Installation Prerequisites

• Must have open site (gravity) drain available or
purchase optional drain pump (see Water Supply and
Drain Requirements).
• Must have a grounded, polarized electrical power
supply on a dedicated electrical circuit (only
appliance on circuit). If GFCI (ground fault circuit
interrupter) is required by your local electrical code, it
must be breaker type, not outlet type (see Electrical
Service).
• Must have cold water supply line available at Ice
Machine (see Water Supply and Drain
Requirements).
• Clearance and air temperatures must be met (see

Location of Ice Machine).

• If built into a cabinet, ice machine must be removable
for yearly cleaning procedure.

General

Call Manitowoc Foodservice at (800) 235-9698 for the
name of a local company capable of installation and
start-up services.
!
Proper installation requires connection to the water
supply, a drain and a dedicated electrical circuit.
These connections are the responsibilities of the
owner/operator. Improper connections can result in
personal injury, substantial property damage and
erratic machine operation. If you are unsure of your
ability to safely connect the ice machine, consult
qualified professionals
Foodservice.
Important
Failure to follow these installation guidelines may
affect warranty coverage.
Part Number 040001361 05/10

Installation Instructions

Warning
or contact Manitowoc
Section 2
Location of Ice Machine
The location selected for the ice machine must meet the
following criteria. If any of these criteria are not met,
select another location.
• The ice machine may be built into a cabinet, however
the location must allow removal of the ice machine
for cleaning and servicing. Service diagnostics are
performed from the top of the ice machine.
• The location must be free of airborne and other
contaminants.
• The air temperature must be at least 50°F (10°C), but
must not exceed 110°F (43°C).
• The location must not be near heat-generating
equipment.
• The location must not obstruct air flow through the
condenser (airflow is in and out the front of the ice
machine).
• The location must allow enough clearance for water,
drain and electrical connections at the rear of the ice
machine.
• The ice machine may be installed outside.
The ice machine must be protected if it will be
subjected to ambient temperatures below 32°F
(0°C). Component failure caused by exposure to
freezing temperatures is not covered by the
warranty.

CLEARANCES

Top/Sides
Back
Front
*The ice machine may be built into a cabinet. There is no minimum clearance
requirement for the top or sides of the ice machine. The listed values are
recommended for efficient operation and servicing only.
! Caution
5" (12.7 cm)*
5" (12.7 cm)
24" (60.9 cm)
5
