  • Page 2 International Headquarters B&B Electronics Mfg. Co. Inc. 707 Dayton Road Ottawa, IL 61350 USA Phone (815) 433-5100 -- General Fax (815) 433-5105 Website: www.bb-elec.com European Headquarters B&B Electronics Westlink Commercial Park Oranmore, Co. Galway, Ireland Phone +353 91-792444 -- Fax +353 91-792445 Website: www.bb-europe.com ©...

  • Page 3: Limited Lifetime Warranty

    FCC RADIO FREQUENCY INTERFERENCE STATEMENT This equipment has been tested and found to comply with the limits for a Class A computing device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.

  • Page 4: Table Of Contents

    Table of Contents FCC RADIO FREQUENCY INTERFERENCE STATEMENT ....................III LIMITED LIFETIME WARRANTY ..........................III ABOUT THE GIGA-MCBASIC-II .............................1 INSTALLING THE GIGA-MCBASIC-II ..........................2 HARDWARE MOUNTING ............................2 POWERING THE GIGA-MCBASIC-II ..........................2 LED OPERATION .................................3 LFPT...................................5 LOW SPD SWITCH ON THE SFP VERSION ........................6 SPECIFICATIONS .................................7...

  • Page 5: About The Giga-Mcbasic-Ii

    SFP version available; both support jumbo frames up to 10240 MTU. The Giga-McBasic-II, TX/FX is a fixed fiber transceiver model, includes two 10/100/100 Mbps RJ-45 connectors and one 1000Mbps SC fiber connector which can support Single Mode fiber or Multi Mode fiber in Dual Strand or Single Strand fiber.

  • Page 6: Installing The Giga-Mcbasic-Ii

    Wallmount bracket. HARDWARE MOUNTING The IE-Giga-McBasic-II can be mounted on a DIN rail or using wall mount brackets (shown below). DIN rail clips (part number 806-39105) and wall mount brackets (part number 895-39229) are available for purchase through a B&B Electronics Distributor.

  • Page 7: Led Operation

    LED OPERATION Each Giga-McBasic-II includes a front LED stack. Functions are as follows: Glows red when a fault has been detected on the unit Glows green with a valid link 1000 Mbps Glows green when is running at 1000Mbps Glows green when unit is powered...
  • Page 8 Each Giga-McBasic-II includes two LEDs, located on the RJ-45 connector. LED functions are as follows: LNK/ACT Glows green with a valid link Blinks green when activity is detected Glows amber when port is running full duplex...

  • Page 9: Lfpt

    LFPT The Giga-McBasic-II includes a LFPT DIP Switch, located on the front of the unit. DIP Switch functions are as follows: Switch Up LFPT ON Switch LFPT OFF Down Link Fault Pass-Through (LFPT) is a troubleshooting feature that combines TX and FX LinkLoss from both the local and remote Giga-McBasic-II, TX-FX/SFP modules.

  • Page 10: Low Spd Switch On The Sfp Version

    LOW SPD SWITCH ON THE SFP VERSION The SFP version of the Giga-McBasic-II supports a LOW SPD DIP Switch. If a gigabit SFP is installed in the SFP port, by setting the switch to the ON position, it will force the SFP to operate at 100Mbps.

  • Page 11: Specifications

    SPECIFICATIONS Ethernet Connections • 10/100/1000 BaseT • Auto Negotiation • AutoCross • Flow Control • 10240 maximum frame size • Full Line-Rate Forwarding AC Power Standard IEC connector 100 to 240 VAC Operating Temperature +14°F to +122°F (-10C° to +50°C) Storage Temperature -31°C to +167°...

  • Page 12: B&B Electronics Technical Support

    B&B ELECTRONICS TECHNICAL SUPPORT Phone: 1-800-346-3119 (Monday-Friday, 7-6:30 CST) Fax: 815-433-5109 E-Mail: techsupport@bb-elect.com Web: www-bb-elec.com FIBER OPTIC CLEANING GUIDELINES Fiber Optic transmitters and receivers are extremely susceptible to contamination by particles of dirt or dust, which can obstruct the optic path and cause performance degradation. Good system performance requires clean optics and connector ferrules.

  • Page 13: Safety Certifications

    WARNING! Integrated circuits and fiber optic components extremely susceptible electrostatic discharge damage. Do not handle these components directly unless you are a qualified service technician and use tools and techniques that conform to accepted industry practices. SAFETY CERTIFICATIONS UL/CUL: Listed to Safety of Information Technology Equipment, including Electrical Business Equipment.
  • Page 14 The information in this document is subject to change without notice. B&B Electronics assumes no responsibility for any errors that may appear in this document. Giga-McBasic-II is a trademark of B&B Electronics. Other brands or product names may be trademarks and are the property of their respective companies.
