Minuteman Smart Up Series User Manual

Smart up series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Smart Up Series
Uninterruptible Power Supply
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Smart Up Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Minuteman Smart Up Series

Summary of Contents for Minuteman Smart Up Series

  • Page 1 Smart Up Series Uninterruptible Power Supply User’s Manual...
  • Page 3 Smart Up Series User’s Manual Introduction Controls and Indicators Installation Operation Troubleshooting Replacing the Battery Obtaining Service Specifications Limited Warranty ã Copyright Para Systems, Inc., 1999...
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS ! Please read the manual before installing your Smart Up Series UPS as it provides the information that should be followed during installation and main- tenance of the UPS and batteries allowing you to correctly set up your sys- tem for the maximum safety and performance.

  • Page 5: Receiving Inspection

    Receiving Inspection After removing your Minuteman UPS from its carton, it should be inspected for damage that may have occurred in shipping. Immediately notify the carrier and place of purchase if any damage is found. Warranty claims for damage caused by the carrier will not be honored.

  • Page 6: Front Panel

    FRONT PANEL On/Test/Alarm Silence On Battery Buck Normal Boost Overload Replace Battery Load Battery Press and release the On/Test/Alarm Silence button to turn on, test or silence the alarm. Press and release the OFF button to turn the UPS OFF. The Buck LED illuminates when the UPS is correcting for a high utility line voltage.
  • Page 7 Minuteman Smart Up Rear Panel Site Wiring Fault Output Receptacles Connector Input Circuit Breaker Accessory Slot Surge Only Receptacle Option Slot Input Power MSU 700 Site Wiring Fault DB9 Connector Input Circuit Breaker Option Slots Accessory Slot Output Receptacles Surge Only Receptacle Input Power MSU 1000 &1400...

  • Page 8: Rear Panel

    DB9 CONNECTOR Minuteman Power Management software and interface cable kits are used with this port (software and cables are optional and available from Minuteman). Use only Minuteman or Minuteman approved interface cables with these UPS’s. Connect the interface cable to the DB9 connector on the rear of the UPS.
  • Page 9 QUALIFIED ELECTRICIAN CORRECT THE PROBLEM. CHARGING THE BATTERIES The Smart Up Series UPS’s will charge the batteries whenever the unit is connected to an AC source. It is recommended that the UPS batteries be charged for a minimum of 4 hours before use.

  • Page 10: Off Switch

    OFF SWITCH Press and release this switch to turn the UPS OFF. The UPS will continue to charge the batteries whenever it is plugged in and the utility line is present. LED STATUS & ALARMS LOAD LEVEL DISPLAY The 4-LED load percentage display shows the power level (20%, 40%, 60%, 80%) drawn by the loads which are connected to THE BATTERY-SUPPLIED OUTLETS on the UPS.

  • Page 11: Battery Replace

    OVERLOAD If an overload occurs, the OVERLOAD LED will light and an uninterrupted alarm will be heard. Under this condition, check the load connected to the UPS. BUCK/BOOST If the UPS detects a high utility voltage, the function of the buck is to automatically reduce the output voltage to its nominal level.

  • Page 12: Battery Low

    BATTERY LOW This function is to inform user of the remaining power capacity of the batteries. When the batteries reach a low capacity condition, the UPS alarm will beep once every second, and the LED on the 25% level will flash. OVER TEMPERATURE When temperature inside the UPS is too high, the LED of Buck, Boost, Normal and On Battery will light, the alarm will sound continuously, and after a minute the UPS will stop...

  • Page 13: Troubleshooting Chart

    TROUBLESHOOTING CHART Possible Cause Problem Solution ON/TEST button is not Press the ON/TEST button to turn pushed. on the UPS. (Refer to Section 4 to No alarm, No LED turn on the UPS). The rear panel circuit indication (UPS is not Reduce some loads connected to turned on).

  • Page 14: Replacing The Battery

    REPLACING THE BATTERY The Smart Up Series UPS has easy-to-replace hot-swappable batteries. Please read the following warning statements before attempting to service the batteries. WARNING! THIS UNINTERRUPTIBLE POWER SOURCE CONTAINS POTENTIALLY HAZARDOUS VOLTAGES. DO NOT ATTEMPT TO DISAS- SEMBLE THE UNIT BEYOND BATTERY REPLACEMENT PROCEDURES BELOW.

  • Page 15: Battery Replacement Procedure

    BATTERY REPLACEMENT PROCEDURE PLEASE READ THE PREVIOUS “CAUTIONS” SECTION BEFORE ATTEMPTING TO REPLACE THE BATTERIES Battery replacement is a safe procedure when cautions and instructions are carefully followed. You may leave the UPS and the loads on for the following procedure. Hold the top of the front panel, tilt it out and pull it carefully away from the chassis.
  • Page 16 Disconnect the battery: For 700VA and 1000VA models, disconnect the batteries and UPS by loosening the connectors. For 1400VA model, disconnect the batteries and UPS by pulling apart the two couplers that are connected together. Connect the new battery: For 700VA and 1000VA models, connect positive (+) connectors (RED- RED) and negative (-) connectors (BLACK-BLACK) together.
  • Page 17 Call your dealer for assistance. If you cannot reach your dealer or if he cannot resolve the problem, call or FAX Minuteman Technical Support at the following numbers: Voice phone (972) 446-7363, FAX line (972) 446-9011, e-mail: support@minuteman-ups.com. Please have the following information available BEFORE calling technical support.
  • Page 18 NOTE: 230VAC Specs Shown In ( ) MSU 700 MSU 1000 MSU 1400 Acceptable input Voltage 0-145 (0-288) VAC Input Voltage (on-line operation) 91-145 (174-288) VAC Output Voltage (on-line operation) 103-131 (200-253) VAC Nominal input frequency 50 or 60 Hz auto-sensing Input protection Manual reset circuit breaker Frequency limits (on-battery...
  • Page 19 LIMITED PRODUCT WARRANTY Para Systems Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three years from the date of original purchase by the end user. For equipment sites within the United States and Canada, this warranty covers repair or replacement of defective equipment at the discretion of Para Systems.
  • Page 20 Notes:...
  • Page 21 Notes:...
  • Page 22 Notes:...
  • Page 24 Para Systems, Inc. 1455 LeMay Dr. Carrollton, TX 75007 Phone: (972) 446-7363 Fax: (972) 446-9011 QuickFax Info System: 1-800-263-3933 Internet: www.minuteman-ups.com P/N: 34000161...

This manual is also suitable for:

Smart up msu 700Smart up msu 1000Smart up msu 1400
