INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: SAVE THESE INSTRUCTIONS
Model(s):
Accentra Freestanding
Pellet Stove
!
Tested and approved for wood pellets only. Burning of any
other type of fuel voids your warranty.
!
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contact local building or 昀椀re of昀椀cials about restrictions
and installation inspection requirements in your area.
1
Installation Manual
Installation and Appliance Setup
CAUTION
CAUTION
Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Do not store or use gasoline or other 昀氀ammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over昀椀re - If any external part starts to glow, you
are over昀椀ring. Reduce feed rate. Over昀椀ring will void
your warranty.
• Comply with all minimum clearances to combustibles
as speci昀椀ed. Failure to comply may cause house 昀椀re.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled.
• NEVER allow children to touch glass.
• Keep children away.
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
昀氀ammable materials.
• Keep clothing, furniture, draperies and other 昀氀ammable
materials away.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com.
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com.
WARNING
3-90-08326i
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Harman Accentra
Summary of Contents for Harman Accentra
- Page 1 CAUTION NOTE Check building codes prior to installation. To obtain a French translation of this manual, please contact your dealer or visit www.harmanstoves.com. • Installation MUST comply with local, regional, state and national codes and regulations. Pour obtenir une traduction française de ce manuel, s’il vous plaît contacter votre revendeur ou visitez www. • Contact local building or 昀椀re of昀椀cials about restrictions harmanstoves.com. and installation inspection requirements in your area. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i...
-
Page 2: Table Of Contents
J. Inspect Appliance & Components ....21 Safety Alert Key: DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. • • NOTICE: Indicates practices which may cause damage to the stove or to property. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 3: Installation Standard Work Checklist
120VAC unswitched power provided to the appliance. ________________________________ Appliance Setup Section 5 (Pg. 20-21) All packaging and protective materials are removed ________________________________ Accessories installed properly ________________________________ Manual bag and all it’s contents are removed from inside the appliance and given to party responsible for use and operation ________________________________ Started appliance and veri昀椀ed that all motors and blowers operate as they should. ________________________________ Hearth and Home Technologies recommends the following: Photographing the installation and copying this checklist for you 昀椀le. The this checklist remain visible at all times on the appliance until the installation is complete. Comments: Further description of the issues, who is responsible (Installer/Builder/Other Trades, etc.) and corrective action needed __________________________________________________________________________________________ _________________________________________________________________________________________________ _________________________________________________________________________________________________ Comments communicated to party responsible____________________ by ________________________ on __________ Builder / Gen Contractor) (Installer) (Date) Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 4: Product Speci昀椀C And Important Safety Information
In the absence of local codes you must comply with DO NOT INSTALL IN SLEEPING ROOM. the ASTM E1509-2004, ULC-S628-93, ULC/ORD-C- 1482-M1990, (UM) 84-HUD. The Accentra is Certi昀椀ed to comply with 2015 particulate emission standards. Not approved for sale after May 15, 2020. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 5: Btu Speci昀椀Cations
Vertical Tube Furnace at 750° C and UL763 shall be Harman® is a registered trademark of Hearth & Home considered non-combustible materials. Technologies. E. Combustible Materials Speci昀椀cation Materials made of or surfaced with wood, compressed paper, plant 昀椀bers, plastics, or other material that can ignite and burn, whether 昀氀ame proofed or not, or plastered or un- plastered shall be considered combustible materials. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 6: Getting Started
• Lower roof line • Avoid outside wall in cooler climates Windward Leeward Multi-level Roofs Recommended: NOT recommended: Outside Air Intake Outside Air Intake on windward side on leeward side Figure 2.1 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 7: Tools And Supplies Needed
RISK OF FIRE OR EXPLOSION! Damaged parts could impair safe operation. DO NOT install damaged, Do NOT use makeshift compromises when installing this appliance, serious consequences may result. incomplete or substitute components. Keep appliance dry. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 8: Appliance Dimension Diagram
20-5/16” 24” 516mm 610mm 23-5/16” 24-5/8” 625mm 592mm Outside Air Intake 12-5/16” 12-5/16” 313mm 313mm Note: Installation of the optional leg kit adds 2.95 inches of height. Figure 3.1 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 9: Clearances To Combustibles
14-3/4” 14-3/4” 375mm 375mm 24” 610mm 2-1/4” 57mm 54” 1372mm Figure 3.2 Place the stove away from combustible walls at least as far as shown in Figures 3.3. Figure 3.3 Note that the clearances shown are minimum for safety but do not leave much room for access when cleaning or servicing. Please take this into account when placing the stove. Due to high temperatures, the stove should be placed out of traf昀椀c and away from furniture and draperies. Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns to skin and/or clothing. Young children should be carefully supervised when they are in the same room as the stove. Clothing and other 昀氀ammable materials should not be placed on or near this unit. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 10: Floor Protection
L Rear 0” below. Minimum size 昀氀oor protection for a corner installation hearth pad is 24-1/16” deep x 28-5/8” wide. NOTE: Floor protector WILL NOT touch the wall. loor protector Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 11: Mobile Home Installation
POINT DIRECTLY UNDER THE VENT TERMINATION. WARNING MOBILE HOME INSTALLATION SHOULD BE DONE IN ACCORDANCE WITH THE MANUFACTURED HOME AND SAFETY STANDARD (HUD), CFR 3280, PART 24. WARNING DO NOT INSTALL IN SLEEPING ROOM Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 12: Termination Location And Vent Information
KEEP COMBUSTIBLE MATERIALS (SUCH AS GRASS, LEAVES, ETC.) AT LEAST 3 FEET AWAY FROM THE FLUE OUTLET ON THE OUTSIDE OF THE BUILDING. 3 Ft. to Combustibles Figure 4.2 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... - Page 13 Kaowool, mineral wool or an equivalent non- combustible insulation is recommended to be installed on top of the sealing plate to reduce the possibility of condensation. The connector pipe should extend through the smoke chamber to the base or into the 昀椀rst 昀氀ue tile. Seal pipe joints with silicone or aluminum tape in addition to the sealing system used by the manufacturer. Be sure to design the venting so that it can be easily cleaned. Figure 4.4 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i...
- Page 14 #6 Installing into an existing chimney (Figure 4.6) w/Full liner This method provides excellent venting for normal operation. This method also provides natural draft in the event of a power failure. In some places in the US and Canada it is required that the vent pipe extend all the way to the top of the chimney. Seal pipe joints with silicone or aluminum tape in addition to the sealing system used by the manufacturer. The pipe or liner inside the chimney should be 4” diameter. In this method a cap should also be installed on the chimney to keep out rain. Figure 4.6 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i...
- Page 15 Through the ceiling vent, follow PL vent manufacturers combustible materials such as shrubbery, mulch or tall recommendations when using wall and ceiling pass through. grasses. Seal pipe joints with silicone or aluminum tape in addition to the sealing system used by the manufacturer. Do not place joints within wall pass-through. min. wall to outlet 12" Figure 4.9 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i...
-
Page 16: Chimney Diagram
F. The clearance to an outside corner is 11" from center of pipe. NOTE G. The clearance to an inside corner is 12". Where passage through a wall, or partition of H. A vent must not be installed within 3 feet (90 cm) above a gas combustible construction is desired, the installation meter/regulator assembly when measured from the horizontal shall conform to CAN/CSA-B365. (if in Canada) center-line of the regulator. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 17: Venting & Use Of Elbows
3” vent pipe should not be used in this • Vertical Pipe or Liner: ½ EVL Unit installation. However, since 4” pipe can support an EVL up to 30, the use of 4” pipe would create a satisfactory • Horizontal Pipe or liner: 1 EVL Unit installation. The total allowable equivalent vent length is: • 20 EVL for 3” pellet vent pipe or liner • 30 EVL for 4” pellet vent pipe or liner Due to the potential for 昀氀y ash accumulation in horizontal venting sections, the maximum permissible horizontal venting length is: • 4 ft. for 3” & 4” pellet vent pipe. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... - Page 18 Increaser Part #3PVPX4ADHB are highly recommended to be installed on the starter collar to insure a proper pipe connection to the unit. • INSTALL VENT AT CLEARANCES SPECIFIED BY THE VENT MANUFACTURER • Use silicone to create an effective vapor barrier at the location where the chimney or outside air ducting passes through to the exterior of the structure Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i...
-
Page 19: Outside Air
Use silicone to create an effective vapor barrier at the location where the chimney or outside air ducting passes through to the exterior of the structure. Figure 4.14 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 20: Locating Your Appliance And Chimney
• Downdrafts Prior to installing the 昀氀ue pipe, connect a draft meter. (The draft meter must have a minimum range of 0 - .5”) Record the • Tight sealing construction of the structure 昀椀rst reading. Connect 昀氀ue pipe to stove and be sure all doors • Mechanical exhausting devices and windows in the home are closed. Record the second draft reading _______. If the second reading is more than .05” lower than the 昀椀rst reading, check for possible restrictions or the need for outside air. For more information on the draft test procedure, refer to Page 21 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 21: Avoiding Smoke & Odors
4” stainless steel 昀氀ex vent piping is only allowed for use in masonry 昀椀replaces and chimneys or factory built wood burning 昀椀replaces with class A metal chimneys. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 22: Fire Safety
MINIMUM LOW BURN RATE THAT MUST NOT BE ALTERED. IT IS AGAINST FEDERAL REGULATIONS TO ALTER THIS SETTING OR OTHERWISE OPERATE THIS WOOD HEATER IN A MANNER INCONSISTENT WITH OPERATING INSTRUCTIONS IN THIS MANUAL. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 23: Appliance Setup
These screws need only be loosened, not removed, to remove the panels. It is recommended that the rear covers are installed after the unit is in place and the vent pipe is installed, to prevent contact with hot or moving parts. C. Flame Guide Install the cast iron 昀氀ame guide on top of the burn pot. Make Figure 5.1 sure that the 昀氀ame guide is fully seated on the vertical sides of the burn pot and that the back of the guide rests against the body of the stove. Figure 5.3. (2) 1/4-20 x 5/8” Hex Screws Figure 5.2 Flame guide Figure 5.3 Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 24: Room Sensor
NOTE: In some cases, the draft may not go as low as -.35 to -.45 even with the set screw completely counter- clockwise. Ideally, you should just set it as low as Figure 5.4 possible. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 25: Reference Materials
FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS IN WARNING YOUR AREA. KEEP COMBUSTIBLE MATERIALS SUCH AS GRASS, LEAVES, ETC. AT LEAST 3 FEET AWAY FROM THE POINT DIRECTLY UNDER THE VENT TERMINATION. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... -
Page 26: Wiring Diagram
B. Wiring Diagram Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i... - Page 27 352 Mountain House Road, Halifax, PA 17032 www.harmanstoves.com Please contact your Harman dealer with any questions or concerns. ® For the location of your nearest Harman dealer, ® please visit www.harmanstoves.com. Printed in U.S.A. Harman® • Accentra Installation Manual_R42 • 2002 -___ • 05/16 3-90-08326i...
