Programming Quick Guide
- FS5103A
Installation
Reset Configuration to Default :
If you are unsure of the scanner configuration or have scanned the
incorrect codes, please scan A1 to A2 for USB HID or B1 for RS232 /
USB Serial. This will reset the scanner to its factory defaults.
USB HID
A1
B1
A2
*Note : Please install PL-2303 driver for USB serial
Keyboard Language (For USB HID only)
Scan the appropriate country code as below to program the
keyboard layout for your country or language. As a general
rule, the following characters are supported, but need special
care for countries other than the United States:
@ | $ # { } [ ] = / ' \ < > ~
USA
(Original setting)
Norway
Germany
Sweden
Denmark
RS232 / USB Serial.
Switzerland
Italian
France
Vietnam
Spain
Portugal
Hungary
1
1D Symbologies – 1
CODABAR
ENABLE
Code 39
ENABLE
ENABLE
Code 32
Code 39
ENABLE
FULL ASCII
ENABLE
Interleaved 25
ENABLE
Code93
Matrix 25
ENABLE
IATA 25
ENABLE
DISABLE
DISABLE
DISABLE
DISABLE
DISABLE
DISABLE
DISABLE
DISABLE
