User- and installation manual
Lucius 140 T, Lucius 140 R
Lucius 140 CR 1/3, Lucius 140 CR 2/3
WARNING - THE COMBUSTION CHAMBER OF THIS
STOVE SHOULD ONLY BE OPENED AND SERVICED BY A
REGISTERED GAS INSTALLER
(i.e. GAS SAFE REGISTERED ENGINEER[GB])
These instructions should be left with the customer
for future reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lucius 140 T and is the answer not in the manual?

Questions and answers

Related Manuals for Element4 Lucius 140 T

Summary of Contents for Element4 Lucius 140 T

  • Page 1 User- and installation manual Lucius 140 T, Lucius 140 R Lucius 140 CR 1/3, Lucius 140 CR 2/3 WARNING - THE COMBUSTION CHAMBER OF THIS STOVE SHOULD ONLY BE OPENED AND SERVICED BY A REGISTERED GAS INSTALLER (i.e. GAS SAFE REGISTERED ENGINEER[GB])

  • Page 2: Table Of Contents

    This Manual Covers the following appliances: Lucius 140 T, Lucius 140 R, Lucius 140 CR 1/3, Lucius 140 CR 2/3 Contents GENERAL INFORMATION......................3 Important Safety Notice .........................3 General Fitting Information ....................4 USER INFORMATION........................5 Remote Control Electronic Ignition System RCE GV60 ...............5 INSTALLER INFORMATION..............

  • Page 3: General Information

    GENERAL INFORMATION Important Safety Notice ing regulations. It is therefore recommend that a registered gas installer be employed for this This appliance has a ceramic Fire-bed arrange- task. The engineer will provide you with informa- ment; this contains Refractory Ceramic Fibres, tion about the safety limits of the installation and which are man-made vitreous silicate fibres.

  • Page 4: General Fitting Information

    GENERAL INFORMATION General Fitting Information ment of the Environment, the Building Standards (Scotland) (Consolidation) Regulations issued by Inlet pipe connection 8mm compression the Scottish Development Department. Chimney requirements Balanced Flue Flue monitor Permanent Pilot BS 5440 part 1, BS 5871 part 2 and BS 6891. User control: Variable rotary control inc.

  • Page 5: User Information

    Remote control electronic ignition - temperature display in degrees Celsius or USER INFORMATION system RCE GV60 Fahrenheit; USER INFORMATION - time; - thermostat function; Remote control electronic ignition sys- The appliance is supplied with a remote control. - temperature display in degrees Celsius or Remote control electronic ignition - temperature display in degrees Celsius or - timer for thermostat function.
  • Page 6 USER INFORMATION USER INFORMATION USER INFORMATION MAN position I g n i t e t h e a p p l i a n c e f o l l o w s : MAN position I g n i t e t h e a p p l i a n c e a s f o l l o w s : By briefly pressing the SET button, you will go S e t b u t t o n A o n t h e g a s c o n t r o l t o MAN position...
  • Page 7 USER INFORMATION Flame height / standby Time The flame height can be adjusted continuously by The display can indicate time. using the buttons After placing the battery or simultaneously press- (large flame) and By continuing to lower the flame height, the ap- pliance can be set to the standby position;...
  • Page 8 USER INFORMATION Example Timer for thermostat function By using the Y TEMP function you can keep the Using the timer enables you to set two times per day temperature at 20 °C; while 24 hours for switching on the day temperature you use the 4 TEMP function at night to maintain and two times per 24 hours for switching on the a temperature of 15 °C.
  • Page 9 USER INFORMATION Setting times for the timer Replacing the battery To set the timer, proceed as follows: If the battery is almost empty, the display will Set the day and night temperature as described show “BATT”. above Briefly press the SET button to enter the (P*) To replace the battery, proceed as follows: Remove the cover at the back side of the TIMER position.

  • Page 10: Installer Information

    INSTALLER INFORMATION restricted to the Flue systems as specified by nstallatIon the supplier, thus the appliance must only be Before beginning the installation, check that the installed with the original flue system, no others details on the rating plate correspond to the gas may be used type and pressure to which the appliance will be connected.
  • Page 11 INSTALLER INFORMATION appliance. The controls need to be located in the completely open and unobstructed sides. The control access box, so an appropriate position for distance between the lowest part of the roof and the access box need to be determined. the top of the terminal should be at least 600mm.

  • Page 12: Terminal Locations Wall Mounting

    INSTALLER INFORMATION INSTALLER INFORMATION Terminal Locations Wall Mounting Dimension Terminal Position Distance (mm) Dimension Terminal Position Distance (mm) Directly below an opening,air brick, opening window etc. Directly below an opening,air brick, opening window etc. Above an opening,air brick, opening window etc. Above an opening,air brick, opening window etc.

  • Page 13: Terminal Locations Roof Termination

    INSTALLER INFORMATION Terminal Locations Roof Termination “Distance” = minimum distance required for positioning of the outlet to avoid adverse effects with respect to: A ventilation opening serving an occupied room, a toilet or a bathroom A heating air supply, when the supply flows through an occupied room. A window that can be opened and that is near an occupied room, a toilet or a bathroom.

  • Page 14: Concentric Flue Parts Identification

    INSTALLER INFORMATION Concentric Flue Parts Identification The following pages identify the parts that may be used in the Balanced Flue installation of this appliance. The Item number in the table refers to the item number of the part in the Identification pages, this Item number is also the number that will be used to identify parts in the Installation suggestion diagrams.
  • Page 15 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 16 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 17 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 18 INSTALLER INFORMATION INSTALLER INFORMATION...
  • Page 19 INSTALLER INFORMATION INSTALLER INFORMATION USVK 100 130 REDUCER Ø130 - Ø100 USDHC 130 HORIZONTAL TERMINALØ130...
  • Page 20 INSTALLER INFORMATION INSTALLER INFORMATION USBI 100 130 Elbow 90° with inspection cover USI 100 130 Inspection Element...

  • Page 21: Flue Restrictor

    INSTALLER INFORMATION FLUE RESTRICTOR - When using Flue system (200/130) with a wall terminal DON’T use any restrictor - When using Flue system (200/130) and vertical is > 1.25 m and then direct through the wall (and no more horizontal) use flue restrictor 35 mm. - When using a roof terminal Flue system (150/100) and vertical is between1.25 m and 2.0 m use restrictor 35 mm.

  • Page 22: Wall Terminal Terminations

    Rigid Balanced Flue Connection Possibilities Horizontal Wall Termination Horizontal Wall Termination Lucius 140 T, Lucius 140 R, Lucius 140 CR 1/3, Lucius 140 CR 2/3 Lucius 140 T, Lucius 140 R, Lucius 140 CR 1/3, Lucius 140 CR 2/3 Diameter Concentric Flue: 200/130...

  • Page 23: Vertical Roof Terminations

    INSTALLER INFORMATION Vertical Roof Terminations When installing the appliance with a roof termination (classification 31) it is important to fit a flue restrictor across the flue outlet inside the fire. Roof terminations will need the 60 mm flue restrictors fitting. This is delivered with the fire. Distance “V”...
  • Page 24 INSTALLER INFORMATION INSTALLER INFORMATION Vertical Roof Mounted Termination with Elbow for Rigid Concentric Flue Vertical Roof Mounted Termination with Elbow for Rigid Concentric Flue We recommend using flue reducer USVK to flue dimension 150/100.
  • Page 25 INSTALLER INFORMATION INSTALLER INFORMATION Vertical Roof Mounted Termination with Angled Elbow for Rigid Concentric Flue Vertical Roof Mounted Termination with Angled Elbow for Rigid Concentric Flue We recommend using flue reducer USVK to flue dimension 150/100.

  • Page 26: Installing Remote Control Electronic Ignition System Gv60

    INSTALLER INFORMATION INSTALLER INFORMATION Installing the controls Installing the controls Electronic Ignition System RCE GV60) Electronic Ignition System RCE GV60) This requires no external electrical power to This requires no external electrical power to operate. The receiver unit has only one lead. This operate.

  • Page 27: Arranging The Ceramic Fire-Bed

    INSTALLER INFORMATION Log Arrangements - Lucius 140 Only the ceramics supplied with this appliance are to be used. The ceramics must be laid only as shown on this page. Replacement parts are available from your dealer, but should only be installed by a quali- fied installation engineer.
  • Page 28 INSTALLER INFORMATION...
  • Page 29 INSTALLER INFORMATION Please make sure that pilot area and second pilot couple area are completely free of any ceramic materials. Finally check if the cross lighting of pilot flame to main burner is correct before the glass is being placed!

  • Page 30: Gravel Arrangements

    Gravel Arrangements / Blackstones / Commissioning the appliance Brilliants INSTALLER INFORMATION Ensure that the Grate , is sitting firmly in the base A soundness test MUST be made before the of the fire box, with the long slot in the centre of installed stove is left with the customer.

  • Page 31: Installing The Fire

    INSTALLER INFORMATION INSTALLATION TIPS Please read first the general fitting information which one can find on page 4 of this book- let. IMPORTANT INSTALLATION TIPS FALSE CHIMNEY BREAST: The false chimney breast must always be constructed of an non-combustible material; Always ventilate the space above the appliance by means of grills or a comparable alternative with a minimum air supply of 400 cm2;...
  • Page 32 INSTALLER INFORMATION INSTALLER INFORMATION INSTALLER INFORMATION TENTION ! - TRAVEL LOCK NUTS - RED. ! ATTENTION ! - TRAVEL LOCK NUTS - RED. ! ATTENTION ! - TRAVEL LOCK NUTS - RED. re two travel locking nuts (one either side) There are two travel locking nuts (one either side) must be released by one turn each before the appliance is fired.
  • Page 33 INSTALLER INFORMATION INSTALLATION OF THE GLASS WINDOW Remove the window trims left, right and bottom like shown in figure 1, 2, 3 Figure 1 Figure 2 Figure 3 Unscrew the crosshead screws and remove the metal clamps which hold the glass window in place (top and bottom glass window).

  • Page 34: Servicing Instructions

    SERVICING INFORMATION SERVICING INFORMATION Troubleshooting servicing instructions Troubleshooting servicing instructions On the next pages you will find remedies for The following outlines only the minimum work that On the next pages you will find remedies for The following outlines only the minimum work problems which may accur when using fires should be performed on an annual basis.

  • Page 35: Troubleshooting

    TROUBLE SHOOTING "Problem” "Possible cause” "Remedy” A. No transmission 1. The (new) communication code 1. Hold down the reset button of the between receiver and remote control receiver, until you hear a long beep (motor will not run) must still be confirmed. .

  • Page 36: Trouble Shooting

    TROUBLE SHOOTING “Problem” “Possible cause” “Remedy” F. Electronics keep sparking while the 1. Receiver is damaged. 1. Replace the receiver and confirm the code pilot burner is ignited (remedy 1 at A) 1.1 Measure the voltage, using a 1. Thermocouple does not function. G.

  • Page 37: Technical Information

    TECHNICAL INFORMATION Technical drawings Lucius 140 R 1532 1386 1386 1417 1417 1419 1419 1547 1419 1419...
  • Page 38 TECHNICAL INFORMATION Lucius 140 CR 1/3 1532 1386 1417 1419 1547 1419...
  • Page 39 TECHNICAL INFORMATION Lucius 140 CR 2/3 1532 1386 1417 1419 1547 1419...
  • Page 40 TECHNICAL INFORMATION Lucius 140 T 1552 1370 1370 1405 1405 1409 1409 1552 1409 1409...

  • Page 41: Technical Details

    TECHNICAL INFORMATION Countries of Destination The following table gives detail of the Countries that these appliances are approved for use within. The tables following immediately on give the technical characteristics of the appliances. Natural Austria I2H G20@20mbar ü Belgium I2E+ G20/G25@20/25mbar ü...
  • Page 42 TECHNICAL INFORMATION Austria ü I3B/P G30/G31@50mbar Belgium ü I3+ G30/G31@28-30/37mbar CH Switzerland ü I3B/P G30/G31@50mbar, I3+ G30/G31@28-30/37mbar CY Cyprus ü I3B/P G30/G31@30mbar Czech Republic ü I3B/P G30/G31@50mbar, I3+ G30/G31@28-30/37mbar DE Germany ü I3B/P G30/G31@50mbar DK Denmark ü I3B/P G30/G31@30mbar Estonia ü...
  • Page 43 Product: atmospheric gas heating appliance Product: atmospheric gas heating appliance Type: Lucius 140 T, Lucius 140 R, Lucius 140 Cr 1/3, Lucius 140 CR 2/3 Type: Lucius 140 T, Lucius 140 R, Lucius 140 Cr 1/3, Lucius 140 CR 2/3...

  • Page 44: Warranty

    Warranty The warranty for your Element4 appliance will be provided by your supplier. In case of complaints, you must always contact him. Your supplier will contact Element4 if necessary. The factory warranty is valid for 24 months after date of purchase.
