1.3 PRODUCT SPECIFICATIONS

ELECTRICAL SPECIFICATIONS

Model
Power
No.
Rating
MCP 6001 6KVA
4.2KW
MCP10001
10KVA
7KW
INPUT
Voltage:
Phase:
Frequency:
Power factor:
OUTPUT
Output voltage regulation:
Power factor:
Frequency regulation:
Distortion:
Overload Capacity:
Load Crest Ratio

OPERATING ENVIRONMENT

Ambient temperature:
Operation humidity:
Altitude:
Storage temperature:
MECHANICAL SPECIFICATIONS
Model Number Dimensions
H x W x D
31.5 x 10.25 x 23.25 in.
MCP 6001
80 x 26 x 59 cm
MCP10001 38 x 13.5 x 26.5 in.
96.5 x 34.3 x 67.3 cm
Freq. Input
(Hz)
Voltage Current
50/60 33A
170-276
VAC
50/60 170-276 56A
VAC
As listed
single phase with ground
50/60Hz +/- 5%, auto selection
>/= 0.97
+/-3%
0.7 lag to unity
+/-5%, phase lock to input under normal conditions, +/-0.5% of nominal frequency,
under normal operation or battery mode.
+/-3.0% THD at full linear load, +/-7% THD at full non-linear load
>130% +/-10% for 200 ms, 105% for 10 second
3:1 maximum
10 to 40 degrees Centigrade
20% to 90%, non-condensing
less than 1500M above sea level
-15 to 40º C
Weight
Net (Shipping)
296(311.6)lb.
134.3(141.3)Kg
519.6(552.2)lb.
235.7(250.5)Kg
Voltage
120, 120/120, 208,
120/208, 240, 120/240V
120, 120/120, 208,
120/208, 240, 120/240V
Page 2
Output
Current
50, 25/25, 28.8,
25/28.8, 25, 25/25A
83.3, 41.7/41.7, 48.1,
41.7/48.1, 41.7, 41.7/41.7A
