RIOTEC CR6300C Programming Quick Manual

Programming Quick Guide
CR6300C/CR6320C/FS5020C

Installation

Make sure that the scanner has the correct cable to plug
into the PC as below described:
1. USB cable connection
(Please use correct cable for the interface)

Reset Configuration to Default

If you are unsure of the scanner configuration or have
scanned the incorrect codes, please read the "Default"
barcode. This will reset the scanner to its factory default.
0B
1.
2.
HID Default

2. Auto-sensing setup

The auto-sensing will be activated while scanner puts on
stand. When scanner is removed from stand, it becomes
trigger mode.
OUTPUT
OUTPUT MODE -
MODE
KEYBOARD / USB
READING
MODE
SINGLE SCAN
.
LASER TIMEOUT
- 5 SECONDS
Demo

Keyboard Language

Scan the appropriate country code as below to program the keyboard layout
for your country or language. As a general rule, the following characters are
supported, but need special care for countries other than the United
@ | $ # { } [ ] = / ' \ < > ~
USA
FRANCE
ITALY
NETHERLANDS
0005012
OUTPUT MODE
- RS232 (SERIAL) BELGIUM
SINGLE SCAN
NO TRIGGER SWITZERLAND
LASER TIMEOUT
- 2 SECONDS
SWEDEN
CANADA
States:
GREECE
FINLAND
JAPAN
GERMANY
TURKEY1
PORTUGAL
NORWAY
0005019
0005013
SPAIN
RUSSIAN
CZECH
DENMARK
HUNGARY
ENGLAND
TURKEY2
0005021
0005020
