IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER

SAFETY NOTICE

If this stove is not properly installed, a
house fire may result. For your safety,
follow the installation instructions. Contact
local building or fire officials about
restrictions and installation inspection
requirements in you area.
TESTED and LISTED to CAN/ULC S627
AND UL 1482
Meets the Environmental Protection
Agency's July 1990 Particulate Emission
Standards
090709-16
INSTALLATION
A N D O P E RAT I N G
INSTRUCTIONS
MODEL
STEP D1
DESIGN-D
STEP.D1
5055.2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STEP D1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pacific energy STEP D1

  • Page 1: Safety Notice

    TESTED and LISTED to CAN/ULC S627 AND UL 1482 Meets the Environmental Protection MODEL Agency's July 1990 Particulate Emission Standards STEP D1 DESIGN-D 090709-16 STEP.D1 5055.2012...
  • Page 2: Table Of Contents

    Contents Safety and Maintenance ..................3 Creosote ....................... 4 Formation and Need for Removal ..................4 Chimney Fires ........................4 In Case of a Chimney Fire ....................4 Avoiding a Chimney Fire ..................... 4 Stove Dimensions ....................5 Minimum Clearance to Combustibles ..............5 Mobile Home Installation ..................
  • Page 3: Safety And Maintenance

    WARNING: ONLY USE MATERIALS SUPPLIED BY MANUFACTURER WHEN DOING MAINTENANCE OR REPLACEMENTS. 4. DOOR GASKETS - The gasket used by Pacific Energy (7/8" medium density fiberglass rope) requires only light pressure to seal. This will prolong seal life. It is important that the door seal be maintained in good condition.
  • Page 4: Creosote

    Creosote In Case of a Chimney Fire Formation and Need for Removal 1. Prepare to evacuate to ensure everyone's safety. Have When wood is burned slowly, it produces tar and other or- a well understood plan of action for evacuation. Have a ganic vapours, which combine with expelled moisture to form place outside where everyone is to meet.
  • Page 5: Stove Dimensions

    Stove Dimensions FIG. #1 Single Wall Connector - Residential Minimum Clearance to Combustibles Double Wall Connector - Residential Alcove: Min. Height 7 1/2' Max. Depth 4' Double Wall Connector - Mobile Home STEP.D1 090709-16...
  • Page 6: Mobile Home Installation

    Assembly Leg Kit 1) Remove the front cover from the leg assembly by remov- Crate Removal ing the two #8 x 1/2" screws located on the left and right sides. 1) Carefully remove wood top and supports. 2) With the unit on its back and the open end of the leg as- 2) Remove plastic cover.
  • Page 7: Listed Chimney And Chimney Connector

    Spark arres- tor rain cap FIG. #2 Chimney The chimney may incorporate 3' (914 mm) Storm collar an offset. To do this safely, all Minimum sections of listed connector, Roof flashing offset elbows and chimney Radiation shield section must be screwed to- gether by at least three sheet metal screws per joint.
  • Page 8: Residential Installation

    with solid fuel that is lined and in good condition and meets local building codes. The chimney flue size should 5. Assemble chimney sections so the finished length be the same as the stove outlet for optimal performance. is resting on the support and protruding through the Reducing or increasing the flue size may adversely affect roof.
  • Page 9: Floor Protector

    Floor Protector Combustion Air The stove may be installed on a combustible floor provided Intake or combustion air must be supplied to the stove noncombustible ember protection is used. in one of two ways. Consult your local building code or This protection must extend as follows: CAN/CSA-B365, Installation Code for Solid-Fuel-Burning Appliances and Equipment before proceeding.
  • Page 10: Operation

    1. Move air control lever to the left-most position (maxi- mum firing rate) and open door. Your PACIFIC ENERGY heater is designed for maximum 2. Place crumpled newspaper in the centre of the heater overall efficiency at a moderate firing rate. Overfiring is and criss-cross with several pieces of dry kindling.
  • Page 11: Restarting After Extended Or Overnight Burns

    If necessary, replace with gasket 3. Inadequate draft may cause backpuffing into the room #139.5 available from your Pacific Energy dealer. Re-install and plugging of the chimney. Smoke leaking into the baffle assembly in reverse order. The two side pieces of room through appliance and chimney connector joints insulation must be tight against the siderails.
  • Page 12: Optional Blower

    Optional Blower FIG. #5 The optional blower kit (kit #WODC.BLOW) is equipped with a three prong power cord and may be installed at any time. Follow installation instructions supplied with the kit. Route power supply cord away from heater. Electrical rating: 115 volts A.C.-1.02 amps. Fan output rating: 125 CFM Blower Installation 1.
  • Page 13: Troubleshooting

    Appendix A Troubleshooting Problem Cause Cure Glass is Dirty 1. Wood is wet - Use dry wood 2. Turning down air control - Do not turn down until or damper too soon a) there is a good bed of coals b) the wood is charred 3.
  • Page 14: Replacement Parts

    12c ..Firebrick - 4" x 4 1/2" x 1 1/4" (1 pc.) ....246 22....Ashlip........... ALIP.5037473MB All parts may be ordered from your nearest Pacific Energy dealer. Contact Pacific Energy for the location of the dealer nearest you. STEP.D1 090709-16...
  • Page 15: Label

    Label STEP.D1 090709-16...
  • Page 16 PACIFIC ENERGY FIREPLACE PRODUCTS LTD. 2975 Allenby Rd., Duncan, BC V9L 6V8 Phone: 250-748-1184 Web site: http://www.pacificenergy.net...
