5.2 — Access Panels
Access panels are located at both the front and sides of the enclosure.
5.2.1— Removal
Insert key into latch and rotate counterclockwise 1/2 turn. See Figure 5-5.
1.
Raise panel using thumb latch.
2.
5.2.2— Installation
Lower panel into position using thumb latch.
1.
Insert key into latch and rotate clockwise 1/2 turn.
2.
Thumb Latch
Owner's Manual for Stationary Diesel Generators
Figure 5-5. Access Panel Key
Key
Maintenance
29
