BodyCraft GALENA BCG 446 Instruction Manual

Hide thumbs Also See for GALENA BCG 446:
Table of Contents

Advertisement

Quick Links

Download this manual
GALENA STRENGTH TRAINING SYSTEM

INSTRUCTION MANUAL

MODEL BCG 446
QUESTION?
As a quality home gym supplier we are committed to your complete satisfaction. If you have
questions, or find missing or damaged parts, we will guarantee your complete satisfaction through
our authorized dealer service centers or our home office customer service department. Please call
your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained
technicians will provide immediate assistance to you, free of charge.
Bodycraft is a division of Recreation Supply Inc.
P.O. BOX 181
Sunbury, OH 43074
6800

Advertisement

Table of Contents
loading

Related Manuals for BodyCraft GALENA BCG 446

Summary of Contents for BodyCraft GALENA BCG 446

  • Page 1: Instruction Manual

    Please call your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained technicians will provide immediate assistance to you, free of charge.

  • Page 2: Before You Begin

    For your safety and benefit, read this manual and the accompanying literature before using the BODYCRAFT GALENA. Keep this manual for future reference. If you have additional questions, please call your local BODYCRAFT dealer or our customer service department at 800-990-5556 Monday through Friday, 9 a.m.

  • Page 3: Table Of Contents

    PARTS LIST DESCRIPTION DESCRIPTION BASE FRAME PRESS BACK PAD(SMALLER) PEC DEC UPRIGHT PRESS SEAT PAD(LARGER) PRESS UPRIGHT PEC DEC BACK PAD(LARGER) CENTER UPRIGHT PEC DEC SEAT PAD(SMALLER) GUIDE ROD 1-1/4" HAND GRIP(LONGER) STACK SPACER 1-1/4" X 140 MM HAND GRIP WEIGHT PLATE 1"...
  • Page 4 PARTS CHART (10) (12) (14) (13) (15) (16) (19) (18) (21) (22) (20) (24) (29) (30a) (23) (11a) (25) (27a) (28) (17) (26)
  • Page 5 PARTS CHART (31) (32) (33) (34) (35) (36) (37) (38) (39) (40) (41) (42) (49) (95) (50) (64) (65) (66) (67) (68) (69) (57) (56) (58) (62) (93) (59) (60) (61) (63) (43) (44) (54) (45a) (46a) (51) (47a) (53) (48a) (94a) (52)
  • Page 6 PARTS CHART (71) (72) (75) (76) (84) (70) (90) (89) (88) (91) (87) (86) (85) (92) 1" 2" 3" 4" 5" 6" 7" (inch)

  • Page 7: Base Frame

    STEP 1 ASSEMBLE BASE FRAME Attach PEC DEC UPRIGHT(2) to BASE FRAME(1) using two 3/8" HEX HEAD BOLT (78), four 3/8" WASHER(90) and two NYLON NUT(87). Attach PRESS UPRIGHT(3) to BASE FRAME(1) using two 3/8" HEX HEAD BOLT(78), four 3/8"WASHER(90) and two 3/8" NYLON NUT(87). Attach CENTER UPRIGHT(4) to BASE FRAME(1) using three 3/8"...

  • Page 8: Guide Rod(

    STEP 2 ASSEMBLE WEIGHT STACK Insert 1" ID BUSHING(64) into the holes on BASE FRAME(1), insert GUIDE ROD(5) to 1" ID BUSHING(64) then slide STACK SPACER(6) and RUBBER CUSHION(38) onto GUIDE ROD(5). Attach TOP PLATE(8) to SELECTOR ROD(9) using TOP PLATE BOLT(70). Slide WEIGHT PLATES(7) onto GUIDE ROD(5).

  • Page 9: Top Frame

    STEP 3 ASSEMBLE TOP FRAME Insert two 1" ID BUSHINGS(64) into the holes on TOP FRAME(10), then place TOP FRAME(10) down onto GUIDE RODS(5) and CENTER UPRIGHT(4). Attach TOP FRAME(10) to CENTER UPRIGHT(4) using three 3/8" X 3/4" HEX HEAD BOLTS(84) and three 3/8"...

  • Page 10: Pec Dec Pulley Bracket 1

    STEP 4 ASSEMBLE PEC DEC STATION Attach PEC DEC SUPPORT(13) and PEC DEC PULLEY BRACKET(12) to PEC DEC UPRIGHT(2) using two 1/2" X 4" HEX HEAD BOLT(72) and two 1/2" NYLON NUT(86). Insert four 3/4" BUSHINGS(65) into PEC DEC SUPPORT(13). Slide ADJ.

  • Page 11: Pres Arm(

    STEP 5 ASSEMBLE PRESS STATION Insert two 5/8" ID BUSHINGS(66) into TOP FRAME(10). Attach PRESS ARM(20) to TOP FRAME(10) using 5/8" X 7-1/2" HEX HEAD BOLT(71), two 5/8" WASHER(88) and 5/8" NYLON NUT(85). Attach PRESS SEAT FRAME(21) to PRESS UPRIGHT(3) using two 3/8' X 4" HEX HEAD BOLT(76), four 3/8"...
  • Page 12 STEP 6 INSTALL TOP CABLE Assemble cables and pulleys simulltaneously. Insert threaded end of TOP CABLE(45a) into slot in front of TOP FRAME(10), over pulley T1, around pulley T2, T3, T4, T5, down to pulley T6, around pulley T7, down to pulley T8, over pulley T9, T10 and screw into SELECTOR ROD(9).

  • Page 13: Single Pulley Bracket 1

    STEP 7 INSTALL PEC DEC CABLE Loosely attach pulley P2 and P4 and CABLE GUIDE(18) to PEC DEC PULLEY BRACKET(12). Insert one end of PEC DEC CABLE(46a) into receiver on right ADJ CAM(14) as shown and route cable over pulley, behind PEC DEC UPRIGHT(2), over pulley and insert opposite end into receive on left ADJ CAM(14).
  • Page 14 STEP 8 INSTALL LINK CABLE Insert one eyelet end under P3 and hook on the eyelet end on SINGLE PULLEY BRACKET(28). Route cable under and around pulley C2. Hook the opposite eyelet end on triangle plate(welded on TOP FRAME(10)). (47a)

  • Page 15: X 2-1/2" Hex Head Bolt

    STEP 9 INSTALL AB CABLE Insert eyelet end of AB CABLE(94a) into slot in front of PRESS UPRIGHT(3), over pulley A1, A2 down and around pulley A3 up and around pulley A4 down and around pulley A5 up and around A6, then insert the eyelet end into the slot of PEC DEC UPRIGHT(2) and fixed using 3/8"...

  • Page 16: Nylon Nut

    STEP 10 INSTALL LOWER CABLE Insert eyelet end of LOWER CABLE(48a) through the "U" shape bracket of foot rest in front of BASE FRAME(1) and route cable under pulley L1, L2, up and around pulley L3, down and around pulley L4, under pulley L5 then attach the eyelet end under the cam of LEG EXETESION using 3/8"...
  • Page 17 STEP 11 INSTALL ACCESSORIES...

  • Page 18: Washer

    STEP 12 INSTALL WEIGHT STACK GUARDS(optional) Attach WEIGHT STACK GUARD(96) to BASE FRAME(1) and TOP FRAME(10) using 5/16" HEX HEAD BOLT(96a) and 5/16" WASHER(96b).
  • Page 19 Guide Rods(5). Enjoy many years of a Fit Lifestyle. Thank you for purchasing the Bodycraft Galena Home Gym. If You have any questions, please call your local BodyCraft dealer or call our customer service department at 800-990-5556.
