Operation
LCD Screen
4.3 — Menu Navigation
See Figure 4-3.
Feature
The system returns to the Home screen if the control pad is not used for five minutes. The screen normally
displays a Status message, such as Ready to Run (Auto mode) or Switched to OFF (Off mode), and the
total Hours of Protection. If an active alarm/warning condition occurs, the associated Alarm/Warning mes-
HOME Screen
sage is displayed. To clear the Alarm/Warning message, press OFF on the control pad followed by ENTER.
In the event of multiple Alarms/Warnings, the next message is then displayed. The highest priority alarm is
always displayed first.
Enables the operator to navigate the software using UP ARROW, DOWN ARROW, ENTER and ESCAPE.
The Main Menu can be accessed from any sub menu by consecutively pressing ESCAPE. Each time
MAIN MENU
ESCAPE is pressed, the preceding menu is displayed. The Main Menu is reached when the System,
Date/Time, Battery, and Sub Menus are displayed.
ESCAPE Used to abort a routine or back up to the preceding menu.
ENTER Used to make a selection or save an entry.
UP ARROW Used to move forward or backward from menu to menu or to scroll forward or backward (increment or dec-
DOWN ARROW rement) through available selections.
NOTE: Pressing the control pad illuminates the backlight for 30 seconds. The backlight also illuminates for 30 seconds when-
ever an active Alarm/Warning message is displayed.
20
Green
LED
AUTO
MANUAL
OFF
Figure 4-2. Control Pad and LCD Screen
UP ARROW
Blue Red
LED LED
ESCAPE
Description
System Menus
Navigation
Owner's Manual for Stationary Diesel Generators
ENTER
DOWN ARROW
