Page 2: Safety Statement
Thank you for your purchase of the eRC Rebel 70 Sport Jet. This jet is designed for the intermediate to advanced pilot. A great deal of the aircraft is pre- built and only requires some simple assembly and the programming of your radio equipment to be ready to fly. - Page 3 Before starting, use the contents list to take an inventory and make sure it is complete. If any parts are missing or are not of acceptable quality, contact Hobby Lobby support at 866-512-1444. Contents List Fuselage Nose cone ...
- Page 4 1. This manual will help you assemble your Rebel 70. Let’s start by locating the horizontal stabilizer, two screws and two wooden spacers. 2. Place the horizontal stabilizer on the fuselage and connect the two servo leads to the extensions coming out of the fuselage.
- Page 5 5. Next, locate the vertical stabilizer, rudder pushrod, and 5 small screws. 6. Set the vertical stabilizer in place on top of the horizontal stabilizer. 7. Secure the vertical stabilizer using two screws on each side and one screw at the back.
- Page 6 9. With the pushrod on the servo arm and the servo arm centered, connect the plastic pushrod clevis to the rudder control horn in the outermost hole. Adjust the length of the pushrod by spinning the clevis until the rudder is centered.
- Page 7 13. Use a screwdriver to attach the wing. 14. Locate the nose gear and 4 screws. 15. Feed the servo wire into the fuselage and out through the battery tray area. 16. Fit the nose gear mount into place and use the 4 screws to secure it.
- Page 8 17. Take the two main landing gear struts and push them into the plastic slots on the bottom of the wing. If the landing gear fits loosely, use a pair of pliers to spread the “U” bend out for a tighter friction fit.
- Page 9 21. The servo leads will be located near the back of the battery tray. You may need a small wire with a hook to fish some of the leads out for access. Connect the leads to your receiver per your radio systems instructions.
- Page 10 Preflight 1. Aircraft assembled correctly and ready for flight. 2. All control throws are set per this manual. 3. Transmitter fully charged and on the correct model. 4. Aircraft balances at the recommended CG location. 5. Flight batteries are fully charged and secure. 6.
- Page 11 2008 Official Academy of Model Aeronautics National Model Aircraft Safety Code GENERAL A model aircraft shall be defined as a non-human-carrying device capable of sustained flight in the atmosphere. It shall not exceed limitations established in this code and is intended to be used exclusively for recreational or competition activity.
-
Page 12: Spare Parts List
Hobby Lobby guarantees this kit to be free from defects in both material and workmanship at the date of purchase. This warranty does not cover any component damaged by use or modification. In no event shall Hobby Lobby’s liability exceed the original cost of the purchased kit. Hobby Lobby International, Inc. 5614 Franklin Pike Circle Brentwood, TN 37027 1-866-WE-FLY-RC (1-866-933-5972) www.hobby-lobby.com...
