Luxman C-1000f Owner's Manual page 18

Now you are ready to take advantage of Luxman's long standing tradition of excellence in the C-
1000f Control Amplifier. The C-1000f's reproduction is sonically transparent and absolutely accu-
rate.
CD, DVD, SACD, TUNER
a twin RCA-to-RCA lead to connect the CD player's left and right 'Audio Outputs' to this input.
The C-1000f only accepts analogue signals from your CD player.
PHONO (Record Player)
You will need to connect the output from your phono cartridge to an outboard phono stage (such as
the E-1, E-600 or EQ-88 + MT-88 + OPEQ-88), then connect the output of the phono stage to an
input on the C-600f. If you hear a lot of hum, you will most likely need to run a copper cable
between the record player's chassis to the phono stage and possibly to the SIGNAL GROUND
(No.21).
Balanced Connection Pin Out
Please refer to Balanced Output Phase Invert
the phase for the output.
1. Ground
2. Cold –
3. Hot +
1. Ground
2. Hot +
3. Cold -
In the USA, most balanced products use Pin 2 = Hot or +. So Luxman's Japanese products
use the reverse mode from the American POV. The output phase can be adjusted from the
remote control.
NOTE: Always turn the amplifier off before connecting or disconnecting cables from the Output
sockets.
connection
Input for a CD or other line-level signal source. Use
on Page 10 for details on how to change
;
