GAS FIRED POWER FLUE COOKER
WITH AIMS
Installation
Instructions
REMEMBER: when replacing a part on this appliance, use only spare parts that
you can be assured conform to the safety and performance specification that we
require. Do not use reconditioned or copy parts that have not been clearly
authorised by AGA.
PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING THIS APPLIANCE
For use in GB and IE
03/10 EINS 515926

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GC3 (PF) and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGA GC3 (PF)

Summary of Contents for AGA GC3 (PF)

  • Page 1 Do not use reconditioned or copy parts that have not been clearly authorised by AGA. PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING THIS APPLIANCE For use in GB and IE...

  • Page 2: Table Of Contents

    SECTION PAGE HEALTH & SAFETY INSTALLATION LOCATION TECHNICAL DATA - AGA GC3 P/F 5 & 7 TECHNICAL DATA - AGA GC3 P/F WITH MODULE 6 & 7 FLUE SYSTEM 8 - 11 AIR SUPPLY INSTALLATION PIPES BAKING OVEN BAFFLE PLATE...

  • Page 3: Health & Safety

    Children should be supervised to ensure that they do not play with the appliance. IMPORTANT NOTICE: PLEASE READ THE ACCOMPANYING WARRANTY. Any alteration that is not approved by AGA could invalidate the approval of the appliance, operation of the warranty and could affect your statutory rights.

  • Page 4: Installation

    Permission may need to be obtained, which should be applied for separately. The complete range of AGA cookers are suitable for Natural or Propane gases only and cannot be used on any other gas. (IMPORTANT: See data plate which is situated on burner housing panel behind top left door).

  • Page 5: Technical Data - Aga Gc3 P/F 5

    TECHNICAL DATA - AGA GC3 (POWER FLUE) Fig. 1 DESN 513391B mm 987 967 851 679 41 1330 756 1125 698 116 48 65 375 595 667 PLEASE NOTE: SIDE CLEARANCE DIMENSION R IS ALSO REQUIRED ON THE LH SIDE FOR THE BAKING OVEN DOOR.

  • Page 6: Technical Data - Aga Gc3 P/F With Module 6

    TECHNICAL DATA - AGA GC3 (POWER FLUE) WITH MODULE DESN 513392 B Fig. 1A N** O** mm 1598 889 851 679 60 967 1330 756 1125 685 116 698 1533 800 48 65 375 500 595 960 * GAS SUPPLY PIPE FOR GC3 (PF) WHEN FITTED TO MODULE...
  • Page 7 TECHNICAL DATA (CONTINUED) AGA GC3 P/F COOKER (AIMS) NATURAL G20 MAXIMUM HEAT INPUT 4.4 kW Thermostat Bypass Size Main Burner Injector Pilot Injector 7218 Inlet Pressure (EU COUNTRIES ONLY) 20mbar Burner Pressure 10 mbar (4” w.g.) PROPANE G31 MAXIMUM HEAT INPUT...

  • Page 8: Flue System

    FLUE SYSTEM FLUE SYSTEM SEE FIGS. 2, 3, 4 & 5 The flue system must be installed in accordance with the regulations in force. Products of combustion discharge is by a fan powered flue pipe of 50mm diameter which can reach up to 6 metres in length through a maximum of 6 x 90Þ...
  • Page 9 M i n i m u m s i t i n g d i m e n s i o n s f o r F l u e t e r m i n a l s Position Minimum Spacing Directly below an openable window, air vent, or an other ventilation opening...
  • Page 10 Fig. 4 DESN 511190...
  • Page 11 DOWNWARD RUNS UP TO 300mm BELOW THE APPLIANCE ARE ALLOWED, PROVIDED ONLY ONE BEND IS USED. DOWNWARD RUNS USING 2 BENDS ARE NOT ALLOWED. Fig. 5 DESN 511191...

  • Page 12: Air Supply

    BAKING OVEN BAFFLE PLATE A metal plate (with square holes) which is provided in the AGA pack MUST be positioned on the top runners of the Baking Oven. Slide in the plate fully, until it makes contact with the back of the oven.

  • Page 13: Burner Assembly - Aims Control

    BURNER ASSEMBLY - AIMS CONTROL A - ON/OFF CONTROL KNOB B - TEMPERATURE CONTROL KNOB C - GAS COCK D - INLET PRESSURE TEST NIPPLE E - BURNER PRESSURE TEST NIPPLE F - VIEWING WINDOW G - AIMS CONTROL KNOB H - SOLENOID N/C (NORMALLY CLOSED) I - SOLENOID N/O (NORMALLY OPEN) Fig.

  • Page 14: Assembly Of Burner - Aims Control

    ASSEMBLY OF BURNER - AIMS CONTROLS SEE FIG. 6 NOTE: Prior to assembly remove controls mounting bracket from burner housing. 1. Fit gas cock to inlet supply pipe. 2. Fit burner assembly to burner housing. 3. Fix AIMS control mounting bracket to burner housing. 4.

  • Page 15: To Test The Aims Control Handset

    Fig. 9 DESN 515480 TO TEST THE AIMS CONTROL HANDSET Fig. 10 DESN 515481 Handset to Base Unit Signal Check/Language Selection Complete the following procedure to check the handset is communicating with the base unit and to select language option. 1.

  • Page 16: Commissioning

    CAUTION: BEFORE LIGHTING: ENSURE KNOB (A) IS IN THE OFF POSITION (SEE FIG. 12). ALSO ENSURE GAS SUPPLY TO COOKER IS ON, AND THE GAS SERVICE COCK (C) IS IN THE ON POSITION (SEE FIG. 6), AND THE ELECTRICAL SUPPLY TO THE AGA IS SWITCHED ON.

  • Page 17: Instructions

    Hand these and the operating instructions to the User for retention and instruct in the safe operation of the appliance. Finally advise the User that, for continued efficient and safe operation of the appliance it is important that adequate servicing is carried out at regular intervals recommended by the AGA Distributor or local Gas Region.

  • Page 18: Burner Controls

    BURNER CONTROLS Fig. 11 Fig. 12 Fig. 13 Fig. 15 Fig. 14 Fig. 16 Fig. 17 DESN 513393...
  • Page 20 For further advice or information contact your local AGA Specialist With AGA’s policy of continuous product improvement, the Company reserves the right to change specifications and make modifications to the appliance described and illustrated at any time Manufactured by Station Road...
