INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your local dealer with questions on installation, operation or service.
NOTICE: SAVE THESE INSTRUCTIONS
Model(s):
Accentra Freestanding
Pellet Stove
Accentra
Use & Care Video
!
Tested and approved for wood pellet fuel only. Burning
of any other type of fuel voids your warranty.
!
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contact local building or fire officials about restrictions
and installation inspection requirements in your area.
1
Owner's Manual
Care and Operation
CAUTION
CAUTION
Harman® • Accentra Owner's Manual_R40 • 2002 -___ • 11/15
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not overfire - If any external part starts to glow, you
are overfiring. Reduce feed rate. Overfiring will void
your warranty.
• Comply with all minimum clearances to combustibles
as specified. Failure to comply may cause house fire.
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled.
• NEVER allow children to touch glass.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
flammable materials.
• Keep clothing, furniture, draperies and other flammable
materials away.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com.
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com.
WARNING
WARNING
3-90-08326c
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Harman Accentra
Summary of Contents for Harman Accentra
-
Page 1: Care And Operation
CAUTION NOTE Check building codes prior to installation. To obtain a French translation of this manual, please contact your dealer or visit www.harmanstoves.com. • Installation MUST comply with local, regional, state and national codes and regulations. Pour obtenir une traduction française de ce manuel, s’il vous plaît contacter votre revendeur ou visitez www. • Contact local building or fire officials about restrictions harmanstoves.com. and installation inspection requirements in your area. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 2: Welcome
DO NOT REMOVE THIS LABEL / NE PAS ENLEVER CETTE ÉTIQUETTE 3-90-247 Rev F LAbEL tiCkEt ECO: 77540 CLASS: Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c PARt # / REv: 3-90-247_Rev F ADHESivE: 486 ORiginAtOR: Spidlet MAtERiAL: MEtAL... -
Page 3: Table Of Contents
• WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. • NOTICE: Used to address practices not related to personal injury. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 4: Product Specific And Important Safety Information
In the absence of local codes you must comply with DO NOT INSTALL IN SLEEPING ROOM. the ASTM E1509-2004, ULC S628-93, ULC/ORD-C- 1482-M1990, (UM) 84-HUD The Accentra is Certified to comply with 2015 particulate emission standards. Not approved for sale after May 15, 2020. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 5: Btu & Efficiency Specifications
NOTE: Hearth & Home Technologies, manufacturer of this wood heater in a manner inconsistent with operating this appliance, reserves the right to alter its products, their instructions in this manual. specifications and/or price without notice. Harman® is a registered trademark of Hearth & Home Technologies. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 6: General Information
• Consider not using the stove when children will be present. Contact your dealer for more information, or visit: www. hpba.org/safety-information. To prevent unintended operation when not using your stove for an extended period of time (summer months, vacations, trips, etc): • Unplug stove from receptacle. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 7: Control Explanation
Blinks to indicate errors listed below. burn and the combustion blower will remain on low. Power Light Indicates power to the Feed Limit control. Sets the maximum feed rate Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 8: Fuel Specification
Moisture CAUTION Always burn dry fuel. Burning fuel with high moisture content takes energy to dry and tends to cool the appliance thus, Tested and approved for use with wood pellets ONLY. robbing heat from your home. Damp pellet fuel could turn Burning of any other fuel will void your warranty. back into sawdust which does not flow properly through the feed system. NOTICE Hearth & Home Technologies is not responsible for stove performance or extra maintenance required as a result of using fuel with higher ash or mineral content. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 9: General Operating Information
• NEVER USE GASOLINE, GASOLINE-TYPE LANTERN Regardless of the burn rate, when the area is warm enough FUEL, KEROSENE, CHARCOAL LIGHTER FLUID, OR to satisfy the room sensor, the appliance will shut off. SIMILAR LIQUIDS TO START OR “FRESHEN UP” A FIRE IN THIS HEATER. KEEP ALL SUCH LIQUIDS WELL AWAY FROM THE HEATER WHILE IT IS IN USE. • DO NOT BURN GARBAGE OR FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. • DO NOT USE CHEMICALS OF FLUIDS TO START THE FIRE. • Combustible materials may ignite. Figure 3.1 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 10: Operating Instructions
• Curing of high temperature paint. made need to be made depending on fuel quality and/or • Open windows for air circulation. heat output desired. Odors may be irritating to sensitive individuals. 5. The fuel feed system and the igniter should now be on. 6. Once the appliance has ignited, let it burn for approximately 7-10 minutes. After this time the unit should begin to operate per the settings at the control. Figure 4.2 Figure 4.3 Figure 4.4 Figure 4.5 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 11: Ignition Cycles
• Closer than required clearances to combustibles in accordance to what temperature the room sensor is to appliance reading. When the room sensor is satisfied the blower will • Within space required for loading or ash removal. shut down until the room sensor sees a demand for heat. 3. Occasionally the appliance may run out of fuel and shut itself down. When this happens, the unit will need to be turned to the off position and restarted. If needed, follow Section A , “Starting Your First Fire”. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 12: Automatic Ignition
If, at #6 setting, a 1" or less ash bed is not obtainable, it is not a problem. The 1" ash bed is only at maximum burn rate and during normal operation, the ash bed will be larger. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... - Page 13 To kill the fire or stop burning the stove, turn the Mode Selector to “OFF”. This will cause the fire to diminish and burn out. When the fire burns out and the stove cools down everything will stop. If you pull the plug to shut down the stove, all motors will stop. This may cause incomplete combustion and smoke in the firebox. If the load door is opened, the smoke may escape. This setting will produce continuous maximum heat output The best way to shut down the stove is simply let it run out with the distribution blower at full speed. of pellets, then the stove will shut down automatically. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
-
Page 14: Maintenance And Service
Heat Exchanger Every 1 ton of fuel Blower, Combustion (Exhaust) More frequently depending on the fuel type Blower, Distribution Every 25 bags or more frequently depending on the fuel type Door Gasket Inspection Prior to heating season Exhaust Path More frequently depending on ash build-up Firebox - Prepare for Non-Burn Season At end of heating season Burnpot - Burning pellets - hardwood Every 3 bags Burnpot - Burning pellets - softwood Every 5 bags Glass When clear view of burnpot becomes obscure Hopper / Hopper Lid Gasket Every 50 bags of fuel or when changing fuel types Venting System More frequently depending on the fuel type Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 15: Glass Maintenance
Ceramic Glass it before operating your stove. Remove pieces carefully. Screws and Gasket Replace glass only with Harman® replacement glass; do not use substitutes. Carefully remove damaged glass, gasket material, and hold down clips (set aside). Install the self adhesive 1/4”” gasket material around the front face of the glass. Set the glass panel and gasket gently onto the door. Install the hold down clips and tighten with bolts. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 16: Burnpot Maintenance
Note: The hot lead/cold lead connection must always Figure 5.3 be pulled to the rear of the feeder body before operation. Viewed from below through the ash pan opening. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 17: Heat Exchanger & Combustion Blower Maintenance
5.5. Swing the latch upward far enough to release the top edge of the heat exchanger cover. Tilt the cover forward approximately 2” and lift it upward about 1” to release the bottom edge. The cover can now be taken completely out through the upper door opening. Repeat the process with the second heat exchanger cover. Combustion intake assembly latch Figure 5.6 Figure 5.4 Figure 5.7 Figure 5.5 Heat Exchanger cover latch • Remove the combustion intake assembly. Figure 5.4. The combustion intake assembly is held into place with two swing latches Figure 5.6. Swing each latch until it hangs down away from the retainer stud. Now the assembly can be taken out by tilting the right side outward first through the lower door opening. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 18: Pellet Feeder Chamber
Figure 5.7 To remove the feeder cover: • Remove the (2) 5/16” wing nuts. • Slide the cover off of the threaded studs. • Inspect and clean the inner chamber if necessary. See above picture. • Reinstall the cover making certain it is centered on the feeder body and tighten the wing nuts as tightly as you can by hand. NOTE: Views are shown with the rear motor covers removed. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 19: Troubleshooting And Frequently Asked Questions
7. This is normal. Flame will settle down once the fire is established. Contact your dealer for additional information regarding operation and troubleshooting. Visit www.harmanstoves. com to find dealer. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 20: Troubleshooting
SMOKE SMELL Seal the vent pipe joints and connection to stove with silicone. The exhaust vent is the only part of the system that is under positive pressure. FIRE HAS GONE OUT- Check for status light. 1. No fuel in hopper. 2. Draft is too low, blocked flue. 3. Something is restricting fuel flow. 4. Hopper lid not closed properly. 5. Feed motor or combustion blower has failed. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 21: Reference Materials
FUELS AND OPERATION GUIDELINES residence. Before using the appliance, have the venting system thoroughly inspected and replace any damaged components. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 22: Motor And Component Location
(Draft) in the firebox. If the high limit and one backup high limit. The control has an automatic draft becomes too low for proper combustion, the switch opens, diagnostic circuit that continuously monitors the ESP and Room cutting power to the feed motor and the igniter circuits. This switch Sensor for faults. If a fault should occur, the control sends a status is connected into the AC (high voltage) wiring. alert and at the same time the unit goes down to minimum feed/ minimum burn as a safety condition. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 23: Loss Of Power
3. Add firestarter to pellets following manufacturer’s will not rise. The unit will then shut-down, and may instructions. flash a six-blink status error. (See ESP error codes) 4. Light pellet gel with a match, and close the door, turn Mode • If the fire is still burning, it will resume normal Selector to Constant Burn. Operation will begin when the operation. fire reaches the proper temperature. Contact your dealer if you have questions about UPS compatibility with your appliance. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... -
Page 24: Service Parts List
008400001- 008408015 Post 008408015 1-10-247260A Gasket, Hopper Throat 3-44-677185 Gasket, Hopper Top 1-00-375501 Grommet, 3/4" 3-31-960021 Hopper Switch 48" Post 008403501 3-20-232108 Additional service parts on following page. 10/15 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... - Page 25 Flame Guide 3-00-08534 3-20-677200 Igniter Pkg of 10 1-00-677200 Igniter Cradle, Holder & Flat Bottom 3 Sets 1-00-06620 Thumb Screw Pkg of 10 3-31-782108-10 Additional service parts on following page. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
- Page 26 Combustion Blower replacement Fan Blade, Single Paddle 5" (Comb Blower) 3-20-40985 Pre 008400001 Parts diagram on Feeder Assemblies following pages Post 008400001 Additional service parts on following page. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
- Page 27 Feeder Repair kit 1-00-677150 Gasket, Feeder, Air Intake Pkg of 6 3-44-72224-6 Pillow Block Pkg of 4 3-31-3614087-4 Pusher Arm, Cast Feeder 1-10-06684 Additional service parts on following page. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
- Page 28 38.16 UL Feeder Cam Block 3-00-677154 Gasket, Hopper Throat 3-44-677185 Hopper Switch FeederFitting Pkg of 2 1-00-142818 Pillow Block Pkg of 4 3-31-3614087-4 Additional service parts on following page. Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
- Page 29 Pkg of 100 3-30-3014-100 Screw, 5/16” Shldr x 1/4” x 1/4”-20 Thrd Alloy Steel Shoulder Pkg of 5 3-30-1105-5 Washer,5/16” x 3/4” 18-8 Stainless Steel Flat Pkg of 100 3-30-9003-100 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
-
Page 30: Warranty Policy
Igniters, electronic components, and glass 2 years Factory-installed blowers Molded refractory panels 3 years Firepots and burnpots 5 years 1 year Castings and baffles Manifold tubes, 7 years 3 years HHT chimney and termination 1 year Burners, logs and refractory years Limited 3 years Firebox and heat exchanger Lifetime All replacement parts 90 Days beyond warranty period See conditions, exclusions, and limitations on next page. 4021-645F 02-18-13 Page 1 of 2 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c... - Page 31 This warranty is void if: • The appliance has been over-fired or operated in atmospheres contaminated by chlorine, fluorine, or other damaging chemicals. Over-firing can be identified by, but not limited to, warped plates or tubes, rust colored cast iron, bubbling, cracking and discoloration of steel or enamel finishes. • The appliance is subjected to prolonged periods of dampness or condensation. • There is any damage to the appliance or other components due to water or weather damage which is the result of, but not limited to, improper chimney or venting installation. LIMITATIONS OF LIABILITY: • The owner’s exclusive remedy and HHT’s sole obligation under this warranty, under any other warranty, express or implied, or in contract, tort or otherwise, shall be limited to replacement, repair, or refund, as specified above. In no event will HHT be liable for any incidental or consequential damages caused by defects in the appliance. Some states do not allow exclusions or limitation of incidental or consequential damages, so these limitations may not apply to you. This warranty gives you specific rights; you may also have other rights, which vary from state to state. EXCEPT TO THE EXTENT PROVIDED BY LAW, HHT MAKES NO EXPRESS WARRANTIES OTHER THAN THE WARRANTY SPECIFIED HEREIN. THE DURATION OF ANY IMPLIED WARRANTY IS LIMITED TO DURATION OF THE EXPRESSED WARRANTY SPECIFIED ABOVE. 4021-645F 02-18-13 Page 2 of 2 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
-
Page 32: Contact Information
• Leave this manual with a n d m a i n t e n a n c e these instructions for safe party responsible for use instructions included. installation and operation. and operation. Printed in U.S.A. - Copyright 2012 Harman® • Accentra Owner’s Manual_R40 • 2002 -___ • 11/15 3-90-08326c...
