FOR ARCHITECTS & DESIGNERS
TCWS54
SERIES D2
100001172-50 TCWS54D2
Dimensions | Clearances | Venting
IMPORTANT
This booklet is intended as a basic specification
guide for architects, designers and builders.
Please refer to the Instruction Manual supplied
with the fireplace for detailed information regarding
installation and operation.
Product installation manuals can also be viewed at:
www.townandcountryfireplaces.com
021118-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D2 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces D2 Series

Summary of Contents for Town & Country Fireplaces D2 Series

  • Page 1 FOR ARCHITECTS & DESIGNERS TCWS54 Dimensions | Clearances | Venting SERIES D2 IMPORTANT This booklet is intended as a basic specification guide for architects, designers and builders. Please refer to the Instruction Manual supplied with the fireplace for detailed information regarding installation and operation.

  • Page 2: Fireplace Dimensions

    Fireplace Dimensions TCWS54.D2 Cad Drawing Available at www.townandcountry replaces.com Examples of Common Locations FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 100001172-50 TCWS54D2 021118-12...

  • Page 3: Mantel Clearance Chart

    Mantel Clearance Chart NON-COMBUSTIBLE ZONE. COMBUSTIBLE FRAMING AND DO NOT INSTALL ANY COMBUSTIBLE FINISH WALL ABOVE STANDOFFS MATERIAL, ELECTRICAL WIRING OR GAS STEEL FRAMING PLUMBING IN THIS AREA. MAY USE COMBUSTIBLE STANDOFF FACING MATERIAL IN THIS MANTEL CLEARANCE AREA CHART NON-COMBUSTBLE * MANTEL CLEARANCE FINISH MATERIAL...

  • Page 4: Non-Combustible Board

    Steel Stud Framing Kit Dimensions Kit Framing kit is supplied Non-combustible with Fireplace Board Detail All other framing can be done with conventional lumber NON-COMBUSTIBLE BOARD 74 3/4" 12” 9 5/8” 12” 55 1/16" NON-COMBUSTIBLE materials must extend 12” above and 9 5/8” to the sides of the framing edges.

  • Page 5: Hearth Extension

    Proflame 2 Control System Town and Country D2 Series fireplaces use the SIT Proflame 2 control system. This includes an elegant hand-held remote control transmitter with an easy to read LCD display. The fireplace also comes with a wall-mounted control...
  • Page 6 Direct Vent Roof Installation FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 100001172-50 TCWS54D2 021118-12...

  • Page 7: Roof Termination Venting Chart

    Roof Termination Venting Chart MAX. CAUTION: Under no condition should combustible material be closer than 1 3/4 inches from any part of the vent pipe. Only 45º elbows can be used in this vent system. Maximum number of elbows is 2. 4' MAX.
  • Page 8 Direct Vent Terminal Clearance Minimum clearances to the vent terminal must be maintained as shown (See illustration to right & below). Measure VENT TERMINAL MINIMUM CLEARANCES clearances to the nearest edge of termination hood. TO ADJACENT STRUCTURES (See pitch table below). NOTE: Vent terminal must not be recessed 36"...
  • Page 9 Optional Power Vent Reach almost any room or commercial setting. Up to 66 feet Optional Power Venting allows runs up to 110’ to of vertical run an outside wall or roof surface (maximum 66’ of vertical run). Vent horizontally or vertically with up to six 90-degree elbows, including runs up to 3’...
  • Page 10 FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 100001172-50 TCWS54D2 021118-12...
  • Page 11 FOR REFERENCE ONLY. CONSULT MANUAL BEFORE INSTALLATION 100001172-50 TCWS54D2 021118-12...
  • Page 12 © 2018 Copyright Pacific Energy Fireplace Products LTD Reproduction, adaptation, or translation without prior written permission is prohibited, except as allowed under the copyright laws. For personal service pertaining to specific projects, contact: Town & Country Architect Resource Planner architects@townandcountryfireplaces.com www.townandcountryfireplaces.com Phone: (250) 748-1184 2975 Allenby Road, Duncan, BC Canada V9L 6V8...
