Concept2 Model E Assembly Instructions

Assembly Instructions
IMPORTANT NOTE:
Use these instructions for
MODEL E assembly.
Serial number
PN 2230
Contents of PN 2953
PN 1233 1"
(2.5 cm)
PN 1253 5/8"
(1.58 cm)
1
(4) 5/8" (1.58 cm)
PN 1253
4
MODEL E
Weight: 65 lb (29 kg)
Dimensions: 8 ft x 2 ft (244 cm x 61 cm)
Space Required for Use: 9 ft x 4 ft (274 cm x 122 cm)
Weight Capacity: 500 lb (227 kg) as tested by Concept2*
*300 lb (135 kg) as tested per European Stationary Fitness
Equipment Testing Standard EN 20957-7
PN 1960 - Gray
PN 2709 - Black
PN 1955 - Gray
PN 1708
PN 2870 - Black
PN 296 - Chain Oil
PN 2953
Assembly Tip
Do not fully tighten screws
until all screws are in place.
MODEL E
MODEL E
MODEL E
Box 1
MODEL E
Box 3
2
3
5
(4) 5/8" (1.58 cm)
PN 1253
Assembly Tip
Do not fully tighten screws
until all screws are in place.
Box 2
PN 1972 - Gray
PN 2793 - Black
PN 1971 - Gray
PN 2717 - Black
PN 1268
PN 1284
3/4"
(1.9 cm)
from step #2
(2) 3/4" (1.9 cm) PN 1201
(1.58 cm)
1116
PN 1060(L)
PN 1059(R)
PN 1937 - Dark Blue
PN 2719 - Black
PM5
PN 1818
*
screws will be
reinstalled in step #5
3/4"
(1.9 cm)
5/8"
