CONCEPT2 DYNAMIC INDOOR ROWER

Assembly Instructions

Step 1. Open the two boxes and remove all the parts. Lay out the parts as shown below and read
through the assembly instructions before beginning assembly.
Flywheel Return Assembly
Shuttle
Channel
2 20-penny nails
Installation
leader tape
(Located in plastic
bag with manuals)
Rear Foot

Parts for Assembly

2 PN 2227 T27 6 lobe drive x
1/2" patched rev. ss
9 PN 2239 T27 6 lobe drive x
3/8" patched rev. ss
11 PN 2228 T27 6 lobe drive
1 6 lobe Driver x 1 3/8" patched rev. ss
Page 2
Foot Carriage
Rail Assembly
Front Leg/Monitor Arm Assembly
012611
Handle
1 Rail Assembly
End Stop w/2 nuts
1 Front Leg End Cap
CONCEPT2.COM
