1
Introduction
Rear Panel I/O Ports
• 1 mini-DIN-6 PS/2 mouse port
• 1 mini-DIN-6 PS/2 keyboard port
• 1 DB-25 parallel por t
• 1 DB-9 serial port
• 1 RJ45 LAN port
• 4 USB 2.0 ports
• Mic-in, line-out and line-in jacks
I/O Connectors
• 2 connectors for 4 additional external USB 2.0 ports
• 1 connector for one external serial port
• 1 front audio connector for external line-out and mic-in jacks
• 1 CD-in internal audio connector
• 1 S/PDIF connector for optical cable connection
• 1 IrDA connector
• 2 Serial ATA connectors
• 2 IDE connectors
• 1 floppy connector
• 1 20-pin ATX power connector
• 1 4-pin ATX 12V power connector
• 1 front panel connector
• 2 fan connectors
Expansion Slots
• 1 AGP 8x slot
• 5 PCI slots
PCB
• ATX form factor
• 30.5cm (12.01") x 20cm (7.87")
9
