magicolor 2210
®
User's Guide
1800669-001B
EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the magicolor 2210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Minolta magicolor 2210

Summary of Contents for Minolta magicolor 2210

  • Page 1 2210 ® User’s Guide 1800669-001B EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 2: Registering The Printer

    The following are registered trademarks of MINOLTA-QMS, Inc.: QMS, the MINOLTA- QMS logo, Crown, CrownNet, and magicolor. Minolta is a trademark of Minolta Co., Ltd. Other product names mentioned in this guide may also be trademarks or registered trademarks of their respective owners.
  • Page 3 Contents 4 5HSODFLQJ &RQVXPDEOHV 1111111111111111111111111111111111111111111111111111111111111111111111111111111111 8 &RQVXPDEOH /LIH ([SHFWDQFLHV 5HSODFLQJ &RQVXPDEOHV 9 2UGHULQJ &RQVXPDEOHV 5HSODFLQJ 7RQHU &DUWULGJHV 7RQHU &DUWULGJH /LIH 7RQHU &DUWULGJH +DQGOLQJ 7RQHU &DUWULGJH 5HSODFHPHQW 5HILOOHG 7RQHU &DUWULGJHV 5HSODFLQJ WKH 23& 'UXP .LW :DVWH 7RQHU 3DFN/ 23& 'UXP &DUWULGJH/ DQG /DVHU /HQV &RYHU 5HPRYLQJ WKH 8VHG :DVWH 7RQHU 3DFN 5HPRYLQJ WKH 8VHG 23&...

  • Page 4: Table Of Contents

    Autoduplexing Upper and Optional Media Trays Multipurpose Tray Printing Envelopes from the Multipurpose Tray Printing Area Media Storage 46 3 Maintaining the Printer ...47 Maintaining the Printer 48 Cleaning 50 Outside the Printer Inside the Printer 4 Troubleshooting ...51 Introduction 52...
  • Page 5 Installing a Lower Feeder Unit (LFU) Media Trays Installation Printer Stand/Cabinet 135 SC-210 Convenience Copier 135 Time-of-Day Clock 6 Color Printing ... 139 Introduction 140 Color Management and Control MINOLTA-QMS QCOLOR Technology Further Information Contents EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 6 7 Repacking the Printer ...143 Storing the Printer 144 Relocating Your Printer 144 Repacking the Printer 145 What's Involved? Remove the Cables Remove the Fuser Oil Roller 146 Remove the Toner Cartridges 146 Remove the Waste Toner Pack 147 Remove OPC Drum Cartridge 147...

  • Page 7: Ednord - Istedgade 37A - 9000 Aalborg - Telefon

    Replacing Consumables EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 8: Consumable Life Expectancies

    Consumable Life Expectancies The stated life expectancy of each consumable is based on printing under specific operating conditions, such as media type, number of color planes, page size, and page coverage (@ normal 5% coverage of letter/A4-size media). The actual life expectancy will vary depending on these and other printing variables, including continuous or intermittent printing, ambient tem- perature, and humidity.
  • Page 9 (Operator Control/Consumables/Print Statistics). The numbers on the startup page refer to number of sheets/faces printed during the lifetime of the printer. The numbers in CrownView and on the consumables statistics page refer to the number of sheets/faces printed to date during the current consumables tracking period (Administration/Con- sumables/Start Period menu).

  • Page 10: Ordering Consumables

    Ordering Consumables Choosing the right consumables for your magicolor 2210 printer not only increases its reliability and performance, but also minimizes the risk of damage. For example, only MINOLTA-QMS toner cartridges are designed to meet the exact specifications of your MINOLTA-QMS printer, giving maximum performance, efficiency, and long life.

  • Page 11: Toner Cartridge Handling

    (as you do for a new cartridge) five or six times. Then reinstall the cartridge. The printer, approximately 100 pages after detecting that toner in a cartridge is low, displays X TONER EMPTY in the message window ( X indicates the toner color).

  • Page 12: Toner Cartridge Replacement

    Open the printer’s front cover. Attention Be careful not to spill toner on the inside of the printer’s front cover. Toner will fall from there into the upper media tray. If toner does fall onto the open cover, immediately wipe it with a dry, lint-free soft cotton cloth or swabs.

  • Page 13: Replacing Toner Cartridges

    WARNING! Dispose of the used toner cartridge according to your local regulations. Do not dispose of it by burning. ACHTUNG! Entsorgen Sie alte Tonerkassetten keinesfalls durch Verbrennen, sondern ordnungsgemäß entsprechend den lokalen Bestimmungen. Remove the new toner cartridge from its shipping carton. Distribute the toner inside the cartridge.

  • Page 14: Refilled Toner Cartridges

    Refilled toner cartridges may produce variations in toner quality and reliability and can reduce the print quality of your documents. Any damage to the printer or quality problems caused by a refilled toner cartridge use will void your warranty. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 „...

  • Page 15: Removing The Used Waste Toner Pack

    Installing the new waste toner pack Removing the Used Waste Toner Pack When you replace the OPC drum cartridge, the printer automatically recov- ers. However, the replaced waste toner pack consumables monitoring system must be manually reset through control panel (Operator Control/ Consumables/Items Replaced) menu.
  • Page 16 Carefully remove the waste toner pack using the handle. Keep the waste toner pack upright so the toner does not spill. Turn the two caps labeled “A” counterclockwise and remove them. Twist the two “A” caps c onto the two “A” holes d. Turn the caps clockwise to secure them.

  • Page 17: Removing The Used Opc Drum Cartridge

    Removing the Used OPC Drum Cartridge When the OPC drum is worn out, the message REPLACE DRUM appears. The printer will not print until the drum kit is replaced. When you replace the OPC drum cartridge after a DRUM LOW or REPLACE DRUM message displays in the message window, the printer automatically recovers.
  • Page 18 Hold the OPC drum cartridge handle and carefully pull it out about 8 inches (20 cm). Support the bottom of the drum with your hand, then carefully pull the cartridge toward you and remove it. 5 " Dispose of it prop- erly according to your local regulations.

  • Page 19: Installing The New Opc Drum Cartridge

    Attention If the laser lens cover is not properly installed, serious damage to the printer could result. Continue with replacing the OPC drum cartridge. Installing the New OPC Drum Cartridge Remove the new OPC drum cartridge from its shipping box.
  • Page 20 Carefully push the OPC drum cartridge in. Attention The cartridge should slide easily into the printer. Don’t force it. Press on the front handle of the OPC drum cartridge with one hand and hold the front handle of the OPC protective cover with the other hand.

  • Page 21: Installing The New Waste Toner Pack

    Zeit abühlen, bevor Sie diese berühren. When the fuser is worn out, the message “REPLACE FUSER UNIT” appears and the printer does not print. Replace the fuser kit. After the new fuser kit is installed, printing automatically resumes. The fuser kit includes the two items below. When replacing the fuser unit, replace the transfer roller as well.
  • Page 22 „ Fuser unit „ Transfer roller unit Replacing the Fuser Unit Open the printer’s top cover. Rotate the two fuser oil roller lock levers to release the fuser oil roller. Remove the fuser oil roller. Hold it by the green handle only.

  • Page 23: Replacing The Fuser Unit And Transfer Roller Kit

    Place the fuser oil roller on a table or level surface. Attention Since the fuser oil roller removed here is to be installed in the new fuser unit, handle it with care. If you set the fuser oil roller on the table do it as shown in the illustration.
  • Page 24 Holding the fuser unit handles, lift up the unit. 5 " Dispose of it properly according to your local regulations. Remove the new fuser from its shipping box. Replacing the Fuser Unit and Transfer Roller Kit EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 25 Carefully lower the new fuser unit so that the two pins in the fuser unit installation section go into the two installation holes in the fuser unit. Press in on the fuser unit release levers c and rotate them downward d. This secures the fuser unit.

  • Page 26: Replacing The Transfer Roller Unit

    (removed in step 4). Rotate the two oil roller levers to lock the oil roller into place. Close the printer’s top cover. Check the release button to make sure the top cover is properly closed. Replacing the Transfer Roller Unit 5 "...
  • Page 27 Holding the two transfer roller unit handles, remove the trans- fer roller unit. 5 " Dispose of it properly according to your local regulations. Remove the new transfer roller unit from the fuser kit box. Attention Do not touch the surface of the transfer roller unit.

  • Page 28: Replacing The Fuser Oil Roller

    Zeit abühlen, bevor Sie diese berühren. When the fuser oil roller is worn out, the message “REPLACE OIL ROLLER” appears and the printer does not print. Replace the fuser oil roller. After the new roller is installed, printing automatically resumes (if you have not turned off the printer).
  • Page 29 Remove the new fuser oil roller from its shipping box. Attention If you set the new fuser oil roller on a table, do it as shown in the illustration. Do not allow the roller surface to contact the table or get dirty. This could lower image quality.

  • Page 30: Replacing The Transfer Belt

    Replacing the Transfer Belt When the transfer belt is at the end of its life, the message “REPLACE TRANSFER BELT” appears, and the printer does not print. Replace the trans- fer belt. After the new transfer belt is installed, printing automatically resumes (if you have not turned off the printer).
  • Page 31 Attention The OPC drum is extremely sensitive to bright light and direct sunlight. Always put it in its protective bag until you’re ready to reinstall it. Any exposure to light should be avoided, or permanent damage could result. Also, handle the cartridge carefully by its sides so you don’t touch the surface (the green part) of the drum.
  • Page 32 Remove the new transfer belt from its packaging and insert it into the printer. Press on the transfer belt front handle with one hand, take the handle of the transfer belt fixture with your other hand, and pull the fixture straight toward you.
  • Page 33 Reinstall the OPC drum cartridge. Close the transfer belt lock lever. Check to make sure the laser lens cover is firmly seated. Reinstall the waste toner pack. Close the front cover. Replacing the Transfer Belt EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 34 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 35: Using Media

    Using Media EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 36: Introduction

    Before purchasing a large quantity of special media, do a trial printing with the same media and check print quality. Check our web site www.minolta-qms.com for a list of current approved media. Attention Do not use the media types listed below. These could cause poor print quality, media jams, or damage to the printer.

  • Page 37: Media Types

    150 sheets of 20 lb bond (75 g/m²) paper; capacity for other weights varies accordingly. Simplex—Face up; Duplex—Face down Simplex—Face down; Duplex—Face up Up to 500 sheets Up to 150 sheets Face up—top of page toward the right Face down—top of page toward the printer side...

  • Page 38: Thick Stock

    Orientation Face down Type For information about thick stock media recommended for your printer, go to www.minolta-qms.com/support, then click on Answer Base, or contact Technical Support. See the Service & Support Guide for a complete listing of support telephone numbers.

  • Page 39: Envelopes

    Envelopes Formatting Your printer receives the instructions to print on envelopes from your application. „ Print on the front side only. Some parts of the envelope consist of three layers of paper—the front, back, and flap. Anything printed in these layered regions may be lost or faded.

  • Page 40: Postcards

    „ Avoid using labels with exposed adhesive; it may stick to the Notes transfer belt or the fuser roller, causing labels to peel off and media jams to occur. „ Adhesive label stock is supported only in letter or A4 sheets. „...
  • Page 41 „ Keep the media path clean. Transparencies are especially sen- sitive to a dirty media path. If there are shadows on either the top or the bottom of the sheets, see “Cleaning the Printer Inte- rior” in the Maintenance Guide.

  • Page 42: Loading Media

    Always load the media short edge first. Attention Do not mix media of different sizes, types, or weights, as this will cause printer jamming. „ When refilling media, first remove any media remaining in the tray. Stack it with the new media, even the edges, then reload it. Although the magi-...

  • Page 43: Upper And Optional Media Trays

    If you are printing duplex from the multipur- pose tray, load the media printing-side up with the top of the media toward the printer. 5 " The options in the driver are Simplex (1-sided pages), or Long Edge (flipped horizontally as in a loose-leaf notebook), or Short Edge (flipped vertically as on a clipboard).
  • Page 44 Adjust the media guides to fit the size paper you’re loading. Squeeze the retainers, move the guides to the appropriate location (media sizes are listed on the tray), and release the retainers. The media should fit easily between the guides. Load the paper face-up, short edge toward the right of the tray.

  • Page 45: Multipurpose Tray

    Attention Always readjust the media guides after inserting the media. Improperly adjusted guides may cause poor print quality, media jams, or printer damage. Slide the tray back into the printer. 5 " If you have...
  • Page 46 Open the media support. Attention Load only one type/size of media per tray at a time. Load the media face down, short edge toward the printer. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Loading Media...

  • Page 47: Printing Envelopes From The Multipurpose Tray

    Always adjust the media guides after inserting the media. A guide that is not properly adjusted can cause poor print quality, media jams, or printer damage. Specify the media size in the multipurpose tray by using the MP Size key on the control panel.

  • Page 48: Printing Area

    Place the envelope stack into the multipurpose tray with the flap-side up. Check your application documentation to determine if the flap should be placed on the left or on the right. Print a single envelope to check the ori- entation before printing multiple copies. Adjust the media guides to the width of the envelopes.

  • Page 49: Maintaining The Printer

    Maintaining the Printer EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 50: Maintaining The Printer

    Maintaining the Printer Handle the printer with care to preserve its life. Abuse may cause damage and void your warranty. If dust and paper scraps remain on the inside or out- side of the printer, printer performance and print quality will suffer, so the printer should be cleaned periodically.
  • Page 51 „ Do not put a cover on the printer immediately after using it. Turn it off and wait until it cools down. „ Do not leave the printer’s covers open for any length of time, especially in well-lit places; light may damage the OPC drum cartridge.

  • Page 52: Cleaning

    12 months, or as needed, whichever comes earlier. Always test any cleaning solution (such as a mild detergent) on a small area of your printer to check the solution’s performance Outside the Printer A soft dry cloth to clean the...

  • Page 53: Troubleshooting

    Troubleshooting EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 54: Introduction

    Introduction This chapter provides information to aid you in resolving printer problems you may encounter, or at least guide you to the proper sources for help. Printing a Status Page Print a status page to verify the printer is printing correctly.

  • Page 55: Automatic Jam Recovery

    Automatic Jam Recovery The magicolor 2210 provides automatic jam recovery (when enabled through the Administration/Engine/Page Recovery menu). After you remove any jammed media, printing automatically resumes from the page the printer stopped at when the jam occurred.

  • Page 56: Understanding The Media Path

    Understanding the Media Path Understanding the printer’s media path will help you locate media jams. c c c c Media exit unit d d d d Output tray e e e e Fuser f f f f Transfer belt g g g g OPC drum cartridge...

  • Page 57: Media Tray (Standard Upper Tray And Optional Tray)

    Lower Feed Unit (LFU) Tray(s) The LFU media tray(s) is (are) located at the bottom front of the printer in the lower feeder unit(s). The media fed through the LFU is picked and delivered to the output tray the same way as media from the standard upper tray.

  • Page 58: Handling Media Jams By Location

    Make sure not to spill any toner inside the printer. Unfused toner can dirty your hands, clothes, or anything else it gets on. If you accidentally get toner on your hands, wash them in cool water.

  • Page 59: Clearing Misfeed (Upper Or Optional Tray) Jams

    Slide the tray(s) back into the printer. Open the front cover, then close it. The media jam message is no longer displayed in the printer message window. Clearing Media Jams EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 60: Clearing Misfeed (Multipurpose Tray) Jams

    Check to see if the media width guides are correct. Open the front cover, then close it. The media jam message is no longer displayed in the printer message window. Clearing Inner Jams, Outer Jams, and Drum Jams...
  • Page 61 Attention Do not pull jammed media from the top of the printer through the fusing rollers. This prevents any unfused toner from dirtying the fuser rollers. Clearing Media Jams...
  • Page 62 Close the right-side cover. The media jam message is no longer displayed in the printer message window. Check the release button to make sure the cover is securely closed. If media was removed in step 1, open the multipurpose tray.
  • Page 63 Carefully remove the jammed media in the top cover media reverse area. Open the media jam removal cover with your left hand and carefully remove the jammed media in the duplex media feed area with your right hand. Close the media jam removal cover with your left hand and close the top cover.
  • Page 64 Pressing the duplex unit cover release, carefully open the cover. Remove the jammed media. Close the duplex unit’s cover. Close the multipurpose tray. If there still is a jam message, press the right-side cover release button and carefully open the cover all the way.
  • Page 65 Be careful not to touch the transfer belt while removing jammed media. Close the printer’s top cover. Close the duplex unit’s paper guide, lower cover, and top cover. The media jam message is no longer displayed in the printer message window. Media Jams near the Fuser Unit Open the top cover.
  • Page 66 Check the release button to make sure the duplex unit cover is securely closed. The media jam message is no longer displayed in the printer message window. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Clearing Media Jams...
  • Page 67 Media Jams in the Optional 5-bin Mailbox Carefully remove the jammed media from the paper eject area of the mailbox. Open the mailbox door. Lift up the paper jam removal guide in the mailbox with your left hand, and use your right hand to carefully remove the jammed paper.

  • Page 68: Media Jams In The Output Tray

    Close the mailbox door. The media jam message is no longer displayed in the printer message window. Media Jams in the Output Tray Remove jammed media from the output tray by gently pulling it to the left away from the media exit area.
  • Page 69 Check for media stuck in the paper guides in the duplex unit’s top cover, and the media supply area on the lower left of the printer. If you removed jammed media from near the OPC drum, reset the OPC drum’s locking levers.
  • Page 70 If the flaps are on the short edge, set the envelopes in the multipurpose tray so that the flaps are on the printer side. Remove the OHP media and load them in the tray one sheet at a time. Do not fan transparencies before loading them.

  • Page 71: Ednord - Istedgade 37A - 9000 Aalborg - Telefon

    —Connect the mailbox power cord plug end to the mailbox power socket (lower connection). —Connect the mailbox power cord socket end to the printer power plug. —Connect the printer power cord socket end to the mailbox power plug (upper connection).
  • Page 72 Latin America: 120 VAC ±10% 220-240 VAC ±10% —Frequency fluctuation rate within 50/60 ±3 Hz Turn the printer off line before printing a status page. Check that the media trays are loaded with media, in place and secure. Make sure the front and top covers are closed securely.
  • Page 73 Make sure you have enough printer memory. Some applications send a printer prep file to the printer at the beginning of each document. When this occurs, other prep files cannot be sent without resetting the printer. Monitor your...
  • Page 74 If the toner cartridges are not empty and blank pages are ejecting, take each cartridge out, rock it from side to side, and reinstall it in the printer. Check that the media type set in the driver matches the media loaded in the printer.
  • Page 75 4 o’clock position, then remove the transfer belt. After 100 1-sided pages of a continuous print run, the magicolor 2210 automati- cally pauses to do an AIDC cycle. This process is provided to make sure reliable printer operation with optimum...

  • Page 76: Solving Problems With Printing Quality

    Adjust the humidity for paper storage. Remove the moist media and replace it with new, dry media. Load the correct media in the printer. Open the front cover. Lift up the transfer belt release lever to the 12 o’clock posi- tion.
  • Page 77 Remove the OPC drum cartridge and check for damage. If necessary, replace the entire drum kit. Make sure that the transfer unit was correctly installed. Replace the transfer roller. Level the printer (not exceeding 1.5° slant at any point around the machine).
  • Page 78 Remove the moist media and replace it with new, dry media. Use media that is covered by the printer warranty. Envelopes, glossy stock, labels, trans- fer media, and thick stock have to be set in the Thick Stock mode.
  • Page 79 Symptom Cause Image is One or more of the toner blurred; cartridges is defective. back- ground is The OPC drum may be lightly misinstalled or defective. stained; there is insuffi- cient gloss of the printed image. Back- One or more of the toner ground is cartridges is defective.
  • Page 80 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Solution Remove the moist media and replace it with new, dry media. Use media that is covered by the printer warranty. Remove the toner cartridge and check for damage. If necessary, replace it.
  • Page 81 Install new ones, if neces- sary. If toner smudges are on the front and back of the page: „ Open the printer front cover once and close it again to clean the image transfer roller. Remove the fuser oil roller and check the roller surface.
  • Page 82 Symptom Cause There are The paper transport roll- toner ers may be dirty. smudges on the back side of the The media path is dirty page with toner. (whether or not it The fuser oil roller is dirty has been or worn.
  • Page 83 Symptom Cause Abnormal Width of abnormal area: areas 1.25" (31.75 mm) (white or The toner cartridge is black) damaged. appear in Width of abnormal area: a regular 3" (76.2 mm) pattern. The transfer belt is damaged. Width of abnormal area: ABCDE 3.25"...
  • Page 84 ABCDE ABCDE The fuser belt may be ABCDE dirty. The fusing unit may be defective. Lateral The printer is not on a lines or level enough surface. bands The media path is dirty appear on with toner. image. One or more of the toner cartridges is defective.
  • Page 85 Symptom Cause Lateral Lateral lines have 1–2 mm lines spacing. appear Lateral lines have 35 mm cyclically spacing. (evenly Lateral lines have 75 mm spaced) spacing. on image. Lateral lines have 95 mm spacing. Lateral lines have 204 mm spacing. Trailing edge 35 mm, other spacing Vertical...
  • Page 86 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Solution Remove the toner cartridges and rein- stall them. Make sure that the printer’s front cover is closed. Remove the OPC drum cartridge and reinstall it. Remove the toner cartridges and gently rock them five or six times to redistrib- ute the toner.

  • Page 87: Status, Error, And Service Messages

    Status, Error, and Service Messages Status, error, and service messages are displayed in the control panel mes- sage window. They provide information about your printer and help you locate many problems. When the condition associated with a displayed message has changed, the message is cleared from the window.
  • Page 88 The < X > (color) toner cartridge is low. There is still enough for approximately 100 letter/A4 pages (at 5% coverage) before the printer stops. The accounting option selected is now in effect. The Job Accounting File is 80, 85, 90, or 95% full.
  • Page 89 The< INPUT> (specified tray) is not inserted correctly. After 100 1-sided pages of a continuous print run, the magicolor 2210 automatically pauses to do an Auto-Image Density Control (AIDC) cycle. This process is provided to make sure reliable printer operation with optimum output quality.
  • Page 90 The Cancel key has been pressed and the End Job option selected. The printer is in energy saver mode to reduce power con- sumption during periods of inactivity. When a print job is received, the printer returns to normal power within 90 sec- onds.
  • Page 91 The printer will not print any more copies until a new fuser oil roller is installed. The printer is on line, but no jobs are in process. The printer is warming up and getting ready to go on line.
  • Page 92 Mail bin jams occur if the media is jammed in the 5-bin mailbox on the models with the 5-bin mailbox installed, between the printer and the 5-bin mailbox, in the mailbox eject area, or in the mailbox transport area. Media has jammed while being pulled from the specified multi- purpose tray.
  • Page 93 The size of the accounting files has been increased or decreased. A printer hardware error has occurred. The printer is online and ready to print. Do this... Locate and remove the jam. Close the door. Locate and remove the jam.
  • Page 94 Refill the tray with the specified size media. Refill the tray with the specified type media. Replace the speci- fied item. No action needed. Wait until the print job is finished and the printer goes idle.
  • Page 95 Cancel key. No other jobs can be printed until this job has ended. The printer is warming up. The waste toner pack is nearly filled with toner. The waste toner pack is filled with toner.

  • Page 96: Service Messages

    An error has been detected with the item indicated in the service message. Correction of these errors is performed by a MINOLTA-QMS authorized service provider only. Contact your local vendor. A service message sometimes occurs as a result of an unusual combination of events, not because of an actual problem.
  • Page 97 An error has been detected with the item indicated in the service message. Correc- tion of these errors is performed by a MINOLTA-QMS authorized service pro- vider only. Contact your local vendor. A service message sometimes occurs as a result of an unusual combination of events, not because of an actual problem.
  • Page 98 An error has been detected with the item indicated in the service message. Correc- tion of these errors is performed by a MINOLTA-QMS authorized service pro- vider only. Contact your local vendor. A service message sometimes occurs as a result of an unusual combination of events, not because of an actual problem.

  • Page 99: Hp-Gl, Hpxl, And Pcl Error Codes

    HP-GL, HPXL, and PCL Error Codes The following tables list error codes that could appear on the printer message window when running the HP-GL, HPXL, or PCL emulation. HP-GL Error Description Code Not enough memory for job. Too many transformations.

  • Page 100: Postscript Errors

    PostScript Errors If your printer is having trouble printing when using PostScript emulation, you should turn on the Error Handler in the control panel menu. Error Handler is a diagnostic tool that identifies PostScript errors encountered during a print job.

  • Page 101: Installing Other Accessories

    Installing Other Accessories EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 102: Introduction

    Three models: For 100-, 120-, or 220-volt printers ADF for convenience copier Via parallel connection for 100, 120, and 220 volts 32, 64, or 128 MB, PC-100 Compliant SDRAM DIMMs, up to a printer maximum of 384 MB Automatic duplexing „ ImageServer „ TIFF „...

  • Page 103: Accessories

    BuzzBox BuzzBox is a printer accessory that warns you with a buzzer and/or a blinking light any time the printer goes off line. This means you’re alerted to print job interruptions, such as empty media trays or other consumable issues.

  • Page 104: What's In The Kit

    Power adapter „ Adhesive-backed clips Installing BuzzBox If you have a cable attached to the printer’s parallel port, unplug it from the printer. Attach one end of the parallel cable on the interface box to the printer’s parallel port. 5 "...

  • Page 105: Using Buzzbox

    Dual in-line memory modules (or DIMMs) are compact circuit boards with surface-mount memory chips. Your magicolor 2210 printer comes with 128 MB SDRAM of printer memory. However, you can upgrade to a maximum of 384 MB of RAM through the installation of additional DIMMs.

  • Page 106: How Much Memory Do You Need

    128 MB of RAM instead of the required 256 MB minimum, the file prints at 600x600 dpi. The magicolor 2210 will print all print jobs at the highest resolution that the installed memory will support. Minimum System Memory Requirements (in MB)
  • Page 107 Administration/Memory/Quick Config menu to choose the correct resolution and paper size for your printing. If you experience a problem with your magicolor 2210, first go through the installation procedure in this guide once more. Verify each item thoroughly. You may also refer to the User’s Guide for troubleshooting tips. If you still experience a problem, contact your local vendor or contact Customer Service.
  • Page 108 DIMMs, so you can recover the current memory settings. Ensure that the printer is turned off and the power cord and all interface cables are disconnected. Remove the printer’s controller board.

  • Page 109: Installing A Duplex Unit

    When you print a startup page, verify that the total size of the RAM installed in your printer is listed. Installing a Duplex Unit Read this section if you purchased a duplex unit for your magicolor 2210. Kit Contents „...
  • Page 110 Remove the tape from the unit. Open the multipurpose tray. Remove the two thumbscrews from the right side cover. 5 " Retain these screws in case you need to remove the duplex unit in the future. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Installing a Duplex Unit...
  • Page 111 Press the right-side cover release button. Open the right-side cover. Pull the right-side cover toward you, lift it, and unhook it from its frame. With the multipurpose tray still open, close the right-side cover. Insert the bottom of the duplex unit at a shallow angle into the right-side cover.
  • Page 112 Press the top of the duplex unit in. Open the duplex unit paper path cover. Secure the duplex unit tightly with the two thumbscrews supplied in the kit. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Installing a Duplex Unit...
  • Page 113 Close the duplex paper path cover and multipurpose tray. Open the right-side cover. Extend the spring wire for the duplex unit about 1 foot (30.5 cm). Installing a Duplex Unit EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 114: Emulations, Fonts, And Other Software

    5 " You must have at least one hard disk, internal or external, attached to the printer in order to use an optional emulation. If more than one hard disk is available, the emulation automatically installs itself on the disk with the most free storage space.

  • Page 115: Downloading An Emulation Via An Ethernet Interface

    When the Disk light stops flashing and the printer’s message window reads IDLE for at least 30 seconds, turn the printer off and then on again. When downloading is complete, reboot the printer. The emulation should be listed in the Options section of the printer’s startup page, in the Administration/Emulation printer’s configuration...

  • Page 116: Fonts

    5 " At least one hard disk (internal or external) must be present on your printer before you can download a font. If more than one hard disk is available, the font automatically installs itself on the disk with the most free storage space.

  • Page 117: Kanji Font Internal Ide Hard Disk

    These fonts can be printed at a variety of point sizes and in different styles and resolutions. After the Kanji hard disk is installed in your magicolor 2210, the Kanji fonts are available for use just as if they were resident in the printer.

  • Page 118: What's In The Kit

    What's in the Kit? „ Internal hard disk preformatted with the following Kanji fonts: z FutoGoB101-Bold z FutoMinA101-Bold z GothicBBB-Medium z Jun101-Light z MidashiGo-MB31 z MidashiMin-MA 31 z Ryumin-Light-KL „ IDE hard disk with ribbon cable attached „ IDE hard disk bracket „...

  • Page 119: 5-Bin Mailbox

    See “Storage Devices” in the CrownBook for information on how to configure your printer’s memory when using an internal hard disk. 5-bin Mailbox Read this section if you purchased a 5-bin mailbox for your magicolor 2210. Kit Contents „ Mailbox unit „...
  • Page 120 Remove any tape and packing material. Open the mailbox unit cover and remove any packing material from the rear of the mailbox unit. Close the mailbox unit cover. Remove any packing material from the front of the mailbox unit. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 5-bin Mailbox...
  • Page 121 Slowly lower the mailbox unit so that the two pins at the bottom fit into the two holes in the printer and the pin on the printer fits into the hole at the bottom of the mailbox.
  • Page 122 Secure the mailbox tightly with the two thumbscrews supplied in the kit. Place the slot on the right side of the accessory screen cover from the kit onto the tab on the mailbox then press on the left side of the accessory screen cover so the tab on that side fits into the slot on the mailbox.
  • Page 123 Make sure the printer is turned off. Make sure the 5-bin mailbox is turned off. Attention Always turn off the printer before turning off the mailbox. 5-bin Mailbox EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 124: Qform

    QFORM QFORM allows you to use existing lineprinter and forms-printing applications on your magicolor 2210. This printer-resident application gives you the ability to store PostScript forms on the printer’s hard disk and fill those forms with your application’s ASCII print stream. Features include „...

  • Page 125: Interfaces And Daughterboards

    Installation Attention It’s very important to protect the printer controller board and any associated circuit boards from electrostatic damage. Before performing this procedure, review the antistatic caution on page 105. In addition, always handle circuit boards by the edges only.
  • Page 126 Turn off the printer, and then disconnect the power cord and all interface cables from the printer. Loosen five screws and, using the tab on the lower side of the panel, pull the controller board from the printer. Remove the two screws holding the metal plate over the optional interface opening.

  • Page 127: Scsi Interface

    Gently slide the controller board into the printer until it is fully seated, and then tighten the five screws. Reconnect all interface cables. Reconnect the power cord, and turn on the printer. 5 " In compliance with UL guidelines, “The appliance inlet is considered to be the main disconnect device.”...
  • Page 128 Installation Attention It’s very important to protect the printer controller board and any associated circuit boards from electrostatic damage. Before performing this procedure, review the antistatic caution on page 105. In addition, always handle circuit boards by the edges only.

  • Page 129: Internal Ide Hard Disk Drive

    Secure the SCSI interface card to the interface panel with the two larger screws in the kit. Reinstall the controller board. Gently slide the controller board into the printer until it’s fully seated, and then tighten the five screws. Reconnect all interface cables.
  • Page 130 The controller board will not function if any of the leads are broken or shorted together. Ensure that the printer is turned off and the power cord and all interface cables are disconnected.
  • Page 131 If you’re installing DIMMs, go to the next section. Otherwise, reinstall the controller board into the printer. Gently slide the controller board into the printer until it is fully seated, and then tighten the five screws. When you print a startup page (page 42), verify that the hard disk is listed.

  • Page 132: Lower Feeder Unit

    2 securing thumbscrews Installation Attention If consumables are installed in the printer, be sure to keep the printer level when moving it to prevent accidental spills. If your printer is located in its permanent location, follow this procedure. Otherwise, skip to step 3.
  • Page 133 With one person holding the carrying bars and another holding the two grips on the left side of the printer, lift the printer and temporarily move it to a flat, level surface. Remove the lower feeder unit from the shipping carton, and place it where the printer will be located.
  • Page 134 With another person’s help, lift the printer. When lifting and carrying the printer, use the pull-out carrying bars the hand grips d d d d c c c c Slowly lower the printer onto the lower feeder unit, lining up the four holes in the...
  • Page 135 Hold bracket R on a slant to insert it from the front end into the bracket R slot on the right side of the printer frame, then hold bracket R level and secure it tightly with the thumbscrew. Unscrew the thumbscrew from the rear of the printer.

  • Page 136: Media Trays

    Slide the upper media tray back into the printer. Media Trays The printer comes with a 150-sheet multipurpose tray (tray 1), and a 500-sheet media tray (the upper tray—tray 2). The optional lower feeder unit has another 500-sheet optional media tray that provides two main benefits: „...

  • Page 137: Printer Stand/Cabinet

    SC-210 Convenience Copier You can expand your magicolor 2210’s functionality by connecting an SC-210 digital color convenience copier option to the standard parallel port on the printer (interface set to “non-interactive”). The SC-210 supports up to legal-size paper.
  • Page 138 Because the time-of-day clock includes an internal battery, there is a danger of explosion if the clock is incorrectly installed or replaced. Replace it only with a supported MINOLTA-QMS time-of-day clock. Dispose of any used time-of-day clock in accordance with local laws and regulations.
  • Page 139 Gently press down on the time-of-day clock until it’s firmly seated. Reinstall the controller board. Gently slide the controller board into the printer until it is fully seated, and then tighten the two screws. Reconnect all interface cables.
  • Page 140 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 141: Color Printing

    Color Printing EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 142: Introduction

    600x600, and 1200x1200 dpi on plain paper, envelopes, labels, thick stock, and transparencies. Color Management and Control The magicolor 2210 offers a host of color screening, matching, and calibra- tion tools for both the beginner and professional color user. MINOLTA-QMS Q Color management does not mean all devices will match exactly.

  • Page 143: Further Information

    Individual page element correction: Q (matches) graphics, text, and images on a singe page using printer-resi- dent CRDs. Further Information For further information about the MINOLTA-QMS color management, refer to the CrownBook . Introduction EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...
  • Page 144 EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 145: Repacking The Printer

    Repacking the Printer EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 146: Storing The Printer

    We strongly suggest that you save the packaging materials in case you ever need to move or ship the printer. Refer to the Service & Support Guide or www.minolta-qms.com for additional information on where to obtain assistance if necessary EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 87.1...

  • Page 147: Repacking The Printer

    Authorization) number you received from your customer support representative on the outside of the carton before shipping the printer. If the printer is not strapped to the pallet or if the RMA number is not prominently visible on the outside of the return inventory, we will not accept receipt.

  • Page 148: Remove The Cables

    Remove the lower input feeder (if attached). Repack the printer for shipment. To avoid toner contamination during shipment, the printer should be repacked without the fuser oil roller, toner cartridges, waste toner pack, OPC drum car- tridge, or transfer belt installed.

  • Page 149: Remove The Waste Toner Pack

    Repack the duplex unit in its original shipping carton for storage or shipment. 5 " If you’re returning the printer for service, you don’t need to return the duplex unit, unless the problem is with the duplex unit. EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 150: Remove The 5-Bin Mailbox

    Remove the brackets on the right and left in front that are securing the optional tray to the printer. Replace the upper media tray. With the help of another person, lift the printer by its carrying grips and carrying bar, and place the printer on a table. WARNING! Your printer weighs approximately consumables.

  • Page 151: Repack The Printer

    Repack the Printer If you need replacement packaging, in the United States, call MINOLTA-QMS Spares at 1 (251) 633-4300 extension 2530 and request part number 2600674-901 for the repacking kit. Refer to the Service & Support Guide or www.minolta-qms.com for locations outside the United States.

  • Page 152: Strapping/Buckling Kit Contents

    Pack the printer for shipment as shown. If you’re also shipping the power cord and any manuals with the printer, place them in the shipping carton. 5 " Don’t ship these items if you’re returning the printer for service. Securely tape the...
  • Page 153 Pull the two ends of the strapping together at the approximate center of the top of the printer. Thread both ends up through the center of the buckle. Weave the slack of one end through the buckle.
  • Page 154 Pull the buckle against the printer as tightly as possible. Some slack may still exist. Repeat this procedure three more times, spacing the straps equidistant across the box.

  • Page 155: A Technical Specifications

    Technical Specifications EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500...

  • Page 156: Requirements

    The illustration below shows the amount of space required for operating the printer, replacing supplies, and removing media jams. Top View 4" (100 m m ) If you have added accessories, the printer’s height will increase by Lower feeder unit Duplex unit 5-bin mailbox EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 4"...

  • Page 157: Power Requirements

    A surface can be tested for levelness with a standard round pencil. If the pencil rolls, the surface is not level. Clear the area of any obstruction or items such as cables that might prevent the printer from sitting directly on the flat, level surface.
  • Page 158 If the printer is located in a cold room that is rapidly heated, or if the printer is moved from a cold place to a warm, humid place, condensation may occur within the printer, degrading print quality.

  • Page 159: Engine And Controller Specifications

    Computer Requirements Printer performance depends upon the type of computer to which you con- nect it. We recommend a Pentium-class computer with at least 16 MB of RAM (if you’re using Windows Me/98/95) or 32 MB of RAM (if you’re using Windows 2000/NT4).

  • Page 160: Print Speed-Autoduplex

    Maximum: 110 volts: 150 seconds Input sources Standard: 500-sheet tray Optional: 500-sheet lower input feeder Output 250-sheet tray on top of printer EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Monochrome ppm 4-Color ppm 220 volts: 160 seconds...

  • Page 161: Controller

    Type 1 / Type 3 Support—Support for Type 1 and Type 3 host-resident downloadable PostScript fonts TrueType—Support for Type 42 (PostScript format) host-resident downloadable TrueType fonts, support for TrueType fonts in PCL Hard disk—MINOLTA-QMS Kanji Internal IDE Hard Disk with 7 Morisawa fonts (Ryumin-Light-KL, GothicBBB-Medium, FutoMinA101-Bold, FutoGoB101, Jun101-Light, MidashiMin-MA31, and Midashi Go-MB31) CrownNet for Ethernet—10BaseT/100BaseTX...

  • Page 162: Electrical

    Softloadable; stored in Flash ROM Optional, up to 2.2 GB 5 " For information about hard disks recommended for your printer, see the magicolor 2210 Answer Base through the Internet at http:// www.minolta-qms.com/support/, or contact Technical Support (see the Service & Support Guide for a complete listing of support telephone numbers).
  • Page 163 Environmental Noise level Relative humidity Temperature range Altitude Inclination Engine and Controller Specifications EDNord - Istedgade 37A - 9000 Aalborg - telefon 96333500 Printing: Less than 55 dB (A) Standby: Less than 41 dB (A) Operating: 15-85% RH (noncondensing) Transportation/Storage: 30–85% RH (noncondensing) Operating: 50-95°...

  • Page 164: Physical

    H: 22.0 in. (560 mm) H: 22.0 in. (560 D: 21.3 in. (522 mm) D: 21.3 in. (522 Unpacked: Unpacked: Printer: 87.1 lbs Printer: 87.1 lbs (39.5 (39.5 kg) Lower Input Lower Input Feeder: Feeder: 13.2 lbs (6.0 kg) 13.2 lbs (6.0 kg) Duplex Unit: 3.7 lbs...

  • Page 165: Document Option Commands

    Media sizes, See “Media Types” on page 35. types, and weights Notes The maximum media weight supported for duplex printing is 24 lb bond (90g/m Document Option Commands This lists the supported Document Option Commands (DOCs) for your magi- color 2210. The commands are grouped by feature type. Each command is preceded by either a DOC statement (%%) or an Include- Feature statement (%%IncludeFeature).

  • Page 166: Hp Pcl 5E Emulation Commands

    Select pen width and color Select plotter Scale the image Set origin HP PCL 5e Emulation Commands Install object Remove object Remove resource Retain temporary Select default font Select default font ID Reset Select scalable fonts Select symbol set Set carriage return to CR+LF Set linefeed to CR+LF Set number of lines per inch Set point size...

  • Page 167: Document Formatting

    Document Formatting Logical page orientation Number up printing Offset logical page Print borders Scale logical page Print background images Set printer resolution Print page range Duplex printing Collate print job Logical page size Select number of copies Select paper Select orientation...

  • Page 168: Ln03 Plus Commands
