Contents Contents Introduction We Want You to Be a Satisfied Customer ...1-2 For U.S.A. Users FCC Part 15-Radio Frequency Devices ...1-2 For Canada Users Interference-Causing Equipment Standard (ICES-003 Issue 4).1-3 For users in countries subject to Class B regulations...1-3 For users in countries not subject to Class B regulations...1-3 Safety Information...1-4 47 CFR - Telecommunication Devices ...1-11 Warning For Setting Of Header And Footer ...1-12...
Page 3 Operating Environment ... 2-4 Proper Use ... 2-4 Transporting the Machine ... 2-5 Care of Machine Supplies ... 2-5 Legal Restrictions on Copying... 2-6 Before Making Copies or Faxing Available Features... 3-2 Components and Their Functions ... 3-3 Parts Names and Their Functions ... 3-4 Main Unit...
Page 4 Contents Specific Types of Originals ...3-29 Precautions for Loading Paper Into the Auto Document Feeder ...3-29 Loading Originals into the Auto Document Feeder...3-30 3.10 Checking the Machine Status ...3-31 Checking the “TOTAL PAGE” Counts ...3-32 Checking the “TX/RX RESULT” ...3-33 To output a report/list...3-34 TX Result Report ...3-35 RX Result Report...3-35...
Page 5 To fax by entering the fax number directly using the 10-Key Pad... 5-2 To fax using one-touch dialing ... 5-3 To fax using speed dialing ... 5-5 To fax using group dialing ... 5-6 To fax using chain dialing ... 5-7 To fax using program dialing (Available only with FAX3900)...
Page 6 Contents Reception Methods ...6-22 Manual Reception...6-22 To receive a fax manually...6-22 Memory Reception ...6-22 Mailbox Reception ...6-23 To retrieve a document from a mailbox ...6-23 Polling Reception...6-24 To receive a fax using polling reception ...6-24 Using F codes...6-26 Using Mailboxes ...6-27 Specifying F codes ...6-28 When sending faxes ...6-28 Programming F codes ...6-28...
Page 7 Setting Up One-Touch Dialing (“ONE-TOUCH DIAL” function)7-27 To program a one-touch dial key ... 7-27 To change/delete a programmed one-touch dial key... 7-29 Specifying the Setting for “SPEED DIAL” ... 7-31 To program a speed dial number ... 7-31 To change/delete a programmed speed dial number ... 7-33 Specifying the Setting for “GROUP DIAL”...
Page 8 Contents Specifying the Setting for “CLOSED NETWORK” ...7-68 Setting Up the Communication...7-69 Specifying the Setting for “TONE/PULSE” ...7-69 To specify the telephone dialing system...7-69 Specifying the Setting for “LINE MONITOR” ...7-70 Specifying the Setting for “PSTN/PBX” ...7-71 To specify the telephone wiring system...7-71 7.10 Setting Up the Report Output ...7-72 Selecting the “REPORTING”...
Page 9 8.11 When Faxing Is Not Performed Correctly ... 8-29 Faxes Cannot Be Sent ... 8-29 Faxes Cannot Be Received ... 8-30 Calls Cannot Be Sent... 8-31 Internet Fax & Network Scan Overview... 9-2 Logging in to Administrator Mode ... 9-13 Getting Ready ...
Page 10 Contents “Scan” Tab...9-38 File Destination Setting...9-38 Specifying the Settings for a One-Touch Dial Key ...9-42 Specifying the Settings for a Speed Dial Number ...9-43 Specifying the Settings for a Group Dial Key ...9-44 Specifying Settings for One-Touch Dialing...9-46 Adding a New One-Touch Dial Setting...9-47 Specifying the Settings for Speed Dialing ...9-48 Adding a New Speed Dial Setting ...9-49 Specifying the Settings for Group Dialing...9-50...
Page 11 Contents...
Page 12: Introduction
Introduction...
Page 13: We Want You To Be A Satisfied Customer
1.1 We Want You to Be a Satisfied Customer We Want You to Be a Satisfied Customer Thank you for choosing the FAX2900/3900. This User Manual describes the functions, operating procedures, precautions, and basic troubleshooting for the FAX2900/3900. Before using this machine, be sure to read the User Manual thoroughly in order to ensure that you use the machine efficiently.
Page 14: For Canada Users
1.1 We Want You to Be a Satisfied Customer For Canada Users Interference-Causing Equipment Standard (ICES-003 Issue 4) This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
Page 15: Safety Information
Safety Information This section contains detailed instructions on the operation and maintenance of this machine. To achieve optimum utility of this device, all operators should carefully read and follow the instructions in this manual. Please read the following section before connecting the machine to the supply. It contains important information related to user safety and preventing equipment problems.
Page 16 1.2 Safety Information Disassemble and modification WARNING • Do not attempt to remove the covers and panels which have been fixed to the product. Some products have a high-voltage part or a laser beam source inside that could cause an electrical shock or blindness.
Page 17 Power source WARNING • Use only the specified power source voltage. Failure to do that could result in a fire or electrical shock. • Connect power plug directly into wall outlet having the same configuration as the plug. Use of an adapter leads to the product connecting to inadequate power supply (voltage, current capacity, grounding), and may result in fire or shock.
Page 18 1.2 Safety Information Power plug WARNING • Do not unplug and plug in the power cord with a wet hand, as an electrical shock could result. • Plug the power cord all the way into the power outlet. Failure to do this could result in a fire or electrical shock.
Page 19 Installation WARNING • Do not place a flower vase or other container that contains water, or metal clips or other small metallic objects on this product. Spilled water or metallic objects dropped inside the product could result in a fire, electrical shock, or breakdown. Should a piece of metal, water, or any other similar foreign matter get inside the product, immediately turn OFF the power switch, unplug the power cord from...
Page 20 1.2 Safety Information Actions in response to troubles WARNING • Do not keep using this product, if this product becomes inordinately hot or emits smoke, or unusual odor or noise. Immediately turn OFF the power switch, unplug the power cord from the power outlet, and then call your authorized service representative.
Page 21 When moving the machine CAUTION • Whenever moving this product, be sure to disconnect the power cord and other cables. Failure to do this could damage the cord or cable, resulting in a fire, electrical shock, or breakdown. • When moving this product, always hold it by the locations specified in the User manual or other documents.
Page 22: 47 Cfr - Telecommunication Devices
If they do, you will be given advance notice so as to give you an opportunity to maintain uninterrupted service. If you experience trouble with this equipment, please contact: Konica Minolta Business Solution U.S.A.,Inc. 100 Williams Drive Ramsey. New Jersey 07446 U.S.A...
Page 23: Warning For Setting Of Header And Footer
it...
Page 24: Laser Safety
1.2 Safety Information present, are connected together. This precaution may be particularly important in rural areas. CAUTION: Users should not attempt to make such connections themselves, but should contact the appropriate electric inspection authority, or electrician, as appropriate. NOTICE: The Ringer Equivalence Number (REN) for this terminal equipment is as follows. The REN assigned to each terminal equipment provides an identification of the maximum number of terminals allowed to be connected to a telephone interface.
Page 25: Cdrh Regulation
1.2 Safety Information Print Head Laser Aperture of the Print Head Unit There is a laser aperture at the location shown above, which must NEVER be viewed directly by the user. CDRH Regulation This machine is certified as a Class 1 Laser product under Radiation Performance Standard according to the Food, Drug and Cosmetic Act of 1990.
Page 26: For European Users
1.2 Safety Information The label shown on page 1-17 indicates compliance with the CDRH regulations and must be attached to laser products marketed in the United States. CAUTION Use of controls, adjustments or performance of procedures other than those specified in this manual may result in hazardous radiation exposure. This is a semiconductor laser.
Page 27 VARNING! Om apparaten används på annat sätt än i denna bruksanvisning specificerats, kan användaren utsättas för osynlig laserstrålning, som överskrider gränsen för laserklass 1. Det här är en halvledarlaser. Den maximala effekten för laserdioden är 15 mW och våglängden är 770-800 nm. VARO! Avattaessa ja suojalukitus ohitettaessa olet alttiina näkymättömälle lasersäteilylle.
Page 28: For Norway Users
1.2 Safety Information For Norway Users ADVERSEL Dersom apparatet brukes på annen måte enn spesifisert i denne bruksanvisning, kan brukeren utsettes for unsynlig laserstråling som overskrider grensen for laser klass 1. Dette en halvleder laser. Maksimal effekt till laserdiode er 15 mW og bølgelengde er 770-800 nm.
Page 29: Ozone Release
Ozone Release CAUTION Locate the Machine in a Well-Ventilated Room § A negligible amount of ozone is generated during normal operation of this machine. An unpleasant odor may, however, be created in poorly ventilated rooms during extensive machine operations. For a comfortable, healthy, and safe operating environment, it is recommended that the room be well ventilated.
Page 30: Energy Star
1.3 Energy Star® ® Energy Star ® As an ENERGY STAR Partner, we have determined that this machine meets the ® ENERGY STAR Guidelines for energy efficiency. ® What is an ENERGY STAR Product? ® An ENERGY STAR product has a special feature that allows it to automatically ®...
Page 31: Explanation Of Manual Conventions
Explanation of Manual Conventions The marks and text formats used in this manual are described below. WARNING Failure to observe instructions highlighted in this manner may result in fatal or critical injuries. § Observe all warnings in order to ensure safe use of the machine. CAUTION Failure to observe instructions highlighted in this manner may result in serious injuries or property damage.
Page 32: Explanation Of Basic Concepts And Symbols
1.5 Explanation of Basic Concepts and Symbols Explanation of Basic Concepts and Symbols The use of words and symbols in this manual are explained below. Paper Feeding During printing, paper is supplied from the front side of the machine and fed into the Copy Tray on top with the printed surface of the page facing down.
Page 33: Width" And "Length
1.5 Explanation of Basic Concepts and Symbols “Width” and “Length” Whenever paper dimensions are mentioned in this manual, the first value always refers to the width of the paper (shown as “A” in the illustration) and the second to the length (shown as “B”).
Page 34: Precautions
Precautions...
Page 35: Installation Precautions
Observe the following precautions to maintain the machine in its best possible condition. Installation Precautions Installation Site To ensure utmost safety and prevent possible malfunctions, install the machine in a location that meets the following requirements: A location away from curtains, etc. that may catch fire and burn easily A location that is not exposed to water or other liquids A location free from direct sunlight A location out of the direct airflow of an air conditioner or heater, and not...
Page 36: Space Requirements
2.1 Installation Precautions Space Requirements To ensure easy machine operation, supply replacement, and maintenance, adhere to the recommended space requirements detailed below. 516mm ( 20.3inch ) Note In order to enable easy machine maintenance and replacement of consumables, maintain an adequate amount of space around the machine. When lifting the machine, be sure to grab the handles on the left and right sides from the rear of the machine.
Page 37: Operation Precautions
Operation Precautions Operating Environment The environmental requirements for correct operation of the machine are as follows: Temperature: 50°F to 86°F with fluctuations of no more than 18°F within an hour Humidity: 15% to 85% with fluctuations of no more than 10% within an hour Proper Use To ensure the optimum performance of the machine, follow the precautions listed below:...
Page 38: Transporting The Machine
2.2 Operation Precautions CAUTION The area around the Fusing Unit is extremely hot. § In order to reduce the risk of burns, do not touch any area other than those indicated in the manual. Be especially careful not to touch parts marked with warning labels, and their surrounding areas.
Page 39: Legal Restrictions On Copying
Legal Restrictions on Copying Certain types of documents must not be copied with the purpose or intent to pass copies of such documents off as the originals. The following is not a complete list, but is meant to be used as a guide to responsible copying.
Page 40: Before Making Copies Or Faxing
Before Making Copies or Faxing...
Page 41: Available Features
Available Features The main copy settings available with this machine are listed below. For details on their operation, refer to the pages indicated. Copies 1-sided copies (p. 4-2) 2in1 copies (p. 4-13) Note Available only with FAX3900 Zoom Ratio Reduced/Full Size/Enlarged (p.
Page 42: Components And Their Functions
3.2 Components and Their Functions Components and Their Functions Main Unit FAX2900/3900 Paper Feed Cassette (option) Capable of holding up to 500 sheets of paper. 32 MB Memory (option only for FAX3900) Increases the machine’s memory. By increasing the machine’s memory, more...
Page 43: Parts Names And Their Functions
Parts Names and Their Functions Main Unit Part Name Description Document Feeder Tray Load the originals to be scanned face up on this tray. Up to 50 document sheets can be loaded at one time. 3.3 Parts Names and Their Functions...
Page 44: Inside The Machine
3.3 Parts Names and Their Functions Part Name Description Document Feeder Opened when clearing an original that has been misfed. Cover (Doc. Feed Cover) Document Guide Plate Slide the guide plate to the size of the originals. Document Exit Tray Receives originals which have been scanned by the machine.
Page 45: Adjusting The Angle Of The Copy Tray
Adjusting the Angle of the Copy Tray Copy Tray can be adjusted to one of three angles. Adjust the tray to the angle appropriate for the desired application. 1. Normal operation (standard position) 2. When back curled paper is fed out 3.
Page 46 3.3 Parts Names and Their Functions Paper Feed Cassette (option) Part Name Description Tray2 Holds up to 500 sheets of paper.
Page 47: Control Panel
Control Panel Names of Control Panel Parts and Their Functions For FAX3900 2in1 Utility Printer Status Auto/Photo Paper Auto RX Memory TX 02/34 01/33 03/35 09/41 10/42 11/43 17/49 18/50 19/51 25/57 26/58 27/59 Error Scan 123/ABC Stop PORS WXYZ Sort Zoom Resolution...
Page 48 3.4 Control Panel For FAX2900 Utility Printer Status Auto/Photo Paper Auto RX Memory TX Error 123/ABC Stop WXYZ PORS Sort Zoom Resolution Phone Book Redial/Pause Speaker Copy Panel Reset Start Speed Dial Function...
Page 49 Part Name Description [Utility] key Press to enter Utility mode. For details, refer to “Utility Mode” on page 7-2. [Printer] key Press to enter Printer mode. For details, refer to the User Manual for the printer controller. [ ] [Ö ] key •...
Page 50 3.4 Control Panel Part Name Description [Yes] key • Press to validate the setting just made. • Press to specify the various settings. [No]/[C] key • Press to reset the number of copies to “1”. • Press to clear the various settings. •...
Page 51: Display Indications
Display Indications In Copy mode: Display Indication Description Document type Displays the document type currently specified for the image density. Zoom ratio Displays the currently specified zoom ratio. Number of copies Displays the currently specified number of copy pages and number of copy sets.
Page 52: Symbol List
3.4 Control Panel Display Indication Description Time The current time is displayed during standby. Resolution The setting resolution is displayed during standby. Symbol Indicates the currently selected mode or function settings. Memory The remaining memory is displayed during standby. Symbol list: Symbol Manual bypass Custom paper size...
Page 53: Turning The Machine On/Off Initial Mode
Turning the Machine On/Off Initial Mode Turning the Machine On/Off To turn on the machine: § Press the | (on) side of the Power Switch. To turn off the machine: § Press the 2 (off) side of the Power Switch. Note Do not turn off the machine while a print cycle is being performed, as a paper misfeed will result.
Page 54: Default Settings
3.5 Turning the Machine On/Off Initial Mode Default Settings When the machine is turned on, the Initial mode screen appears in the Display of the Control Panel. The Initial mode screen appears at the beginning of all operations. Factory default settings Number of copies: 1 Image density: TEXT Auto Zoom ratio: 100% (full size)
Page 55: Useful Functions
Useful Functions Panel Resetting Press the [Panel Reset] key to return all modes and functions (zoom ratio, number of copies, etc.) to their defaults. (All selected settings are canceled.) The [Panel Reset] key comes in handy for canceling all selected settings at one time.
Page 56: Auto Print Start
3.6 Useful Functions Auto Print Start If a document is loaded and the [Start] key is pressed during the period after the machine has been turned on but before it is ready to make print, the machine will automatically start the print cycle as soon as it completes the warm-up cycle. Auto Tray Switching If the tray runs out of paper while printing, the machine will automatically switch to a different paper source and continue printing provided that the new tray contains...
Page 57: Entering Text
Entering Text When specifying the user name or programming one-touch dial keys with the recipient name, letters, accented characters, numbers, and symbols can be entered. Key operation: 10-Key Pad: Used to enter numbers and letters, symbols. List of characters available with each key of the 10-Key Pad: 10-Key Pad Available characters* .
Page 58: Inputting Example
3.7 Entering Text Inputting Example To enter the name “NJ Office” * The cursor (_) flashes alternately with the character at its current location. Press the [123/ABC] key. Press the [6] key twice. Press the [5] key once. Press the [0] key once. Press the [6] key 3 times.
Page 59 Correcting text and input precautions To erase all entered text, press the [Panel Reset] key. To delete only part of the entered text, use the [ ] and [ cursor (_) to the character that you wish to delete, and then press the [No] key. To change an entered character, use the [ ] and [ (_) below the character that you wish to change, and then press the [No] key.
Page 60: Copy Paper
3.8 Copy Paper Copy Paper Paper Specifications The following table specifies the type and size of paper to be used with each tray together with its capacity. Tray1 Specifications Paper Type • Plain paper, recycled paper (16 lb to 24 lb) •...
Page 61: Unsuitable Paper
Unsuitable Paper The following types of paper should not be used, otherwise decreased print quality, paper misfeeds, or damage to the machine may occur. Overhead projector transparencies that have already been fed through the machine Even if the transparency is still blank, do not reuse it. Paper that has been printed on by a heat-transfer printer or an inkjet printer Paper that is either extremely thick or extremely thin Folded, curled, wrinkled, or torn paper...
Page 62: Loading Paper
3.8 Copy Paper Loading Paper While loading paper, be sure to observe the following precautions. If the paper is curled, flatten it before loading it. Do not load so much paper that the top of the stack is higher than the ▼...
Page 63 When loading envelopes, load them with the flap facing down, as shown in the illustration at the right. Note Before loading envelopes, press them down to make sure that all air is removed, and make sure that the folds of the flaps are firmly pressed, otherwise the envelopes may become wrinkled or a paper misfeed may occur.
Page 64: Loading Paper Into Tray1
3.8 Copy Paper Loading Paper into Tray1 Remove the Bypass Tray. Load the paper into the tray so that the front side of the paper (the side facing up when the package was unwrapped) faces up. Slide the paper guides against the edges of the paper.
Page 65 Note If paper with a different size or type is loaded, various settings must be specified from the “PAPER SOURCE SETUP” menu in the Utility mode. If the settings are not correctly specified, paper size error may occur. For details, refer to “Specifying the Setting for “TRAY SETTING””...
Page 66: Loading Paper Into The Bypass Tray
3.8 Copy Paper Loading Paper into the Bypass Tray Load the paper so that the front side of the paper (the side facing up when the package was unwrapped) faces up. Slide the paper guides against the edges of the paper. Note When paper is loaded into the Bypass Tray, the paper size and type must be specified, otherwise paper size error may occur.
Page 67: Loading Paper Into Tray2 (Option)
Loading Paper into Tray2 (option) Pull out the drawer for Tray2. Remove the drawer cover, and then press down on the paper- lifting plate until it locks into place. Load the paper into the drawer so that the front side of the paper (the side facing up when the package was unwrapped) faces up.
Page 68: Loading Originals
3.9 Loading Originals Loading Originals Loading Originals in the Auto Document Feeder The Auto Document Feeder automatically feeds originals one page after another so that the machine can scan the data on each page. After the machine finishes scanning the data, the Auto Document Feeder ejects the page into the Exit Tray. To ensure the best possible performance of the Auto Document Feeder, use only originals of the specified type.
Page 69: Loading Originals Into The Auto Document Feeder
Loading Originals into the Auto Document Feeder Place the stack of originals face up on the auto Document Feeder Tray. Note A maximum of 50 document pages can be loaded. Do not load so many pages that the top of the stack is higher than the t mark. Be sure to adjust the document guides so that they are against the edges of the document, otherwise the document may not be fed in straight.
Page 70: Checking The Machine Status
3.10 Checking the Machine Status 3.10 Checking the Machine Status The total number of pages printed and scanned since this machine was installed can be checked. Menu Item TOTAL PAGE TOTAL COUNT TOTAL SCAN TX PAGES RX PAGES TX/RX RESULT TX RESULT REPORT RX RESULT REPORT PRINT REPORT...
Page 71: Checking The "Total Page" Counts
Checking the “TOTAL PAGE” Counts Press the [Status] key. Press the [Yes] key. Press the [▼] and [▲] keys to check the “TOTAL COUNT”, “TOTAL SCAN”, “TX PAGES”, or “RX PAGES” values. 3-32 3.10 Checking the Machine Status...
Page 72: Checking The "Tx/Rx Result
3.10 Checking the Machine Status Checking the “TX/RX RESULT” Press the [Status] key twice. Press the [Yes] key. Press the [▲] and [▼] keys to display the desired transmission results to check them. In the transmission result screen, “TX” indicates sent faxes, and “RX”...
Page 73: To Output A Report/List
To output a report/list Press the [Status] key 3 times. Press the [Yes] key. Press the [▲] and [▼] keys to select the report/list that you wish to print, and then press the [Yes] key. After the specified report/list is printed, the main screen appears again.
Page 74: Tx Result Report
3.10 Checking the Machine Status TX Result Report The document number, recipient name, date sent, starting time of transmission, number of document pages, time required, mode, and transmission result are printed. SESSION FUNCTION DESTINATION STATION DATE 0001 AAA NEWYORK 012345678 NG PAGE:1.3.5.7 RX Result Report The document number, caller name, date received, starting time of reception,...
Page 75: Memory Image Print
Memory Image Print A reduced image of the first page of the document stored in the memory and waiting to be sent, in addition to the document number, type of operation being performed, recipient/caller name, date, time, and number of document pages are printed. One-Touch List The recipients programmed in the one-touch dial keys are printed in numerical order of the keys.
Page 76: Print Area
3.11 Print Area 3.11 Print Area Any part of the image within the area indicated below is not copied. A margin 1/4 (at full size) from the leading edge of the paper (A) A margin 1/4 (at full size) from the trailing edge of the paper (B) A margin 1/4 (at full size) on both sides of the paper (C) For details on using the machine to print from a computer when the printer controller is installed, refer to the User Manual for the printer controller.
Page 77 3.11 Print Area 3-38...
Page 78: Making Copies
Making Copies...
Page 79: Making A Basic Copy
Making a Basic Copy The following procedure describes how to place an original and make a basic copy of it. Position the original. Select the paper tray. “Selecting the Paper” on page 4-4 Specify the zoom ratio. “Specifying the Zoom Ratio” on page 4-9 Specify the image density.
Page 80 4.1 Making a Basic Copy Using the 10-Key Pad, enter the number of copies to be made. Any number from 1 to 99 can be entered. Press the [Start] key. This will start the print cycle. To stop the print cycle in mid- operation, press the [Stop] key.
Page 81: Selecting The Paper
Selecting the Paper Before making a copy, the tray containing the paper to be used must be selected. Either a paper tray can be selected or paper can be loaded into the Bypass Tray. Manual Paper Selection The tray containing the paper you want to use can be manually selected. Note The optional Paper Feed Cassette is required.
Page 82: Specifying The Size And Type On The Manual Bypass Tray
4.2 Selecting the Paper Specifying the Size and Type on the Manual Bypass Tray Position the original. Load paper into the Bypass Tray. “Loading Paper into the Bypass Tray” on page 3-27 The message shown at the right appears. Press the [No] key. Press the [ ] and [ until the desired paper type is...
Page 83 Press the [ ] and [ press the [ ] key to select the size of paper that is loaded. If “CUSTOM” is not selected, continue with step 10. If “CUSTOM” is selected, perform steps 7 through 10. Note If “OHP” was selected in step 4, the only paper sizes that can be loaded are A4 and Letter.
Page 84 4.2 Selecting the Paper Using the 10-Key Pad, enter the width (X) of the paper. To clear the entered value, press the [C] key. Note The width can range from 90 mm (3-1/2) to 216 mm (8-1/2). When entering the paper size, refer to the diagram on the right side of the screen to check which sides of the paper...
Page 85 Using the 10-Key Pad, enter the length (Y) of the paper. Note The length can range from 140 mm (5-1/2) to 356 mm (14). Enter the value by mm using the 10-key Pad. Refer to the conversion rate below. 1 inch = 25.4 mm Press the [Yes] key.
Page 86: Specifying The Zoom Ratio
4.3 Specifying the Zoom Ratio Specifying the Zoom Ratio By specifying a zoom ratio, the copy can be enlarged or reduced. Zoom Ratio Settings Zoom Ratio Settings Description Fixed ratios • The following optimum zoom ratios are available for making copies •...
Page 87: Setting The Zoom Ratio
Setting the Zoom Ratio Position the original. Press the [Zoom] key until the desired fixed ratio is selected. Each press of the [Zoom] key changes the setting. To specify a zoom ratio other than a fixed ratio, press the ] and [ ] keys until the desired zoom ratio is specified.
Page 88: Adjusting The Image Density
4.4 Adjusting the Image Density Adjusting the Image Density The image density setting can be adjusted in two broad modes, “Text” and “Photo”. Image Density Setting Text mode: The image density can be adjusted either automatically (Auto) or manually in nine steps.
Page 89 Each press of the [Auto/Photo] key changes the setting as shown at the right. If Text mode is selected, “TEXT” is displayed. If the Auto setting is selected, “[A]” is displayed. If Photo mode is selected, “PHOTO” is displayed. Note In the Photo mode, the Auto setting cannot be selected.
Page 90: Making 2In1 Copies (Available Only With Fax3900)
4.5 Making 2in1 Copies (Available only with FAX3900) Making 2in1 Copies (Available only with FAX3900) Two sheets of single-sided documents can be copied onto one double-sided sheet. Original Specifying Settings for 2in1 Copies Position the original. Note Be sure to position the documents as shown in the illustration at the right.
Page 91: Finishing Copies
Finishing Copies When printing two or more sets, each set can be printed (sorted) in order. Note In order to sort the printed pages, the Auto Document Feeder is required. Finishing methods Non-Sort: The copies are stacked on top of each other as they are made.
Page 92: Specifying Sorting
4.6 Finishing Copies Specifying Sorting Load the originals in the Auto Document Feeder. Press the [Sort] key, and then check that the indicator lights up. Note If the Sort indicator is not lit, the Non-Sort setting is selected. Make the other necessary settings. “Selecting the Paper”...
Page 93 4.6 Finishing Copies 4-16...
Page 94: Faxing
Faxing...
Page 95: Dialing
This machine is a G3 fax. Faxes can only be sent or received with this machine if the recipient’s or sender’s machine complies with the G3 standard. Dialing The recipient’s fax number can be dialed using any of the seven different dialing methods described below.
Page 96: To Fax Using One-Touch Dialing
5.1 Dialing § If the machine is connected to a PBX line and the outside line access number has been specified in the communication settings (p. 7-69), enter “#” to dial the outside line access number automatically. Press the [Start] key to begin scanning and sending the fax. To fax using one-touch dialing If one-touch dial keys have already been programmed with fax numbers, the fax number of a recipient can be specified by pressing just the corresponding one-...
Page 97 Press the [Start] key. The machine automatically starts scanning the document and sending the fax. 5.1 Dialing...
Page 98: To Fax Using Speed Dialing
5.1 Dialing To fax using speed dialing If speed dial numbers have already been programmed, the fax number of a recipient can be specified quickly by entering the corresponding speed dial number. For details on programming speed dial numbers, refer to “Specifying the Setting for “SPEED DIAL””...
Page 99: To Fax Using Group Dialing
To fax using group dialing If one-touch dial keys have already been programmed with a group of fax numbers, the fax numbers of all recipients in the group can be specified by pressing just the corresponding one-touch dial key. For details on programming one-touch dial keys with a group of fax numbers, refer to “Specifying the Setting for “GROUP DIAL””...
Page 100: To Fax Using Chain Dialing
5.1 Dialing To fax using chain dialing Faxes can be sent to recipients that are specified using any combination of one- touch dial keys, speed dial numbers, direct input using the 10-Key Pad, and the [Redial] key. As an example, the following procedure describes how to specify recipients using one-touch keys, then using the10-Key Pad.
Page 101: To Fax Using Program Dialing (Available Only With Fax3900)
To fax using program dialing (Available only with FAX3900) If one-touch dial keys have already been programmed with fax numbers and a transmission/reception function (such as timer transmission or polling reception), that function can be carried out by pressing just the corresponding one-touch dial key.
Page 102: To Fax Using The Phone Book
5.1 Dialing To fax using the phone book The phone book contains all programmed one-touch dialing and speed dialing numbers, allowing you to search for and select the recipient that you wish to send the fax to. Press the [Fax] key to enter Fax mode. Load the document into the Auto Document Feeder.
Page 103: To Search The Phone Book
To search the phone book Press the [Phone Book] key. Using the [ ] and [ select “SEARCH”, and then press the [Yes] key. A screen appears, allowing you to enter the text to be searched for. Using the 10-Key Pad, enter the first few characters of the name programmed for the desired recipient.
Page 104: To Redial The Last Recipient Called
5.1 Dialing Using the [ ] and [ select the desired recipient. If the desired recipient name does not appear in the search results, press the [No] key twice to return to the screen allowing you to enter the search text, and then try searching for different text.
Page 105: Transmission Settings
[Yes] key. Note Depending on the recipient’s fax machine, faxes sent with the Super Fine or Super Fine + Half Tone setting may not be sent as specified, and instead are sent with the Fine or Half Tone setting.
Page 106: Basic Faxing
5.3 Basic Faxing Basic Faxing To fax using the Auto Document Feeder Press the [Fax] key. The machine enters Fax mode, and the fax screen appears. Load the document to be faxed into the Auto Document Feeder. Adjust the Document Guide Plates to fit the size of the document.
Page 107: If The Memory Becomes Full While Scanning Fax Documents
(p. 6-20). About redialing: While faxing, if the recipient’s fax machine is busy or does not answer or if, for any other reason, such as a transmission error, the fax is not sent correctly, the transmission result report is printed.
Page 108: Checking Transmission Results
5.4 Checking Transmission Results Checking Transmission Results The transmission result information for a maximum of 60 sent and received documents is saved. To check the transmission result Press the [Status] key. Press the [ ] key. Press the [Yes] key. Using the [ ] and [ display the desired transmission...
Page 109 5.4 Checking Transmission Results 5-16...
Page 110: Fax Transmission/Reception Methods
Fax Transmis- sion/Reception Methods...
Page 111: Transmission Methods
Transmission Methods Memory Transmission With memory transmission, the document is scanned, then stored in the memory for transmission (queued transmission). Memory transmission is selected as the default transmission mode. For details on sending faxes through memory transmission, refer to “Basic Faxing” on page 5-13.
Page 112: Direct Transmission
6.1 Transmission Methods Using the 10-Key Pad, enter the fax number of the recipient. The fax number of a previously programmed recipient can also be specified. Refer to “Dialing” on page 5-2. Press the [Start] key to begin scanning and sending the fax. To stop the transmission, press the [Stop] key.
Page 113: Manual Transmission
This is useful, for example, if you wish to tell the recipient that you are sending a fax. Note If the recipient’s fax machine is set to receive faxes automatically (automatic reception), a beep is sounded without the recipient answering the phone;...
Page 114: To Send A Fax Manually
After finishing talking on the phone, the recipient should press the necessary key to start receiving the fax. Once the recipient’s fax machine is ready, a beep is sounded. Press the [Start] key to begin scanning and sending the fax.
Page 115: Batch Transmission
Batch Transmission Multiple documents can be stored in the memory and faxed together at a specified time. In order to use this function, the corresponding Utility mode function must first be used to program a one-touch dial key with the batch transmission settings (transmission time).
Page 116: Broadcast Transmission
FAX3900: 274 (64 for one-touch dial, 200 for speed dial, 10 for full dial) FAX2900: 142 (32 for one-touch dial, 100 for speed dial, 10 for full dial) The recipients can be specified by using the one-touch dial keys, the speed dial numbers or group dialing, by selecting from the phone book, or by entering the fax number using the 10-Key Pad.
Page 117 Specify the fax number of the recipient. Repeat the appropriate operations described below until all recipients have been specified. When using the one-touch dial keys: Press the one-touch dial key programmed with the desired fax number. Press the [Yes] key, and then specify the next recipient.
Page 118 6.1 Transmission Methods To check the recipients, press the [Yes] key. If you do not wish to check the recipients, skip to step 9. The recipients specified in step 5 are displayed in the order that they were selected. Check the recipient, and then press the [Yes] key.
Page 119: Timer Transmission
Timer Transmission A document can be scanned and stored in the memory to be sent at a specified time. This function is convenient for sending documents with a large number of pages at discounted calling times. Note The time is set for a 24-hour period. If the machine is not programmed with the current time (p.
Page 120: To Fax Using Timer Transmission
[No] key, and then enter the correct time. Specify the fax number of the recipient. Refer to “Dialing” on page 5-2. Press the [Start] key. The machine scans the document, then enters transmission standby mode. FAX3900 FAX2900 6-11...
Page 121: Mailbox Transmission
If necessary, change the “Resolution” setting (p. 5-12). Press the [Function] key. Press the [3] key from the 10-Key Pad. Press the [Function] key 3 times to select “MAILBOX TX”, and then press the [Yes] key. 6-12 6.1 Transmission Methods FAX3900 FAX2900...
Page 122 6.1 Transmission Methods Specify the recipient, and then press the [Yes] key. Refer to “Dialing” on page 5-2. A screen appears, allowing you to specify the mailbox ID. Using the 10-Key Pad, enter the mailbox ID of the recipient. Enter the mailbox ID (SUB) (20 digits or less) registered for the recipient.
Page 123: Relay Initiation Transmission
Documents can be sent from this machine (transmitting station) to another fax machine (acting as a relay station), which then sends the documents to multiple recipients (receiving stations). By relaying the documents through a fax machine closer to the remote recipients, the transmission time and cost for the transmitting station are reduced.
Page 124 If you wish to correct the password, press the [No] key, and then enter the new number. Press the [Start] key to begin scanning and sending the fax. FAX3900 FAX2900 6-15...
Page 125: Relay Broadcast Transmission (Available Only With Fax3900)
Relay Broadcast Transmission (Available only with FAX3900) If this machine is specified as a relay station, it can receive documents sent from another fax machine (transmitting station), then send the documents to multiple recipients (receiving stations) In order to fax using relay broadcast transmission, a Relay Box must first b e programmed.
Page 126: Polling Transmission
Position the document to be faxed. If necessary, change the “Resolution” setting (p. 5-12). Press the [Function] key. Press the [5] key from the 10-Key Pad. Press the [Function] key 5 times to select “POLLING TX”, and then press the [Yes] key. FAX3900 FAX2900 6-17...
Page 127 Using the [ ] and [ select either “SINGLE” or “MULTI”, and then press the [Yes] key. To allow only one polling transmission request, then delete the document from the memory, select “SINGLE”. To allow multiple polling transmission requests, select “MULTI”. The document is stored in the memory until it has been deleted.
Page 128: To Delete A Document From The Polling Transmission Setup
[Yes] key. Press the [No] key to delete from the memory the document set for polling transmission. To keep the polling transmission setting, press the [Yes] key. Press the [No] key twice to return to the main screen. FAX3900 FAX2900 6-19...
Page 129: Canceling (Deleting) A Document Queued In The Memory For Transmission
The message “NONE” appears. Using the [ ] and [ select the job to be deleted. The following types of job are displayed. MEMORY: Memory transmission B-CAST: Broadcast transmission TIMER: Timer transmission 6-20 6.1 Transmission Methods FAX3900 FAX2900 ] keys,...
Page 130 6.1 Transmission Methods M.B. TX: Mailbox transmission POLL-TX: Polling transmission POLL-RX: Polling reception RELAY: Relay initiation transmission FORWARD: Fax forwarding To check the recipient of the currently displayed transmission job, press the ] key. After checking, press the [Yes] key to return to the previous screen.
Page 131: Reception Methods
Were the long beeps not sounded by the caller’s fax machine? § If the caller’s fax machine is set to send automatically, the long beeps may not be sounded. If the telephone receiver is replaced, the fax reception is finished and the machine sounds a beep.
Page 132: Mailbox Reception
Press the [Function] key 4 times to select “PRINT MAILBOX RX”, and then press the [Yes] key. A screen appears, allowing you to enter the mailbox ID. Using the 10-Key Pad, enter the 4- digit mailbox ID, and then press the [Yes] key. FAX3900 FAX2900 6-23...
Page 133: Polling Reception
Refer to step 5 of “To fax using broadcast transmission” on page 6-7. To enter the polling ID and password, press the [ If there is no need to enter a polling ID and password, skip to step 7. 6-24 FAX3900 FAX2900 ] key. 6.2 Reception Methods...
Page 134 6.2 Reception Methods Using the 10-Key Pad, enter the polling ID (20 digits or less), and then press the [Yes] key. Using the 10-Key Pad, enter the password (20 digits or less), and then press the [Yes] key. To specify multiple fax numbers, repeat steps 3 through 6.
Page 135: Using F Codes
SID: Specify when limiting the recipient/caller with a password. SEP: Specify when calling another fax machine to receive a document set up in it (polling reception). Note The F code function is only available with fax machines that have this function as well.
Page 136: Using Mailboxes
6.3 Using F codes Using Mailboxes Specifying mailboxes: Mailboxes can be used if they are set up using the corresponding Utility mode function. Refer to “Mailbox Reception” on page 6-23. F code mailbox transmission/reception: A maximum of 5 mailboxes can be set up. Since a mailbox ID is required in order to retrieve documents received in the different mailboxes, confidential faxes can safely be sent and received.
Page 137: Specifying F Codes
Specifying F codes When sending faxes F codes can be specified when the 10-Key Pad is being used to enter the fax number of a recipient while sending a fax. Using the 10-Key Pad, enter the fax number of the recipient. Press the [ ] key, and then use the 10-Key Pad to enter the SUB.
Page 138: Using The Utility Mode
Using the Utility Mode...
Page 139: Utility Mode
Utility Mode There are fifteen menus in the Utility mode. Name MACHINE SETTING PAPER SOURCE SETUP ADMIN.MANAGEMENT COPY SETTING FAX REGISTRATION TX OPERATION RX OPERATION COMM. SETTING REPORTING INITIAL USER DATA NETWORK SETTING E-MAIL SETTING 1 E-MAIL SETTING 2 SCAN SETTING Description Used to specify settings for the machine’s operating environment.
Page 140: Specifying The Machine Settings
7.2 Specifying the Machine Settings Specifying the Machine Settings From the “MACHINE SETTING” menu, various settings for the machine’s operating environment can be specified. Refer to the following table for details on each function. Name Description AUTO PANEL RESET Whether the Auto Panel Reset function is disable or the time (0.5 min, 1 min, 2 min, 3 min, 4 min, or 5 min) until the machine is reset after finishing copying/printing or after performing the last operation can be selected.
Page 141: Selecting The "Machine Setting" Menu
Selecting the “MACHINE SETTING” menu Press the [Utility] key. “MACHINE SETTING” appears. From the 10-Key Pad, press the key ([1] to [7]) for the MACHINE SETTING function that you wish to set. The MACHINE SETTING functions are as follows: 1 AUTO PANEL RESET 2 ENERGY SAVE MODE 3 DENSITY 4 PRINT DENSITY...
Page 142: Specifying The Setting For "Auto Panel Reset
7.2 Specifying the Machine Settings Specifying the Setting for “AUTO PANEL RESET” Select the “AUTO PANEL RESET”. Refer to “Specifying the Machine Settings . Press the [ ] and [ select either “ON” or “OFF”, and then press the [Yes] key. If “OFF”...
Page 143: Specifying The Setting For "Energy Save Mode
Specifying the Setting for “ENERGY SAVE MODE” Select the “ENERGY SAVE MODE”. Refer to “Specifying the Machine Settings . Use the 10-Key Pad to specify the desired length of time until the machine enters Energy Save mode. The timer can be set between 1 min and 240 min.
Page 144: Specifying The Setting For "Density
7.2 Specifying the Machine Settings Specifying the Setting for “DENSITY ” Select the “DENSITY”. Refer to “Specifying the Machine Settings . Press the [ ] and [ select either “Mode 1” or “Mode 2”. Press the [Yes] key. ] keys to Auto/Photo...
Page 145: Specifying The Setting For "Print Density
Specifying the Setting for “PRINT DENSITY” Select the “PRINT DENSITY”. Refer to “Specifying the Machine Settings . Press the [ ] and [ select one of the seven print density levels between “LIGHT” and “DARK”. Press the [Yes] key. 7.2 Specifying the Machine Settings ] keys to Auto/Photo...
Page 146: Specifying The Setting For "Lcd Contrast
7.2 Specifying the Machine Settings Specifying the Setting for “LCD CONTRAST” Select the “LCD CONTRAST”. Refer to “Specifying the Machine Settings . Press the [ ] and [ select one of the four display contrast levels between “LIGHT” and “DARK”. Press the [Yes] key.
Page 147: Specifying The Setting For "Buzzer Volume
Specifying the Setting for “BUZZER VOLUME” Select the “BUZZER VOLUME”. Refer to “Specifying the Machine Settings . Press the [ ] and [ set the buzzer volume to “HIGH”, “LOW” or “OFF”. Press the [Yes] key. 7-10 7.2 Specifying the Machine Settings ] keys to Auto/Photo...
Page 148: Specifying The Setting For "Initial Mode
7.2 Specifying the Machine Settings Specifying the Setting for “INITIAL MODE” Select the “INITIAL MODE”. Refer to “Specifying the Machine Settings . Press the [ ] and [ select either “COPY” or “FAX”. Press the [Yes] key. ] keys to Auto/Photo 7-11...
Page 149: Setting Up The Paper Sources
Setting Up the Paper Sources From the “PAPER SOURCE SETUP” menu, the various settings for each paper tray can be specified. Name Description TRAY1 PAPER The type and size of paper loaded in Tray1 can be specified. • The manufacturer’s default settings are “PLAIN” and “Letter L”. TRAY SETTING Whether or not auto tray switching is enabled for each paper tray can be specified.
Page 150: Specifying The Setting For "Tray1 Paper
7.3 Setting Up the Paper Sources Specifying the Setting for “TRAY1 PAPER” Select the “TRAY1 PAPER”. Refer to “Setting Up the Paper Sources . Press the [ ] and [ until the type of paper loaded is selected. Press the [Yes] key. ] keys Auto/Photo 7-13...
Page 151: Specifying The Setting For "Tray Setting
Specifying the Setting for “TRAY SETTING” Select the “TRAY SETTING”. Refer to “Setting Up the Paper Sources . Press the [ ] and [ select a tray. Note A tray can be selected only if the optional Paper Feed Cassette is installed. Press the [Yes] key.
Page 152: Specifying Administrative Settings ("Admin. Management" Menu)
7.4 Specifying Administrative Settings (“ADMIN. MANAGEMENT” menu) Specifying Administrative Settings (“ADMIN. MANAGEMENT” menu) From the “ADMIN. MANAGEMENT” menu, various functions for controlling the use of the machine can be set. In order to set an “ADMIN. MANAGEMENT” function, the administrator access number must be entered. “ADMIN.
Page 153: To Select The "Admin. Management" Menu
7.4 Specifying Administrative Settings (“ADMIN. MANAGEMENT” menu) To select the “ADMIN. MANAGEMENT” menu Press the [Utility] key three times. “ADMIN. MANAGEMENT” appears. Press the [Yes] key. Using the 10-Key Pad, enter the 6- digit administrator access number, and then press the [Yes] key. If, at any time, you wish to quit setting an “ADMIN.
Page 154: Specifying The Setting For "Remote Monitor
7.4 Specifying Administrative Settings (“ADMIN. MANAGEMENT” menu) Specifying the Setting for “REMOTE MONITOR” Select the “ADMIN.MANAGEMENT”. Press the [ ] and [ select either “LIMITED” or “FULL” or “OFF”. Press the [Yes] key. If “LIMITED” or “OFF” was selected, the “ADMIN.MANAGEMENT” menu appears again.
Page 155: Specifying Copy Settings
Specifying Copy Settings When the machine is turned on or the [Panel Reset] key is pressed, the machine is automatically reset to its initial mode. By changing the default settings, you can change the initial mode. Refer to the following table for the default settings for each function.
Page 156: Selecting The "Copy Setting" Menu
7.5 Specifying Copy Settings Selecting the “COPY SETTING” menu Press the [Utility] key four times. “COPY SETTING” appears. From the 10-Key Pad, press the key ([1] to [5]) for the COPY SETTING function that you wish to set. The COPY SETTING functions are as follows: 1 PAPER PRIORITY 2 DENSITY PRIORITY 3 DENSITY LEVEL (A)
Page 157: Specifying The Setting For "Paper Priority
Specifying the Setting for “PAPER PRIORITY” Select the “COPY SETTING”. Refer to “Specifying Copy Settings . Press the [ ] and [ select either “TRAY1” or “TRAY2” Note If optional Tray2 is not installed, the bottom screen shown at the right appears.
Page 158: Specifying The Setting For "Density Priority
7.5 Specifying Copy Settings Specifying the Setting for “DENSITY PRIORITY” Select the “DENSITY PRIORITY”. Refer to “Specifying Copy Settings . Press the [ ] and [ select either “AUTO”, “MANUAL” or “PHOTO”. Press the [Yes] key. ] keys to Auto/Photo 7-21...
Page 159: Specifying The Setting For "Density Level (A)
Specifying the Setting for “DENSITY LEVEL (A)” Select the “DENSITY LEVEL (A)”. Refer to “Specifying Copy Settings . Press the [ ] and [ select one of the three print density levels between “LIGHT” and “DARK”. Press the [Yes] key. 7-22 7.5 Specifying Copy Settings ] keys to...
Page 160: Specifying The Setting For "Density Level (M)
7.5 Specifying Copy Settings Specifying the Setting for “DENSITY LEVEL (M)” Select the “DENSITY LEVEL (M)”. Refer to “Specifying Copy Settings . Press the [ ] and [ select one of the nine print density levels between “LIGHT” and “DARK”. Press the [Yes] key.
Page 161: Specifying The Setting For "Output Priority
Specifying the Setting for “OUTPUT PRIORITY” Select the “OUTPUT PRIORITY”. Refer to “Specifying Copy Settings . Press the [ ] and [ select either “NON” or “SORT”. Press the [Yes] key. 7-24 7.5 Specifying Copy Settings ] keys to Auto/Photo...
Page 162: Setting Up The Fax Registration
7.6 Setting Up the Fax Registration Setting Up the Fax Registration From the “FAX REGISTRATION” menu, various settings can be specified in order to take advantage of this machine’s many fax functions. FAX REGISTRATION Characteristic/Description ONE-TOUCH DIAL This function can be used to program one-touch dial keys with fax numbers, allowing the recipient to be specified easily and accurately without the need to manually enter the number using the 10-Key Pad.
Page 163: Selecting The "Fax Registration" Menu
If, at any time, you wish to quit programming, changing, or deleting a “FAX REGISTRATION” function, press the [No] key. When the message “STOP REGISTRATION?” appears, press the [Yes] key to quit. 7-26 7.6 Setting Up the Fax Registration FAX3900 FAX2900 Utility...
Page 164: To Program A One-Touch Dial Key
10-Key Pad. The following is the maximum of numbers that can be programmed. FAX3900: 64 FAX2900: 32 To program a one-touch dial key Select the “FAX REGISTRATION”. Refer to “Setting Up the Fax Registration .
Page 165 number, and then skip to step 10. If you wish to change the fax number, press the [No] key, and then enter the correct number. For details on F codes (SUB and SID), refer to “Using F codes . Press the [ ] key, and then use the 10-Key Pad to enter the SUB.
Page 166: To Change/Delete A Programmed One-Touch Dial Key
7.6 Setting Up the Fax Registration To change/delete a programmed one-touch dial key Select the “FAX REGISTRATION”. Refer to “Setting Up the Fax Registration . Press the [1] key from the 10-Key Pad to select “ONE-TOUCH DIAL”. Press the one-touch dial key that you wish to change or delete, and then press the [Yes] key.
Page 167 dialing or program dialing, a confirmation message appears, asking whether or not to change the corresponding settings programmed in group dialing or program dialing. If the [Yes] key is pressed, the corresponding settings programmed in group dialing or program dialing are changed. If the [No] key is pressed, the corresponding settings programmed in group dialing or program dialing are deleted.
Page 168: Specifying The Setting For "Speed Dial
10-Key Pad. The following is the maximum of numbers that can be programmed. FAX3900: 200 FAX2900: 100 To program a speed dial number Select the “FAX REGISTRATION”. Refer to “Setting Up the Fax Registration .
Page 169 and then skip to step 10. If you wish to change the fax number, press the [No] key, and then enter the correct number. For details on F codes (SUB and SID), refer to “Using F codes . Press the [ ] key, and then use the 10-Key Pad to enter the SUB.
Page 170: To Change/Delete A Programmed Speed Dial Number
7.6 Setting Up the Fax Registration To change/delete a programmed speed dial number Select the “FAX REGISTRATION”. Refer to “Setting Up the Fax Registration . Press the [2] key from the 10-Key Pad to select “SPEED DIAL”. Using the 10-Key Pad, enter the speed dial number that you wish to change or delete.
Page 171 Change the fax number, F codes (SUB and SID), and modem speed as desired. For details on making changes, refer to “Entering Text . For details on changing the F codes (SUB and SID) or modem speed, refer to p. 7-27. When you are finished making changes, press the [Yes] key.
Page 172: Specifying The Setting For "Group Dial
7.6 Setting Up the Fax Registration Specifying the Setting for “GROUP DIAL” A single one-touch dial key can be programmed with a maximum of 50 different fax numbers as one group. Programming a one-touch dial key with a group of fax numbers is convenient when documents are frequently sent to a set group of multiple recipients.
Page 173: To Change/Delete A Programmed Group Of Fax Numbers
numbers can be specified as one group. With group dialing, a one-touch dial key programmed with a group can be specified. In that case, the number of fax numbers programmed in the specified one-touch dial key (group dial key) is added. When you are finished specifying recipients, press the [Start] key.
Page 174 7.6 Setting Up the Fax Registration group name is displayed. (Continue with step 6.) If “DELETE” was selected, the group dialing settings are deleted and the “SELECT REGIST.KEY” screen appears again. If you wish to change the name of the group, enter the new name, and then press the [Yes] key.
Page 175: Specifying The Setting For "Program Dial" (Available Only With Fax3900)
Specifying the Setting for “PROGRAM DIAL” (Available only with FAX3900) If one-touch dial keys have been programmed with fax numbers and a transmission/reception function, that function can be carried out by pressing just the corresponding one-touch dial key. * This function is only available with FAX3900 Transmission/reception functions that can be programmed: Broadcast transmission Timer transmission...
Page 176: To Change/Delete A Programmed Broadcast Transmission
7.6 Setting Up the Fax Registration Follow the instructions for the selected function. “To fax using broadcast transmission “To fax using timer transmission “To fax using mailbox transmission “To fax using relay initiation transmission “To receive a fax using polling reception The settings are registered.
Page 177: To Change/Delete A Programmed Timer Transmission
displayed in order. (Continue with step 6.) If “DELETE” was selected, the program dialing settings are deleted and the “SELECT REGIST.KEY” appears again. To delete the displayed recipient, press the [No] key. To keep the displayed recipient, press the [Yes] key. The next recipient is displayed.
Page 178: To Change/Delete A Programmed Mailbox Transmission
7.6 Setting Up the Fax Registration Using the [ ] and [ select either “EDIT” or “DELETE”, and then press the [Yes] key. If “EDIT” was selected, the programmed transmission time is displayed. (Continue with step 6.) If “DELETE” was selected, the program dialing settings are deleted and the “SELECT REGIST.KEY”...
Page 179 Press the [4] key from the 10-Key Pad to select “PROGRAM DIAL”. Press the one-touch dial key ([61] through [64]) programmed with the mailbox transmission that you wish to change or delete. Press the [No] key. Using the [ ] and [ select either “EDIT”...
Page 180: To Change/Delete A Programmed Polling Reception
7.6 Setting Up the Fax Registration To change the password, press the [No] key, and then use the 10- Key Pad to enter the new password. Press the [Yes] key. Other program dialing settings can be changed. Press the [No] key to return to the “FAX REGISTRATION”...
Page 181: To Change/Delete A Programmed Relay Initiation Transmission
To delete the displayed recipient, press the [No] key. To keep the displayed recipient, press the [Yes] key. To add a recipient, in the screen containing “Fin.=START”, specify a recipient using the one-touch dial keys or the speed dial numbers, or by entering a fax number using the 10-Key Pad.
Page 182 7.6 Setting Up the Fax Registration Using the [ ] and [ select either “EDIT” or “DELETE”, and then press the [Yes] key. If “EDIT” was selected, the specified recipient is displayed. (Continue with step 6.) If “DELETE” was selected, the program dialing settings are deleted and the “SELECT REGIST.KEY”...
Page 183: Specifying The Setting For "Batch Tx
Refer to “Setting Up the Fax Registration . For FAX3900: Press the [5] key from the 10-Key Pad to select “BATCH TX”. For FAX2900: Press the [4] key from the 10-Key Pad to select “BATCH TX”. Press the one-touch dial key...
Page 184: To Change The Batch Transmission Setting
7.6 Setting Up the Fax Registration dialing, program dialing, or not registered fax number, or not programmed at all? § An error message appears. Using the 10-Key Pad, enter the desired transmission time, and then press the [Yes] key. Press the [No] key to return to the “FAX REGISTRATION”...
Page 185 For FAX3900: Press the [5] key from the 10-Key Pad, to select “BATCH TX”. For FAX2900: Press the [4] key from the 10-Key Pad, to select “BATCH TX Press the one-touch dial key programmed with the batch transmission setting that you wish to change.
Page 186: To Delete The Batch Transmission Setting
Refer to “Setting Up the Fax Registration . For FAX3900: Press the [5] key from the 10-Key Pad, to select “BATCH TX”. For FAX2900: Press the [4] key from the 10-Key Pad, to select “BATCH TX Press the one-touch dial key...
Page 187: Specifying The Setting For "Mailbox
Refer to “Setting Up the Fax Registration . For FAX3900: Press the [6] key from the 10-Key Pad to select “MAILBOX”. For FAX2900: Press the [5] key from the 10-Key Pad to select “MAILBOX”. Using the 10-Key Pad, enter the mailbox number.
Page 188: To Delete A Mailbox
Refer to “Selecting the “FAX REGISTRATION” menu . For FAX3900: Press the [6] key from the 10-Key Pad to select “MAILBOX”. For FAX2900: Press the [5] key from the 10-Key Pad to select “MAILBOX”. Using the 10-Key Pad, enter the number of the mailbox that you wish to delete.
Page 189 Using the 10-Key Pad, enter the 4- digit mailbox ID, and then press the [Yes] key. If you wish to change the ID, press the [No] key, and then enter the new number. The specified mailbox is deleted. Press the [Panel Reset] key. The main screen appears again.
Page 190: Specifying The Setting For " Relay Box" (Available Only With Fax3900)
7.6 Setting Up the Fax Registration Specifying the Setting for “ RELAY BOX” (Available only with FAX3900) Relay Box IDs must first be specified in order to receive faxes with mailbox reception only if the mailbox ID sent by the caller matches the mailbox ID set on this machine.
Page 191: To Delete A Relay Box
To delete a Relay Box Select the “FAX REGISTRATION”. Refer to “Setting Up the Fax Registration . For FAX3900: Press the [7] key from the 10-Key Pad to select “RELAY BOX”. Using the 10-Key Pad, enter the number of the Relay Box that you wish to delete.
Page 192: Setting Up The Transmission
7.7 Setting Up the Transmission Setting Up the Transmission From the “TX OPERATION” menu, various functions for sending faxes can be set. TX OPERATION Characteristic/Description SCAN CONTRAST This function can be used to set the default scanning contrast level to one of five settings between “LIGHT”...
Page 193: Specifying The Setting For "Scan Contrast
If, at any time, you wish to quit setting a “TX OPERATION” function, press the [No] key. When the message “STOP SETTING?” appears, press the [Yes] key to quit. Specifying the Setting for “SCAN CONTRAST” Select the “TX OPERATION”. Refer to “Selecting the “TX OPERATION” menu . Press the [1] key from the 10-Key Pad to select “SCAN CONTRAST”.
Page 194: Specifying Setting For "Default Tx
7.7 Setting Up the Transmission Using t the [ ] and [ select the desired resolution setting, and then press the [Yes] key. The resolution settings appear as follows. STD: Standard FINE: Fine S/F: Super Fine H/T: Half Tone If “H/T” was selected, a screen appears, allowing you to make a detailed setting. (Continue with step 4.) If any setting other than “H/T”...
Page 195: Specifying The Setting For "Header
Specifying the Setting for “HEADER” Select the “TX OPERATION”. Refer to “Selecting the “TX OPERATION” menu . Press the [4] key from the 10-Key Pad to select “HEADER”. Using the [ ] and [ select either “ON” or “OFF”, and then press the [Yes] key.
Page 196: Setting Up The Reception
7.8 Setting Up the Reception Setting Up the Reception From the “RX OPERATION” menu, various functions for receiving faxes can be set. RX OPERATION Characteristic/Description MEMORY RX MODE This function can be used to set whether to allow (“ON”) memory reception or not (“OFF”).
Page 197: Selecting The "Rx Operation" Menu
Selecting the “RX OPERATION” menu Press the [Utility] key seven times. “RX OPERATION” appears. From the 10-Key Pad, press the key ([1] through [9]) for the “RX OPERATION” function that you wish to set. The “RX OPERATION” functions are as follows: 1 MEMORY RX MODE 2 NO.
Page 198: Specifying The Setting For "Memory Rx Mode
7.8 Setting Up the Reception Specifying the Setting for “MEMORY RX MODE” Select the “RX OPERATION”. Refer to “Selecting the “RX OPERATION” menu . Press the [1] key from the 10-Key Pad to select “MEMORY RX MODE”. Using the [ ] and [ select “ON”, and then press the [Yes] key.
Page 199 Using the 10-Key Pad, enter the time for memory reception to end, and then press the [Yes] key. Using the 10-Key Pad, enter the 4- digit password used to cancel memory reception, and then press the [Yes] key. If no password is to be specified, press the [Yes] key without entering anything.
Page 200: To Cancel Memory Reception
7.8 Setting Up the Reception To cancel memory reception Memory reception is automatically canceled at the specified ending time, and the received documents are printed. If no ending time has been set or if you wish to cancel memory reception before the ending time, follow the procedure described below.
Page 201: Specifying The Setting For "No.of Rings
Specifying the Setting for “NO.of RINGS” Select the “RX OPERATION”. Refer to “Selecting the “RX OPERATION” menu . Press the [2] key from the 10-Key Pad to select “NO.of RINGS”. Using the 10-Key Pad, enter the desired number of rings, and then press the [Yes] key.
Page 202: Specifying The Setting For "Rx Print
7.8 Setting Up the Reception Specifying the Setting for “RX PRINT” Select the “RX OPERATION”. Refer to “Selecting the “RX OPERATION” menu . Press the [4] key from the 10-Key Pad to select “RX PRINT”. Using the [ ] and [ select either “MEMORY RX”...
Page 203: Specifying The Setting For "Forward
Specifying the Setting for “FORWARD” Select the “RX OPERATION”. Refer to “Selecting the “RX OPERATION” menu . Press the [6] key from the 10-Key Pad to select “FORWARD”. Using the [ ] and [ select “ON”, “ON(PRINT)” or “OFF”, and then press the [Yes] key.
Page 204: Specifying The Setting For "Footer
7.8 Setting Up the Reception Specifying the Setting for “FOOTER” Select the “RX OPERATION”. Refer to “Selecting the “RX OPERATION” menu . Press the [7] key from the 10-Key Pad to select “FOOTER”. Using the [ ] and [ select either “ON” or “OFF”, and then press the [Yes] key.
Page 205: Specifying The Setting For "Closed Network
Specifying the Setting for “CLOSED NETWORK” Select the “CLOSED NETWORK”. Refer to “Selecting the “RX OPERATION” menu . Press the [9] key from the 10-Key Pad to select “CLOSED NETWORK”. Using the [ ] and [ [Yes] key. The “RX OPERATION” menu appears again. 7-68 7.8 Setting Up the Reception ] keys, select either “ON”...
Page 206: Setting Up The Communication
7.9 Setting Up the Communication Setting Up the Communication From the “COMM.SETTING” menu, various functions are available for specifying communication settings. COMM.SETTING Characteristic/Description TONE/PULSE This function can be used to specify the dialing system. If this function is not correctly set to the type of dialing system used, faxes cannot be sent. Select the correct setting after checking which type of dialing system is used by your telephone line.
Page 207: Specifying The Setting For "Line Monitor
Using the [ ] and [ select either “TONE” (for tone dialing) or “PULSE” (for pulse dialing), and then press the [Yes] key. If “PULSE” was selected, select either “10pps” or “20pps”, and then press the [Yes] key. The “COMM.SETTING” menu appears again.
Page 208: Specifying The Setting For "Pstn/Pbx
7.9 Setting Up the Communication Specifying the Setting for “PSTN/PBX” The connected wiring system can be set to either PSTN (Public Switched Telephone Network) or PBX (Private Branch Exchange). For a PBX system, the outside line access number (or extension number) must be specified.
Page 209: Setting Up The Report Output
7.10 Setting Up the Report Output From the “REPORTING” menu, various functions are available for specifying which reports are automatically printed. REPORTING Characteristic/Description ACTIVITY REPORT Every 60 transmissions/receptions, a report can be printed to show the results of the transmissions/receptions. This function can be used to set whether the report is printed automatically when the 60th transmission/ reception is reached.
Page 210: Specifying The Setting For "Activity Report
7.10 Setting Up the Report Output If, at any time, you wish to quit setting/changing a “REPORTING” function, press the [No] key. When the message “STOP SETTING?” appears, press the [Yes] key to quit. To exit the “REPORTING” menu, press the [Panel Reset] key. The main screen appears again.
Page 211: Specifying The Setting For "Tx Result Report
Specifying the Setting for “TX RESULT REPORT” Select the “REPORTING”. Refer to “Selecting the “REPORTING” menu . Press the [3] key from the 10-Key Pad to select “TX RESULT REPORT”. Using the [ ] and [ select either “ON” or “OFF”, and then press the [Yes] key.
Page 212: Specifying Initial User Data
7.11 Specifying Initial User Data 7.11 Specifying Initial User Data Various settings for the machine’s user data can be specified. Refer to the following table for details on each function. Name Description DATE&TIME The date and time for the machine can be specified. USER FAX NO.
Page 213: Specifying The Setting For "Date&Time
Specifying the Setting for “DATE&TIME” Select “DATE&TIME”. Refer to “Selecting the “INITIAL USER DATA” menu . Using the 10-Key Pad, enter the current time and date. Enter the settings in the following order: hours, minutes, year, month, and day. Press the [Yes] key to display the time zone setting. Press the [▲] and [▼] keys to select the appropriate time zone.
Page 214: Specifying The Setting For "User Fax No
7.11 Specifying Initial User Data Specifying the Setting for “USER FAX NO.” Select the “USER FAX NO.” Refer to “Selecting the “INITIAL USER DATA” menu . Using the 10-Key Pad, enter the fax number. Press the [Yes] key. 7-77...
Page 215: Specifying The Setting For "User Name
Specifying the Setting for “USER NAME” Select the “USER NAME”. Refer to “Selecting the “INITIAL USER DATA” menu . Using the 10-Key Pad, enter the user name for the machine. Each press of the [123/ABC] key switches the input mode between numbers and letters.
Page 216: When A Message Appears
When a Message Appears...
Page 217: When The Message "Paper Empty" Appears
When the Message “PAPER EMPTY” Appears When the currently selected paper tray runs out of paper, the message shown below appears, and printing cannot continue. Check the paper tray that has run out of paper, and then supply paper according to the following procedures.
Page 218: Loading Paper Into Tray1
8.1 When the Message “PAPER EMPTY” Appears Loading Paper into Tray1 Remove the Bypass Tray. Load the paper in the tray so that the front side of the paper (the side facing up when the package was unwrapped) faces up. Attach the Bypass Tray in its original position.
Page 219: Loading Paper Into Tray2 (Option)
Loading Paper into Tray2 (option) Pull out the drawer for Tray2. Remove the drawer cover, and then press down on the paper- lifting plate until it locks into place. Load the paper into the drawer so that the front side of the paper (the side facing up when the package was unwrapped) faces up.
Page 220: When The Message "Toner Empty" Appears
8.2 When the Message “TONER EMPTY” Appears When the Message “TONER EMPTY” Appears When toner is about to run out, the message shown below appears, indicating that the toner is almost empty. When this message appears, replace the Toner Cartridge with a new one as soon as possible. If you continue making copies/ printing, the toner will be emptied, and copies/printing can no longer be made.
Page 221: Replacing The Toner Cartridge
Note Use only the toner that has been manufactured specifically for this machine. Never use any other types of toner, as a malfunction could result. For details, contact your service representative. Before replacing the Toner Cartridge, check that it is of the following type. Toner Cartridge TN-110 and 4519-322 on its box Do not use a Toner Cartridge of a different type.
Page 222 8.2 When the Message “TONER EMPTY” Appears Move the lever in the direction of the arrow to release the lock. Remove the Toner Cartridge from the Drum Cartridge. Note When separating the Toner Cartridge from the Drum Cartridge, do not tilt the cartridge, otherwise toner may spill.
Page 223 Shake the new Toner Cartridge well. Remove the protective cover from the Toner Cartridge. Note Do not touch the developer roller, otherwise decreased image quality may result. 8.2 When the Message “TONER EMPTY” Appears Developer roller...
Page 224 8.2 When the Message “TONER EMPTY” Appears Align the blue parts of the Drum Cartridge and Toner Cartridge, and then attach them together. Align the tab on the Imaging Cartridge with the rail in the machine, and then install the cartridge.
Page 225: When The Message "Paper Misfeed" Appears
When the Message “PAPER MISFEED” Appears If the message shown below appears during printing and the machine stops operating, a paper misfeed has occurred in a paper tray. Follow the procedure described below to clear the misfed paper. Clearing a Paper Misfeed in the Paper Trays Remove all paper from the Bypass Tray.
Page 226 8.3 When the Message “PAPER MISFEED” Appears Remove all paper from Tray1. Note Do not reuse paper that has been misfed. Reload the paper stack in the tray. Attach the tray removed in step 2. Reload the paper removed in step 1. Remove the cover of optional Tray2, and then pull out the drawer.
Page 227 Reload the paper stack into the drawer, and then slide the drawer back into the Paper Feed Cassette. Open, then close the Front Cover. 8-12 8.3 When the Message “PAPER MISFEED” Appears...
Page 228: When The Message "Paper Jam" Appears
8.4 When the Message “PAPER JAM” Appears When the Message “PAPER JAM” Appears If the message shown below appears during printing and the machine stops operating, a paper misfeed has occurred in the machine. Follow the procedure described below to clear the misfed paper. CAUTION The area around the Fusing Unit is extremely hot.
Page 229 Remove the Imaging Cartridge. Grab both sides of the paper, and then pull it out upward. Grab both sides of the paper, and then carefully pull out the sheet of paper. 8-14 8.4 When the Message “PAPER JAM” Appears...
Page 230 8.4 When the Message “PAPER JAM” Appears Grab both sides of the paper, and then carefully pull the sheet of paper straight upward. Grab both sides of the paper, and then carefully pull the sheet of paper straight downward. Align the tab on the Imaging Cartridge with the rail in the machine, and then install the cartridge.
Page 231: When The Message "Original Doc. Jam" Appears
8.5 When the Message “ORIGINAL DOC. JAM” Appears When the Message “ORIGINAL DOC. JAM” Appears If the message shown below appears while scanning an original with the Auto Document Feeder and the machine stops operating, a paper misfeed has occurred in the Auto Document Feeder.
Page 232 8.5 When the Message “ORIGINAL DOC. JAM” Appears Close the Document Feeder Cover. Load the documents removed in step 2 back into the tray. Note Replace the document page that was misfed, according to the page number indicated in the Display. If “ORIGINAL DOC.JAM”...
Page 233: When The Message "Paper Size Error" Appears
8.6 When the Message “PAPER SIZE ERROR” Appears When the Message “PAPER SIZE ERROR” Appears If the paper size specified for a paper tray differs from the size of the paper loaded in the tray, the message shown below appears when paper is fed from that tray. Check the message for the paper tray and the paper size to be fed, and then load paper according to the corresponding procedure described below.
Page 234 8.6 When the Message “PAPER SIZE ERROR” Appears Remove the Bypass Tray, and then remove all paper from Tray1. Load the desired paper into the tray. Try performing the print cycle again. 8-19...
Page 235: For The Bypass Tray
8.6 When the Message “PAPER SIZE ERROR” Appears For the Bypass Tray Remove all paper from the Bypass Tray. Load the desired paper into the tray. Select the setting for the type and size of paper that is loaded. “Specifying the Size and Type on the Manual Bypass Tray”...
Page 236: When The Message "Machine Trouble" Appears
8.7 When the Message “MACHINE TROUBLE” Appears When the Message “MACHINE TROUBLE” Appears If the message shown below appears, some machine malfunction has occurred. Contact your service representative. Note When contacting the service representative, be sure to inform them of the machine code (error code: C####) that was indicated.
Page 237: What Does Each Message Mean
What Does Each Message Mean? Message *REMOVE PAPER IN BYPASS TRAY* FRONT COVER OPEN CLOSE FRONT COVER DOC.FEED COVER OPEN CLOSE DOC.FEED COVER MEMORY FULL PRESS ANY KEY MACHINE TROUBLE SERVICE CALL (C####) FUSER COVER OPEN CLOSE FUSER COVER PAPER JAM OPEN FRONT COVER NO SUITABLE PAPER LOAD PAPER (LT)
Page 238: What Does Each Message Mean
• Communication is not possible because of a problem with the recipient/ caller’s fax machine. All redial attempts failed Check the condition of the because either the recipient’s recipient’s line, and then try line is busy or there was no sending the fax again.
Page 239 Internet Fax/Network Scan Message *COMM.ERROR* XXXX Server *CANNOT CONNECT* XXXX Server *CANNOT GET IP* XXXX Server *DISCONNECT* XXXX Server *WRONG PASSWORD* XXXX Server *RECEIVE WRONG DATA* XXXX Server *MEM.FULL/TX CANCEL* *MEM.FULL/RX CANCEL* XXXX Server *FILE FULL/TX CANCEL* *FILE FULL/RX CANCEL* XXXX Server *SERVER MEMORY FULL* SMTP Server...
Page 240 8.8 What Does Each Message Mean? Message *FTP SERVER ERROR* MACHINE TROUBLE SERVICE CALL (C####) Cause Remedy While uploading scan data, Consult your network the data could not be administrator for details. correctly uploaded to the FTP server. Some problem occurred in Turn the copier off, then on again.
Page 241: When Incorrect Copies Are Produced
When Incorrect Copies Are Produced * If the problem is not corrected even after the operations described above are performed, contact your service representative. Symptom The printed output is too light. The printed output is too dark. The printed output is blurry. 8-26 8.9 When Incorrect Copies Are Produced Possible Cause...
Page 242 8.9 When Incorrect Copies Are Produced Symptom The printed output has dark specks or spots. The printed output has lines. The printed output on the copy is not aligned properly. The printed page is curled. The edge of the printed output is dirty.
Page 243: The Machine Is Not Functioning As Designed
8.10 The machine is not functioning as designed Symptom Nothing appears in the Display. The [Start] key indicator does not light up green. The machine does not operate when it is turned on. * If the problem is not corrected even after the operations described are performed, turn off the machine, unplug its power cord, and then contact the service representative.
Page 244: When Faxing Is Not Performed Correctly
A number specifically for Check the number. telephone calls is being dialed. There is a problem with the Contact the recipient. recipient’s fax machine (it is out of paper, it is not set to receive faxes automatically, it is turned off, etc.). 8-29...
Page 245: Faxes Cannot Be Received
Faxes Cannot Be Received Symptom The received fax is not clear. The received fax is blank. Faxes cannot be received automatically. Black streaks appear through the print. 8-30 8.11 When Faxing Is Not Performed Correctly Possible Cause Remedy Paper that does not meet Use paper that meets specifications has been specifications.
Page 246: Calls Cannot Be Sent
8.11 When Faxing Is Not Performed Correctly Calls Cannot Be Sent Symptom Nothing can be heard from the connected telephone. After dialing, the ringing cannot be heard. After the [Speaker] key is pressed, it is difficult to hear the recipient/caller’s voice. The ringing of the telephone is too low (loud).
Page 247 8.11 When Faxing Is Not Performed Correctly 8-32...
Page 248: Internet Fax & Network Scan
Internet Fax & Network Scan...
Page 249: Overview
Overview The scan function makes it possible to easily convert paper documents into electronic documents and file them in an electronic filing system that makes it much easier to access the information. The scanned images (scan data) are stored in TIFF or PDF format and can be sent to computers over a network.
Page 250: Scan To E-Mail
9.1 Overview 9.1.1 Scan to E-mail The scan data is sent as TIFF or PDF e-mail attachments to other computers on the network or over the Internet. This method requires that a mail server is available over the network. Mail server Client computer Intranet Mail server...
Page 251 9.1.2 Scan to Server (FTP) The scan data is uploaded, as TIFF or PDF files, to the specified folder on an FTP server. This method requires that an FTP server is available over the network. The scan data can also be sent to an FTP server that is accessed via a proxy server.
Page 252 9.1 Overview In addition, the system can be set to send, to as many as 10 specified recipients, notification of the FTP server address where the data was uploaded. FTP server FTP server Internet Client computer Intranet Internet Mail server Client computer...
Page 253: Internet Faxing
9.1.3 Internet Faxing Unlike fax machines that use telephone lines, Internet faxing can send and receive fax images over the Internet. The Internet fax service uses Internet e-mail services to send and receive fax images. An Internet fax service transmits scanned images as TIFF-F files attached to e- mail messages and sends them to the desired Internet fax destination.
Page 254: System Requirements
9.1 Overview 9.1.4 System Requirements The following system environment is required in order to use the Internet fax or network scanning functions. TCP/IP connections must be enabled in order to use the Internet fax or network scanning functions. The copier must be connected to a phone line in order to use functions that require a phone line connection.
Page 255: Names Of Control Panel Parts And Their Functions
9.1.5 Control Panel Parts and Their Functions 9.1.5.1 Names of Control Panel Parts and Their Functions Auto RX Memory TX 02/34 01/33 03/35 09/41 10/42 11/43 17/49 18/50 19/51 25/57 26/58 27/59 Part Name [Resolution] key [Phone Book] key [Function] key [Speed Dial] key One-touch dial keys Resolution...
Page 256 9.1 Overview Utility Printer Status Auto/Photo Paper Part Name keys [Auto/Photo] key [Utility] key Display [Status] key keys [Zoom] key [No/C] (clear) key [Yes] key “Error” indicator 10-key pad [Stop] key [123/ABC] key [Scan] key [Start] key [Fax] key [Panel Reset] key Error WXYZ PORS...
Page 257: Using Pagescope Light
9.1.6 Using PageScope Light 9.1.6.1 What is PageScope Light? PageScope Light is a device control utility program provided by the HTTP server built into the network interface card. This utility can be used with a Web browser as an interface for remotely controlling the copier and network interface card.
Page 258: Accessing Pagescope Light
9.1 Overview SMTP settings POP3 settings FTP settings Adding/changing e-mail addresses One-touch dial settings Speed dial settings Group dial settings Speed dial settings (adding an FTP server address) 9.1.6.2 System Requirements PageScope Light can be used in the following system environments. Operating system Browser 9.1.6.3 Accessing PageScope Light...
Page 259: About The Screen Layout
9.1.6.5 About the Screen Layout The following screen appears when you access PageScope Light. Note Screen images used in this chapter may differ from the actual screen display. They are also subject to change without notice. Status display Administrator password Tabs Menu Information/setting...
Page 260: Logging In As An Administrator
9.1 Overview 9.1.6.6 Logging In as an Administrator Some of the settings available in PageScope Light can only be changed by an administrator. These settings are only displayed when you log in to the Administrator mode. Logging in to Administrator Mode Enter the administrator password in the “Admin Password”...
Page 261: Getting Ready
Getting Ready 9.2.1 Connecting to a LAN Network This copier supports the TCP/IP protocol used by LAN networks. In order to use this protocol, the copier must be connected to the LAN with a network cable. Connecting the LAN Cable Insert the connector on one end of the LAN cable into the network port (marked LAN) on the back of the copier, and the connector on the other end to an open port on a network hub.
Page 262 9.2 Getting Ready About the LEDs Green LED : This LED ligths up when the network cable is connected correctly. If this LED is not lit, check the connection again, even if the copier appears to be connected correctly. If this LED is not lit when both ends are connected correctly, the network cable may be damaged.
Page 263: Specifying The Network Settings
9.2.2 Specifying the Network Settings Depending on the network environment in which the copier is located, there may be some restrictions on the network functions that the copier can use. Specify the network settings to suit the functions and environment required for your configuration. The network settings can be specified from the control panel of the copier or using the Administrator mode of PageScope Light.
Page 264 9.2 Getting Ready Function Description This function is CONFIG. used to enable or disable the DNS (Domain Name System) setting. If there is a DNS server on your network, enter the IP address of the DNS server. *If the DNS server is located within your local network, select “ENABLE”.
Page 265 Function Description SMTP PORT This function is used to specify the port number (1 to 65535) for the SMTP server. Consult your network administrator for details. SMTP This function is TIMEOUT used to specify the length of time (in seconds) until the connection to the SMTP server times out.
Page 266 9.2 Getting Ready Function Description POP3 This function is TIMEOUT used to specify the length of time (in seconds) until the connection to the POP3 server times out. (30 to 300 seconds) POP3 This function is ACCOUNT used to specify the account name used to log in to the POP3 server.
Page 267 Function Description HEADER This function is PRINT used to specify whether or not to print header information when printing e-mail messages that have been received. PageScope Light Administrator mode: “Scan” tab File This function is Destination used to specify the FTP destination used for Scan to Server (FTP)
Page 268: Network Settings
9.2 Getting Ready Function Description PageScope Light Administrator mode: “Network” tab This function is Configuration used to specify the IP address for the proxy server of an FTP server. *1: Required if notification of the URL is sent by e-mail. *2: Can also be assigned automatically by the DHCP server.
Page 269: Setting The Ip Address
Setting the IP Address Press the [Utility] key. The Utility mode menu appears. Press the “NETWORK SETTING” appears. Press the [1] key on the 10-key pad to select “IP ADDRESS”. Press the select “AUTO” or “SPECIFY”, and then press the [Yes] key. If “AUTO”...
Page 270: Specifying The Subnet Mask
9.2 Getting Ready Press the [Yes] key. The NETWORK SETTING screen appears. To register settings in the copier, the copier must be turned off, then on again. While the NETWORK SETTING screen is displayed, press the [No] key or [Panel Reset] key so that the message “PLEASE RE-START POWER SUPPLY OFF/ON”...
Page 271: Specifying The Dns Configuration
Using the 10-key pad, enter the IP address for the gateway. The illustration at the right is an example of a gateway address. Consult your network administrator for details about these settings. Press the [Yes] key. The NETWORK SETTING screen appears. To register settings in the copier, the copier must be turned off, then on again.
Page 272: Specifying The E-Mail Settings ("E-Mail Setting 1" Menu)
9.2 Getting Ready Set the power switch for the copier to “2”, then “1” to restart the copier. Specifying the E-mail Settings (“E-MAIL SETTING 1” Menu) The settings for the E-MAIL SETTING 1 functions are specified from the “E-MAIL SETTING 1” menu in Utility mode. This section describes how to specify settings for the following functions.
Page 273: Registering The E-Mail Address Of The Sender
Press the [Yes] key. The E-MAIL SETTING 1 screen appears again. Registering the E-mail Address of the Sender From the “E-MAIL SETTING 1” menu in the Utility mode, press the [2] key on the 10-key pad to select “E-MAIL ADDRESS”. Enter the e-mail address of the copier.
Page 274: Specifying The Smtp Port Number ("Smtp Port No." Function)
9.2 Getting Ready Specifying the SMTP Port Number (“SMTP PORT NO.” Function) From the “E-MAIL SETTING 1” menu in the Utility mode, press the [4] key on the 10-key pad to select “SMTP PORT NO.”. Enter the port number for the SMTP server.
Page 275: Specifying The Default Subject Line
Press the select “ON” or “OFF”, and then press the [Yes] key. The E-MAIL SETTING 1 screen appears again. Specifying the Default Subject Line From the “E-MAIL SETTING 1” menu in the Utility mode, press the [7] key on the 10-key pad to select “DEFAULT SUBJECT”.
Page 276: Specifying The Pop3 Server Address
9.2 Getting Ready Specifying the POP3 Server Address Press the [Utility] key. The Utility mode menu appears. Press the MAIL SETTING 2” appears. Press the [1] key on the 10-key pad to select “POP3 SERVER”. Enter the IP address or host name of the POP3 server.
Page 277: Specifying The Timeout Period For The Pop3 Server ("Pop3 Timeout" Function)
Press the [Yes] key. The E-MAIL SETTING 2 screen appears again. Specifying the Timeout Period for the POP3 Server (“POP3 TIMEOUT” Function) From the “E-MAIL SETTING 2” menu in the Utility mode, press the [3] key on the 10-key pad to select “POP3 TIMEOUT”.
Page 278: Setting Up Auto Reception
9.2 Getting Ready Enter the password. For information on entering text, refer to “Entering Text” on page 3-18. Up to 32 characters can be entered for the password. The illustration at the right is an example of the password display. Consult your network administrator for details about this setting.
Page 279: Specifying The Address For Result Notifications
Specifying the Address for Result Notifications From the “E-MAIL SETTING 2” menu in the Utility mode, press the [7] key on the 10-key pad to select “REPLY ADDRESS”. Enter the e-mail address to which error notifications should be sent. For information on entering text, refer to “Entering Text”...
Page 280: Network" Tab
9.2 Getting Ready clicked after the message “Update Successful” has appeared. “Network” tab TCP/IP Configuration TCP/IP Configuration Function IP Address Subnet Mask Default Gateway Base Port Number DHCP (APIPA) IP Address in NVRAM Description This function is used to specify the IP address for the copier. This function is used to specify the subnet mask used to access the network.
Page 281: Smtp & Pop3 Configuration
SMTP & POP3 Configuration SMTP Configuration Function SMTP Server Address Default Subject for E-mail Attachment Sender name E-Mail Address Port Number 9-34 Description This function is used to specify the IP address or host name of an SMTP server. (Up to 64 characters) This function is used to specify the default subject line when sending scan data as an e-mail attachment.
Page 282 9.2 Getting Ready Function SMTP Server Timeout POP3 Configuration Function POP3 Server Address Account Name Password Auto Reception Reply Address Port Number POP3 Server Timeout Description This function is used to specify the length of time (30 to 300 seconds) until the connection to the SMTP server times out. Description This function is used to specify the IP address or host name of the POP3 server.
Page 283: Ftp & Dns Configuration
FTP & DNS Configuration FTP Configuration Function FTP Proxy Server Address Remote Port Number of Proxy FTP Server Timeout DNS Configuration Function Enable DNS Server DNS Server Address 9-36 Description This function is used to specify the IP address for the proxy server used to access an FTP server.
Page 284: Fax" Tab
9.2 Getting Ready “Fax” Tab Fax Configuration E-mail Setting Function Text Insert Header Print Description This function is used to specify whether or not text explaining that an image has been attached to the e-mail message is inserted when scan data is sent as an e-mail attachment. This function is used to specify whether or not to print header information when printing e-mail messages that have been received.
Page 285: Scan" Tab
“Scan” Tab File Destination Setting Click a number in the File Destination List that does not contain a file destination. 9-38 9.2 Getting Ready...
Page 286 9.2 Getting Ready Enter the necessary information in the screen that appears. File Destination Function Destination Name FTP Server Address Directory Use Proxy Description This function is used to specify the name for the file destination. (Up to 20 characters) This function is used to specify the host name or IP address of the FTP site where the scan data will be sent.
Page 287 Function Remote Port Number E-Mail Notification Function Enable Notification Notification Address Account Information Function Anonymous Private Site 9-40 Description This function is used to specify the remote port number (1 to 65535) if a proxy server is not being used. Normally, port number 21 is used.
Page 288: Adding Destinations
9.2 Getting Ready 9.2.3 Adding Destinations Destinations can be added using the control panel of the copier or using PageScope Light. E-mail Address Location 2: Can be added; -: Cannot be added One-touch dial key Speed dial number Group dial key Speed dial number (with FTP server addresses added)
Page 289: Using The Control Panel To Add Addresses
9.2.3.1 Using the Control Panel To Add Addresses Specifying the Settings for a One-Touch Dial Key Press the [Utility] key. Press the key until “FAX REGISTRATION” appears. Press the [1] key on the 10-key pad to select “ONE-TOUCH DIAL”. Press the one-touch dial key where you wish to add an address, and then press the [Yes] key.
Page 290: Specifying The Settings For A Speed Dial Number
9.2 Getting Ready Press the [No] key when you have finished adding addresses. The FAX REGISTRATION screen appears again. Specifying the Settings for a Speed Dial Number Press the [Utility] key. Press the key until “FAX REGISTRATION” appears. Press the [2] key on the 10-key pad to select “SPEED DIAL”.
Page 291: Specifying The Settings For A Group Dial Key
Press the [No] key when you have finished adding addresses. The FAX REGISTRATION screen appears again. Specifying the Settings for a Group Dial Key Press the [Utility] key. Press the key until “FAX REGISTRATION” appears. Press the [3] key on the 10-key pad to select “GROUP DIAL”.
Page 292 9.2 Getting Ready the destinations have been specified. Up to 50 destinations can be specified for one group dial key. In this case, the numbers of destinations specified for the one- touch (group dial) key are added to the current group dial setting. Press the [Start] key when you have finished adding addresses.
Page 293: Specifying Settings For One-Touch Dialing
9.2.3.2 Using PageScope Light To Add Addresses Specifying Settings for One-Touch Dialing From the page displayed by clicking “One-Touch Dial Setting” in the menu on the “Fax” tab, one-touch dial settings for the copier can be specified. Name Destination address Timer Transmission [Delete] button 9-46...
Page 294: Adding A New One-Touch Dial Setting
9.2 Getting Ready Adding a New One-Touch Dial Setting Start up PageScope Light. Refer to “Using PageScope Light” on page 9-10. Log in to the Administrator mode. Click “One-Touch Dial Setting” in the menu on the “Fax” tab. Click the one-touch dial number where you wish to add a new address. The One-Touch Registration screen appears.
Page 295: Specifying The Settings For Speed Dialing
Specifying the Settings for Speed Dialing From the page displayed by clicking “Speed Dial Setting” in the menu on the “Fax” tab, speed dial settings for the copier can be specified. Index Destination Name Destination address [Delete] button 9-48 Click an index number to jump to the corresponding speed dial list.
Page 296: Adding A New Speed Dial Setting
9.2 Getting Ready Adding a New Speed Dial Setting Start up PageScope Light. Refer to “Using PageScope Light” on page 9-10. Log in to the Administrator mode. Click “Speed Dial Setting” in the menu on the “Fax” tab. Click the speed dial number where you wish to add a new address. The Speed Dial Registration screen appears.
Page 297: Specifying The Settings For Group Dialing
Specifying the Settings for Group Dialing From the page displayed by clicking “Group Dial Setting” in the menu on the “Fax” tab, group dial settings for the copier can be specified. Destination Name Address [Delete] button Adding a New Group Dial Setting Start up PageScope Light.
Page 298 9.2 Getting Ready The Group Dial Registration screen appears. Destinations that have already been specified for one-touch dialing or speed dialing can be added to the 50 destinations specified for a group dial key. To select a destination, select the check box to the left of the destination in the list.
Page 299: Specifying The Settings For Speed Dialing (Ftp Server)
Specifying the Settings for Speed Dialing (FTP Server) From the page displayed by clicking “File Destination Setting” in the menu on the “Scan” tab, FTP servers can be specified for speed dial numbers on the copier. Destination Name Address [Delete] button 9-52 Speed dial number (201 to 210) FTP server name...
Page 300: Adding A New Speed Dial (Ftp Server) Setting
9.2 Getting Ready Adding a New Speed Dial (FTP Server) Setting Start up PageScope Light. Refer to “Using PageScope Light” on page 9-10. Log in to the Administrator mode. Click “File Destination Setting” in the menu on the “Scan” tab. Click the speed dial number where you wish to add a new address.
Page 301 File Destination Function Destination Name FTP Server Address Directory Use Proxy Remote Port Number E-Mail Notification Function Enable Notification Notification Address Account Information Function Anonymous Private Site 9-54 Description This function is used to specify the name for the file destination. (Up to 20 characters) This function is used to specify the host name or IP address of the FTP site where the scan data will be sent.
Page 302: Downloading And Uploading The Destination List
9.2 Getting Ready Downloading and Uploading the Destination List From the page displayed by clicking “Downloading/Uploading Destination list” in the menu on the “Fax” tab, you can export to a txt file the one-touch dial and speed dial settings for destinations (except FTP server destinations) registered on the copier (download).
Page 303: Using Scan To E-Mail Operations
Using Scan to E-mail Operations With a Scan to E-mail operation, documents are sent via a mail server. They are not sent directly to the recipient. In addition, images are regarded as having been sent successfully on completion of their transmission to the server.
Page 304 9.3 Using Scan to E-mail Operations 9.3.1 Transmission Procedures 9.3.1.1 Starting to Scan Press the [Scan] key. The copier switches to Scan mode, and the Scan screen appears. Place the document to be scanned in the auto document feeder. Adjust the guides to the size of the document.
Page 305 If settings such as the subject, cc recipient, and resolution are not to be specified, press the [Start] key instead of the [Yes] key, and skip to step 10. Enter a title (subject), and then press the [Yes] key. Enter the e-mail address for any additional recipient, and then press the [Yes] key.
Page 306: Changing The Scan Mode Settings
9.3 Using Scan to E-mail Operations 9.3.1.2 Changing the Scan Mode Settings The scan mode settings can be changed from the screen for selecting the resolution. If the settings are not changed, scan data will be sent using the default scan mode settings, or the initial settings. For more details, refer to “Specifying the Default Settings for the Scan Settings”...
Page 307: Changing The Scanned Image Size
To change other settings, press the To quit making changes to the scan mode settings, press the [Start] key. The screen for selecting the document mode appears. Press the the compression encoding method (“MH”, “MR”, or “MMR”). Press the [Start] key to return to the Scan screen. The document mode selection screen appears.
Page 308: Specifying The Data Format
9.3 Using Scan to E-mail Operations then press the [Yes] key. The SCAN SETTING screen appears. Specifying the Data Format Press the [Utility] key. Press the “SCAN SETTING” appears. Press the [2] key on the 10-key pad to select “IMAGE FORMAT”. Press the the data format (“TIFF”...
Page 309: If Memory Becomes Full While Scanning
9.3.1.5 If Memory Becomes Full While Scanning A warning message will appear if the amount of free memory in the copier becomes low while scanning a document. Approximately two seconds later If the [Start] key is pressed within one minute of the message appearing, the scan data for the pages that have already been scanned is sent.
Page 310: Specifying The Destination Using One-Touch Dial Keys
9.3 Using Scan to E-mail Operations 9.3.2 Specifying the Destination Using One-Touch Dial Keys Note The one-touch dial setting must have already been specified. For information on setting up one-touch dial keys, refer to “Adding Destinations” on page 9-41. Press the one-touch dial key ([01] to [64]) programmed with the e-mail address where you want to send the scan data.
Page 311: Specifying The Destination Using Speed Dial Numbers
9.3.3 Specifying the Destination Using Speed Dial Numbers Note The speed dial setting must have already been specified. For information on setting up speed dial numbers, refer to “Adding Destinations” on page 9-41. Press the [Speed Dial] key, and then use the 10-key pad to enter the 3-digit speed dial number programmed with the e-mail address where you want to send the...
Page 312: Specifying The Destination Using Group Dial Keys
9.3 Using Scan to E-mail Operations 9.3.4 Specifying the Destination Using Group Dial Keys Note The group dial setting must have already been specified. For information on setting up group dial keys, refer to “Adding Destinations” on page 9-41. If at least one fax number is registered as a recipient with a group dial key, that group dial key cannot be used with the Scan to E-mail transmission.
Page 313: Specifying The Destination Using The Phone Book
9.3.5 Specifying the Destination Using the Phone Book The phone book contains all programmed one-touch dialing and speed dialing numbers, allowing you to search for and select the recipient that you wish to send a document to. Press the [Phone Book] key. Press the “LIST”...
Page 314: Using Scan To Server (Ftp) Operations
9.4 Using Scan to Server (FTP) Operations Using Scan to Server (FTP) Operations In order to perform this operation, an FTP server address must have already been specified. Use PageScope Light to specify the settings. (Refer to “File Destination Setting” on page 9-38.) A specified recipient can be notified by e-mail of the FTP server address where a file was uploaded.
Page 315 9.4.1 Procedure for Scanning to a Server 9.4.1.1 Using the Auto Document Feeder Press the [Scan] key. The copier switches to Scan mode, and the scan screen appears. Place the document to be scanned in the auto document feeder. Adjust the guides to the size of the document.
Page 316 9.4 Using Scan to Server (FTP) Operations Press the the color mode (“COLOR” or “B/W”), and then press the [Yes] key. Press the the resolution (150× 150 dpi, 300× 300 dpi, or 600× 600 dpi), and then press the [Yes] key. The 600×...
Page 317 9.4.1.2 If Memory Becomes Full While Scanning A warning message will appear if the amount of free memory in the copier becomes low while scanning a document. Approximately two seconds later If the [Start] key is pressed within one minute of the message appearing, the scan data for the pages that have already been scanned is sent.
Page 318: Using Internet Faxing Operations
9.5 Using Internet Faxing Operations Using Internet Faxing Operations Internet faxes are sent and received via a mail server. They are not sent directly to the recipient. In addition, images are regarded as having been sent successfully on completion of their transmission to the server.
Page 319 9.5.1 Procedure for Sending Internet Faxes 9.5.1.1 Starting to Scan Press the [Fax] key. The copier switches to Fax mode, and the fax screen appears. Place the document to be scanned in the auto document feeder. Adjust the guides to the size of the document.
Page 320 9.5 Using Internet Faxing Operations For information on entering text, refer to “Entering Text” on page 3-18. Press the [Start] key. Scanning starts, and the scan data is sent to the recipient. 9.5.1.2 If Memory Becomes Full While Scanning A warning message will appear if the amount of free memory in the copier becomes low while scanning a document.
Page 321: Specifying The Destination Using Programmed Dialing
9.5.2 Specifying the Destination Using Programmed Dialing The only transmission functions that can be used when an e-mail address is selected are broadcast transmission and timer transmission. 9-74 9.5 Using Internet Faxing Operations...
Page 322: Sending A Document To Multiple Destinations (Broadcast Transmission)
9.5 Using Internet Faxing Operations 9.5.3 Sending a Document to Multiple Destinations (Broadcast Transmission) The same scan data can be sent to multiple destinations. The maximum number of destinations that can be specified at one time is 274. Note For information on using broadcast transmission, refer to “To fax using broadcast transmission”...
Page 323: Sending A Document At A Specified Time (Timer Transmission)
9.5.4 Sending a Document at a Specified Time (Timer Transmission) A document can be scanned and stored in the copier’s memory, then sent at a specified time. Note For information on using timer transmission, refer to “To fax using timer transmission” on page 6-11. 9-76 9.5 Using Internet Faxing Operations...
Page 324 9.5 Using Internet Faxing Operations 9.5.5 Canceling (Deleting) a Document Queued for Timer Transmission Of the e-mail messages stored in the copier’s memory and reserved for timer transmission, a specific e-mail message can be selected and deleted. Note For information on canceling a queued document, refer to “Canceling (Deleting) a Document Queued in the Memory for Transmission”...
Page 325: Receiving Internet Faxes
9.5.6 Receiving Internet Faxes 9.5.6.1 Types of E-mail Messages That Can Be Received The copier can receive the following types of e-mail messages. Body text of an e-mail message (single-byte characters only) TIFF-F images Body text of an e-mail message (single-byte characters only) and TIFF-F images Text files sent as attachments (single-byte characters only) Note...
Page 326: Manual Reception
9.5 Using Internet Faxing Operations <Screen during auto reception> 9.5.6.3 Manual Reception If the copier is not set to automatically retrieve messages, or you want to check for messages immediately, e-mail can be checked manually. Checking E-mail Manually Press the [Fax] key. The copier switches to Fax mode, and the fax screen appears.
Page 327 Press the [Yes] key. The copier checks the POP3 server for received e-mail messages, then begins to print any messages that have been received. After checking for received e-mail messages and printing them, the fax screen appears again. 9-80 9.5 Using Internet Faxing Operations...
Page 328: Forwarding Fax Documents
9.5 Using Internet Faxing Operations 9.5.7 Forwarding Fax Documents Fax messages received by the copier can be forwarded to another fax machine (fax number) or to an Internet fax service (e-mail address). Note When forwarding a document that has been received by Internet fax, some limitations may apply, depending on the data format of the image or the type of destination.
Page 329 If the option to forward and print the document (“ON (PRINT)”) is selected, the received fax is forwarded to a destination after printed the received data. The destination e-mail address or fax number can be entered using the 10-Key pad, the one-touch dial keys, or speed dial numbers. Press the [Yes] key.
Page 330: Checking The Transmission/Reception Results
9.6 Checking the Transmission/Reception Results Checking the Transmission/Reception Results The transmission results for up to 60 messages, including sent and received faxes, are recorded. The copier is set to automatically print the activity report each time there have been 60 transmissions. In addition, the transmission result report can be printed by pressing the [Status] key.
Page 331: Checking The Transmission Results
9.6.1 Checking the Transmission Results Press the [Status] key. Press the “TX/RX RESULT”, and then press the [Yes] key. Press the display and check the desired transmission results. In the transmission results screen, “TX” indicates result for sent messages, “RX” indicates results for received messages.
Page 332: Miscellaneous
Miscella- neous...
Page 333: Specifications
Print Paper Size Capacity Warm-up Time Zoom Ratios Multiple Copies Density Control Lost Image 10-2 FAX2900 Desktop Electrostatic Dry Powdered Image Transfer to Plain Paper Heated Roller Horizontal: 600 dpi Vertical: 600 dpt Types: Sheets Size: Maximum Legal L Plain paper, recycled paper (16 lb to 24 lb)
Page 334: Scan To E-Mail / Scan To Server
10.1 Specifications Specification FAX2900 Power Requirements 110-127 V: less than 7A, 50-60 Hz 220-240 V: less than 3.7 A, 50/60 Hz Power Consumption 120-127 V: 770-890W 220-240 V: 814-888W Dimensions 416mm (width) ( 16.4inch (width) Standard Memory Copier function: 16 MB...
Page 335: Auto Document Feeder
Power Consumption Dimensions Weight 10-4 FAX2900 Standard Mode: 1-sided original Plain paper: 13-1/4 lb to 32 lb A4 L, B5 L, A5 L, Legal L, Letter L, Invoice L Custom size: Width: 5-3/4 to 8-1/2, Length: 5 to 14...
Page 336: Function Menu Commands
10.2 Function Menu Commands 10.2 Function Menu Commands Function Menu Commands Menu Settings 1 BROADCAST Recipients 2 TIMER TX Transmission time 3 MAILBOX TX Recipient, mailbox ID and password 4 PRINT MAILBOX RX Mailbox ID 5 POLLING TX SINGLE/MULTI, polling ID and password 6 POLLING RX Caller, polling ID and password 7 RELAY INITIATE...
Page 337: Care Of The Machine
10.3 Care of the Machine Cleaning Turn off the machine before cleaning it. Housing Cover § Wipe the surface of the housing cover with a soft cloth dampened with a mild household detergent. Control Panel § Wipe the surface of the Control Panel clean with a soft, dry cloth.
Page 338: Glossary
10.4 Glossary 10.4 Glossary Terms and Definitions Term Definition Automatic redialing If a call cannot be completed, for example if the recipient’s machine is busy, the recipient is automatically called again. If a document queued in the memory to be sent contains multiple pages, until the time for redialing has been reached, it is advanced in the queue and sent.
Page 339: Paper Size And Zoom Ratio Tables
10.5 Paper Size and Zoom Ratio Tables Paper Sizes Paper Format Paper Format Legal Foolscap Government Legal Foolscap Foolscap Foolscap Folio 8-1/4 × 11-3/4 Letter Government Letter Quarto Statement Invoice 4 × 6 10-8 10.5 Paper Size and Zoom Ratio Tables Metric Size Inch Size 210 mm ×...
Page 340: Zoom Ratios
10.5 Paper Size and Zoom Ratio Tables Zoom Ratios Metric Sizes Document Paper Size 210 mm × 297 mm 8-1/4 × 11-3/4 148 mm × 210 mm 5-3/4 × 8-1/4 105 mm × 148 mm 4-1/4 × 5-3/4 182 mm × 257 mm 7-1/4 ×...
Page 341 Letter 8-1/2 × 11 215.9 mm × 279.4 mm Invoice 5-1/2 × 8-1/2 139.7 mm × 215.9 mm Zoom ratio = Paper size/Document size 1 inch = 25.4 mm 1 mm = 0.0394 inch 10-10 10.5 Paper Size and Zoom Ratio Tables ×...

This manual is also suitable for:

Fax3900

Konica Minolta FAX2900 User Manual

1 Introduction

2 Precautions

3 Before Making Copies or Faxing

4 Making Copies

5 Faxing

6 Fax Transmission/Reception Methods

7 Using the Utility Mode

8 When a Message Appears

9 Internet Fax & Network Scan

Quick Links

Need help?

Questions and answers

Related Manuals for Konica Minolta FAX2900

Summary of Contents for Konica Minolta FAX2900
