RIOTEC FS5100D Programming Quick Manual

Programming Quick Guide
- FS5100D

Installation

Make sure that the scanner has the correct cable to
plug in the PC as below described:
*Note : Please install PL-2303 driver for USB serial

Reset Configuration to Defaults

If you are unsure of the scanner configuration or have
scanned the incorrect codes, please scan from A1 to A6 for
USB HID or B1 for RS232 or USB Serial. This will reset the
scanner to its factory defaults.
HID
A1 B1
A2
%%RSDF
A3
%SETUP
A4
A5
8002
A6
* Note: Please install PL-2303 driver for USB Serial.
0
%%%END D
1

Keyboard Country

Scan the appropriate country code as below to program the
keyboard layout for your country or language. As a general
rule, the following characters are supported, but need special
care for countries other than the United States:
@ | $ # { } [ ] = / ' \ < > ~
RS232/
USB Serial
USA
(Original setting)
%+-$.00
%%RSDF
Norway
%+-$.01
Germany
%+-$.02
Sweden
%+-$.03
Denmark
%+-$.04
Switzerland
%+-$.05
(For USB HID only)
Italian
%+-$.06
France
%+-$.07
Vietnam
%+-$.08
Spain
%+-$.09
Portugal
%+-$.10
Hungary
%+-$.11
