Seat Removal

Refer to Safety Precautions on page 91.
The front seat must be removed for spark plug maintenance, main
fuse maintenance, battery maintenance, to check the engine oil
level, to add engine oil, to change the engine oil filter, and to access
the tool kit.
Removal
1. Open the doors (page 36).
2. Pull the front of the front seat upward then slide it slightly
forward.
grommets
front seat
prongs
Installation
Insert the hooks into the frame and the prongs into the grommets of
the front seat.
108 Servicing Your Honda
hooks
