ‛ONE’ MACRO #2 - DISABLED MACRO #2 – FIND ‛2’ AND REPLACE WITH ‛TWO’ FOR CODE 39 ONLY MACRO – FIND ‛0’ AND REPLACE WITH ‛A’ MACRO –...

  • Page 27: Termination String Setup Bar Codes

    TERMINATION STRING SETUP BAR CODES STRING #1 – TERMINATION CHAR - CR STRING #1 – TERMINATION - LF STRING #1 - DISABLE STRING #1 – TERMINATION CR+LF STRING #2– CODE 128 TERMINATION CHAR - STRING #2 – CODE 128 TERMINIATION CHAR - STRING #2–...
  • Page 28 Appendix-A Troubleshooting & Error Beeps...
  • Page 29 a. Problem: Nothing happens when I follow the operating instructions. Possible Cause Possible Solution Interface cables are loose Check for loose cable connections b. Problem: When I connected RS232 interface reader to PC, I could not get power up signal. Possible Cause Possible Solution There is no power from PC series...
  • Page 30 d. My computer gets a keyboard error while booting up. Possible Cause Possible Solution The scanner is damaged or is no Disconnect the scanner from your longer functioning. computer and use your keyboard only. Reboot your computer. If your computer still gets a keyboard error, then the problem may not be the scanner.
  • Page 31 Problem: The scanner beeps, but no data is displayed on my computer. Possible Cause Possible Solution Scanner is not programmed for the Please make sure the scanner is correct host type. configured to the appropriate host type by scanning the corresponding programming barcode on the User’s Manual.
  • Page 32 h. Problem: Some of the barcode data is missing displayed on the host. Possible Cause Possible Solution The scanner’s transmit speed is too For RS232, you can set up the fast. scanner’s transmit speed. My Caps Lock LED on my keyboard flickers when I read a bar code. Possible Cause Possible Solution The Keyboard Country that you are...
  • Page 33 Version: 2.0 Date: November 11, 2008 P/N: 79.60002.101...
