RIOTEC FS5107A Programming Quick Manual

Programming Quick Guide
- FS5107A

Installation

Make sure that the scanner has the correct cable to
plug in the PC as below described:
*Note : Please install PL-2303 driver for USB serial

Reset Configuration to Defaults

If you are unsure of the scanner configuration or have scanned the incorrect
codes, please scan from A1 to A7 for USB HID or B1 to B7 for RS232 or USB
Serial. This will reset the scanner to its factory defaults.
USB HID
A1
A2
A3
A4
A5
A6
A7
* Note: Please install PL-2303 driver for USB Serial.

Barcode Configuration Method:

(Flow chart for setup procedure :)
Start
Configuration
1
Keyboard Country
Scan the appropriate country code as below to program the keyboard
layout for your country or language. As a general rule, the following
RS232 or USB Serial
characters are supported, but need special care for countries other
than the United States: @ | $ # { } [ ] = / ' \ < > ~
B1
USA
(Original setting)
B2
Denmark
B3
France
B4
Italy
B5
1D Symbologies – 1
B6
ENABLE
B7
ENABLE
ENABLE
ENABLE
End
ENABLE
Configuration
(For USB HID Only)
Japan
Finland
Germany
Norway
CODE 39 DISABLE
CODE 39 Transmit
Start/Stop Character DISABLE
CODE 39
FULL ASCII DISABLE
CODE 128 DISABLE
GS1-128
UCC/EAN-128 DISABLE
