Back Panel - MSI RX480M2 MS-7093 User Manual

MS-7093 M-ATX Mainboard
M ou se
Composite
Keyboard
TV-Out
(for RS480)
M ouse/Keyboard Connector
Pin6 NC
Pin4 VCC
Pin2 NC
IEEE 1394 Port
2 4 6
1 3 5
VGA Port
1
5
15 11
2-10

Back Panel

Parallel
S-Video
VGA Port
(for RS480)
(for RS480)
Pin5
Mouse/KBD Clock
Pin3 GND
Pin1
Mouse/KBD
DATA
PIN SIGNAL
1 PWR
2 GND
3 TPB-
4 TPB+
5 TPA-
6 TPA+
PIN SIGNAL
1 RED
2 GREEN
3 BLUE
4 N/C
5 GND
6 GND
7 GND
8 GND
9 +5V
10 GND
11 N/C
12 SDA
13 Horizontal Sync
14 Vertical Sync
15 SCL
1394 Port
LAN
(Optional)
USB Ports
USB Ports
1 2 3 4
S-Video
Pin3 C-TV
Pin1 GND
RJ-45 LAN Jack
8
10/100 LAN
PIN SIGNAL DESCRIPTION
1 TDP Transmit Differential Pair
2 TDN Transmit Differential Pair
3 RDP Receive Differential Pair
4 NC Not Used
5 NC Not Used
6 RDN Receive Differential Pair
7 NC Not Used
8 NC Not Used
L-In
L-Out
SPDIF-Out
Mic
PIN SIGNAL
1 VCC
2 -Data
3 +Data
4 GND
Pin4 Y-TV
Pin2 GND
1
