Model:
13201 — 3,400 RPM, with 13016 Arbor
13202 — 3,400 RPM, with 13017 Arbor
13203 — 3,400 RPM, with 13014 Arbor
13204 — 3,400 RPM, with 13015 Arbor
13205 — 3,400 RPM, with 13071 Arbor
13206 — 4,500 RPM, with 13016 Arbor
13207 — 4,500 RPM, with 13071 Arbor
13220 — 3,400 RPM, Versatility Kit
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools (ANSI B186.1) and any other applicable safety
!
WARNING
codes and regulations. Please refer to Dynabrade's Warning/Safety Operating Instructions for more complete safety information.
01721 Rear Bearing Plate
02649 Bearing
L
3
01089 Throttle Lever
95558 Retaining Ring
Right Hand Threads
01295 Housing
Please Indicate:
Model #, Serial #,and
RPM when ordering
replacement parts.
01477 Valve Stem
95730 O-Ring
01024 O-Ring
01247 Regulator
(includes O-rings)
53181 Adapter
L
T
2
2
53178 Rotor
50767 Pin
01028 Cylinder
Pinion
53192 - 3,400 Rpm
01185 Blades (4) (4 pkg.)
O
53194 - 4,500 Rpm
01017 Pin
01464 Seal
01468 Spring
01472 Tip Valve
See inside for Important Operating, Maintenance and Safety Instructions.
KEY
Oil
Grease
O
G
Loctite/Hernon: L
= Loctite #271,
L
2
L
= Loctite #609, L
= Hernon #940
3
4
Torque: N•m x 8.85 = In. - lbs.
T
T
= 17 N•m, T
= 23 N•m, T
= 28 N•m
2
3
4
53175 Rubber Collar
50767 Pin
53179 Spacer
53174 Bearing
T
2
53171 Front Bearing Plate
L
2
95711 Retaining Ring
94521 Muffler Base
95438 O-Ring
94524 Sintered Muffler
01564 Air Control Ring
Shaded parts represent 94520 Muffler Assembly.
Dynastraight
L
04014 Lock Screw (2)
4
53186 Planetary Housing
T
4
01041 Grease Fitting (2)
G
53180 Planetary Carrier
04026 Bearing (4)
02552 Bearing
53191 Ring Gear
Planetary Gear (2)
53193 - 3,400 Rpm
53195 - 4,500 Rpm
94522 Muffler Cap
94526 Spacer
94525 Felt Muffler
95375 O-Ring
Parts Page Reorder No. PD97•26
Effective March, 1997
Supercedes PD94•06
Air Motor and Machine Parts
02552 Bearing
53182 Gear Shaft (2)
94523 Inlet Adapter
T
L
O
3
4
