  • Page 1 Projector ® User manual...

  • Page 2: Table Of Contents

    TablE of ConTEnTs safETY ....................4 Important Safety Instruction....................... 4 Laser Radiation Safety Information ................... 5 Copyright ........................... 6 Disclaimer ..........................6 Trademark Recognition ......................6 FCC ............................6 Declaration of Conformity for EU countries ................7 WEEE ............................7 InTRoDUCTIon ..................
  • Page 3 Compatible resolutions ......................52 Image size and projection distance ..................54 Projector dimensions and ceiling mount installation ..............55 IR remote codes ........................56 Troubleshooting ........................59 Warning indicators ........................61 Specifications ........................... 63 Optoma global offices ....................... 64 English...

  • Page 4: Safety

    ‡ Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. ‡ See projector enclosure for safety related markings.

  • Page 5: Laser Radiation Safety Information

    ‡ Only use attachments/accessories specified by the manufacturer. ‡ Do not look into straight into the projector lens during operation. The bright light may harm your eyes. ‡ This projector will detect the life of the lamp itself. ‡ When switching the projector off, please ensure the cooling cycle has been completed before disconnecting power.

  • Page 6: Copyright

    ‡ Adequate instructions for assembly, operation, and maintenance, including clear warnings concerning precautions to avoid possible exposure to laser and collateral radiation in excess of the accessible emission limits in Class 3R. Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved.

  • Page 7: Declaration Of Conformity For Eu Countries

    operation Conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation. notice: Canadian users This Class A digital apparatus complies with Canadian ICES-003.

  • Page 8: Introduction

    InTRoDUCTIon Package overview Carefully unpack and verify that you have the items listed below under standard accessories. Some of the items under optional accessories may not be available depending on the model, specification and your region of purchase. Please check with your place of purchase. Some accessories may vary from region to region. The warranty card is only supplied in some specific regions.

  • Page 9: Product Overview

    InTRoDUCTIon Product overview note: Do not block projector inlet or outlet air vents. (*) optional accessory varies depending on model, specification, and region. Item Item Front IR Receiver Power Switch Lens Power Socket Top IR Receiver 10. Kensington Lock Port LED Status Indicators 11.

  • Page 10: Connections

    InTRoDUCTIon Connections Item Item HDBaseT Connector DVI-D Connector Remote IN Connector Power Socket Remote OUT Connector 10. USB Connector (support 5V, 0.5A) for wireless dongle HDMI Connector 11. Security Bar VGA IN / YPbPr Connector 12. SERVICE Connector VGA OUT Connector 13.

  • Page 11: Keypad

    InTRoDUCTIon Keypad Item Item Power Four Directional Select Keys Menu Zoom Enter Focus Exit 10. Auto Input 11. Lens AV Mute English...

  • Page 12: Remote Control

    InTRoDUCTIon Remote control Mode Info Auto Input Enter Menu Exit Gamma Bright Cont. Lens H Focus Lens V Keystone H Zoom Keystone V Shutter Hot Key Pattern (AV Mute) Item Item Item Power On Bright Mode Number Keys 10. Lens H Input Info 11.

  • Page 13: Setup And Installation

    sETUP anD InsTallaTIon Installing the projection lens Before setting up the projector, install the projection lens on the projector. ImPoRTanTT! ‡ Make sure the projector is properly turned off before installing the lens. ‡ During lens installation, do not adjust the lens shift, zoom, or focus either using the remote control or the projector keypad.
  • Page 14 sETUP anD InsTallaTIon Install the lens onto the projector. Rotate the lens clockwise to lock the lens in place. Firmly install the lens ring onto the lens. note: The lens ring is compatible with the following lens modules: A01 (1.00-1.28), A02 (1.28-1.61), A03 (1.60- 3.07), and A13 (3.04-5.78).

  • Page 15: Adjusting The Projector Position

    sETUP anD InsTallaTIon adjusting the projector position When you select a position for the projector, consider the size and shape of your screen, the location of your power outlets, and the distance between the projector and the rest of your equipment. Follow these general guidelines: ‡...

  • Page 16: Connecting Sources To The Projector

    sETUP anD InsTallaTIon Connecting sources to the projector Item Item CAT5e/6/6A Cable DVI-D Cable Wired Remote-In Cable 10. RJ-45 Cable Wired Remote-Out Cable 11. Power Cord HDMI Cable 12. VGA-Out Cable RCA Component Cable 13. Wireless (Wi-Fi) Dongle VGA-In Cable 14.

  • Page 17: Adjusting The Projector Image

    sETUP anD InsTallaTIon adjusting the projector image Image height The projector is equipped with elevator feet for adjusting the image height. Locate the adjustable foot you wish to adjust on the underside of the projector. Rotate the adjustable foot clockwise or counterclockwise to raise or lower the projector. Tilt-Adjustment Feet Tilt-Adjustment Ring Zoom and focus...

  • Page 18: Remote Setup

    sETUP anD InsTallaTIon Remote setup Installing / replacing the batteries Two AAA size batteries are supplied for the remote control. Remove the battery cover on the back of the remote control. Insert AAA batteries in the battery compartment as illustrated. Replace back cover on remote control.
  • Page 19 sETUP anD InsTallaTIon Approx. ±30° Approx. ±30° English...

  • Page 20: Using The Projector

    UsInG THE PRoJECToR Powering on / off the projector Mode Info Auto Input Enter Menu Exit Powering on Gamma Bright Cont. Securely connect the power lead and signal/source cable. Set the Power switch to the “ON” position. Lens H Focus Turn on the projector by pressing “...

  • Page 21: Selecting An Input Source

    UsInG THE PRoJECToR selecting an input source Turn on the connected source that you want to display on the screen, such as computer, notebook, video player, etc. The projector will automatically detect the source. If multiple sources are connected, press the Input button on the projector keypad or the remote control to select the desired input.

  • Page 22: Menu Navigation And Features

    UsInG THE PRoJECToR menu navigation and features The projector has multilingual on-screen display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. To open the OSD menu, press "Menu" on the remote control or the projector keypad. When OSD is displayed, use pqtu to navigate within the menu and adjust a setting up or down.

  • Page 23: Osd Menu Tree

    UsInG THE PRoJECToR osD menu tree main menu sub menu sub menu 2 sub menu 3 sub menu 4 Values Presentation Video Bright Display Mode DICOM SIM By source set Blending User Save to User Brightness 0 ~ 100 Contrast 0 ~ 100 Sharpness 0 ~ 4...
  • Page 24 UsInG THE PRoJECToR main menu sub menu sub menu 2 sub menu 3 sub menu 4 Values Warmest Warm Color By source set Temperature Cool Bright REC709 Color Space REC601 Auto RGB Video Auto Red Gain 0 ~ 100 Green Gain 0 ~ 100 PICTURE Advanced...
  • Page 25 UsInG THE PRoJECToR main menu sub menu sub menu 2 sub menu 3 sub menu 4 Values HDMI Sub Source Component HDBaseT DVI-D Swap Small Size Medium Large Large OUTPUT PIP/PBP PBP, Main Left PBP, Main Top PBP, Main Right PBP, Main Bottom Layout...
  • Page 26 UsInG THE PRoJECToR main menu sub menu sub menu 2 sub menu 3 sub menu 4 Values Pin Protect PIN default : 12345 Change PIN DHCP by set IP Address by set Subnet Mask by set Default Gateway by set MAC Address Apply by set...
  • Page 27 UsInG THE PRoJECToR main menu sub menu sub menu 2 sub menu 3 sub menu 4 Values Logo Blue Background Logo Color Black White Blank Screen Aspect Ratio Hot-Key settings Blank Screen Freeze Screen Overscan 0.5W mode Standby Power 0.5W mode Communication Mode mode...
  • Page 28 UsInG THE PRoJECToR main menu sub menu sub menu 2 sub menu 3 sub menu 4 Values - Vert Refresh Sub Source - Resolution - Signal Format - Pixel Clock - Horz Refresh - Vert Refresh Light Source Information Mode Total Projector OPTION Hours...

  • Page 29: Picture Menu

    UsInG THE PRoJECToR PICTURE menu PICTURE PICTURE Display Mode Presentation Brightness Contrast oUTPUT Sharpness Color Tint sETUP Phase Frequency Horz Position oPTIon Vert Position PICTURE (1/2) PICTURE PICTURE Auto Image Color Matching Advanced oUTPUT sETUP oPTIon PICTURE (2/2) Display mode There are many factory presets optimized for various types of images.
  • Page 30 UsInG THE PRoJECToR sharpness Adjust the sharpness of the image. Color Adjust a video image from black and white to fully saturated color. Tint Adjust the color balance of red and green. Phase Synchronize the signal timing of the display with the graphic card. If the image appears to be unstable or flickers, use this function to correct it.
  • Page 31 UsInG THE PRoJECToR Color matching menu Color matching PICTURE Enable Auto Test Pattern Red Part of Red 1000 oUTPUT Green Part of Red Blue Part of Red Green Part of Green 1000 sETUP Red Part of Green Blue Part of Green Blue Part of Blue 1000 oPTIon...
  • Page 32 UsInG THE PRoJECToR Reset to Default Select “Yes” to reset all the color matching adjustments to the factory defaults or select “No” to keep the current values. advanced menu advanced PICTURE White Peaking Gamma VIdeo Color Temperature Bright oUTPUT Color Space Auto Color Settings Color Enhancement...
  • Page 33 UsInG THE PRoJECToR film mode Control film mode detection and determine whether the original source of the input video was film or video. note: This function is available for interlaced video signals. Extreme black Contrast can be increased by a dark content. Select “On” to let the projector will automatically improvement contrast or select “Off”...

  • Page 34: Output Menu

    UsInG THE PRoJECToR oUTPUT menu oUTPUT PICTURE Aspect Ratio Auto Overscan H Digital Zoom oUTPUT V Digital Zoom H Digital Shift V Digital Shift sETUP Image Warping PIP/PBP oPTIon aspect Ratio Choose your desired aspect ratio. ‡ auto: Automatically selects the appropriate display format. ‡...
  • Page 35 UsInG THE PRoJECToR Image Warping menu Image Warping PICTURE H Keystone V Keystone H Pincushion oUTPUT V Pincushion sETUP oPTIon H Keystone Adjust image distortion horizontally and make a squarer image. Horizontal keystone is used to correct a keystoned image shape in which the left and right borders of the image are unequal in length. This is intended for use with horizontally on-axis applications.
  • Page 36 UsInG THE PRoJECToR PIP/PbP menu PIP/PbP PICTURE PIP/PBP Enable Main Source Sub Source DVI-D oUTPUT Swap Size Large Layout PBP, Main Left sETUP oPTIon PIP/PbP Enable Toggle between displaying two sources at once (Main and PIP/PBP images) or one source only. main source From the list of active inputs, select one to be used as the main image.
  • Page 37 UsInG THE PRoJECToR PIP/PBP layout and size table as described below: PIP/PbP size PIP/PbP layout small medium large PBP, Main Left PBP, Main Top PBP, Main Right PBP, Main Bottom PIP-Bottom Right PIP-Bottom Left PIP-Top Left PIP-Top Right English...

  • Page 38: Setup Menu

    UsInG THE PRoJECToR sETUP menu sETUP PICTURE Language English Ceiling Mount Auto Rear Projection oUTPUT Lens Function Menu Preferences Keypad LED Settings sETUP Communications oPTIon language Choose the multilingual OSD menu. Ceiling mount Turn the image upside down for ceiling-mounted projection. Rear Projection Reverse the image so you can project from behind a translucent screen.
  • Page 39 UsInG THE PRoJECToR lens function menu lens function PICTURE Focus Zoom Lens Shift oUTPUT Lens Calibration Lens Lock sETUP oPTIon focus Adjust focus function on the projected image. Zoom Adjust zoom function on the projected image. lens shift Shift the projected image. lens Calibration Perform calibration and return lens to the center position.
  • Page 40 UsInG THE PRoJECToR menu Preferences menu menu Preferences PICTURE Menu Transparency Show Messages oUTPUT sETUP oPTIon menu Transparency Change OSD menu background to be transparent. show messages Display status messages on the screen. Pin menu PICTURE Pin Protect Change PIN oUTPUT sETUP oPTIon...
  • Page 41 UsInG THE PRoJECToR Communications menu Communications PICTURE WLAN Network oUTPUT Serial Port Baud Rate 19200 Serial Port Path RS232 Projector Address sETUP oPTIon Configure the local area network (LAN) settings. ‡ DHCP: Turn the DHCP ON/OFF. ‡ IP address: Select an IP address. ‡...
  • Page 42 UsInG THE PRoJECToR Projector address Set the projector address. The projector will respond to IR remotes set either at the same address as the projector or to IR remotes set to address 0. How to use web browser to control your projector Turn “On”...

  • Page 43: Setup Network Control Settings Menu

    UsInG THE PRoJECToR setup network control settings menu lan_RJ45 function For simplicity and ease of operation, the projector provides diverse networking and remote management features. The LAN / RJ45 function of the projector through a network, such as remotely manage: Power On / Off, Brightness and Contrast settings.
  • Page 44 UsInG THE PRoJECToR lan RJ45 (for Windows XP) Connect an RJ45 cable to RJ-45 connector on the projector and the PC (laptop). On the PC (Laptop), select start > Control Panel > network Connections. Right-click on the Local area Connection, and select Property. In the Properties window, select the General tab, and select Internet Protocol (TCP / IP).
  • Page 45 UsInG THE PRoJECToR Click “Properties”. Type in the IP address and Subnet mask, then press “OK”. Press the “Menu” button on the projector. Select sETUP > Communications > lan. Enter the following connection parameters: ± DHCP: Off ± IP Address: 10.10.10.10 ±...
  • Page 46 UsInG THE PRoJECToR Press “Enter”. The projector is setup for remote management. The LAN / RJ45 function displays as follows: Main page Information page Tool page Contact IT helpdesk English...
  • Page 47 UsInG THE PRoJECToR Rs232 by Telnet function There is alternative RS232 command control way, in projector so called “RS232 by TELNET” for LAN / RJ45 interface. Quick start-Guide for “Rs232 by Telnet” ‡ Check and get the IP address on OSD of the projector. ‡...

  • Page 48: Option Menu

    UsInG THE PRoJECToR oPTIon menu oPTIon PICTURE Auto Source High Altitude Test Pattern oUTPUT Background Color Logo Hot-Key settings Blank Screen Power Settings sETUP Light Source Settings Light Sensor Information oPTIon Factory Reset OPTION (1/2) oPTIon PICTURE Service oUTPUT sETUP oPTIon OPTION (2/2) auto source...
  • Page 49 UsInG THE PRoJECToR light source settings Configure the light source settings. Refer to “Light Source Settings menu” on page 51. light sensor ‡ light sensor Calibration: Calibrate the Light Sensor for use with the Constant Luminance mode, which allows the projector to be set for constant brightness. If the Light Sensor has not been calibrated, Constant Luminance mode will be disabled.
  • Page 50 USING THE PROJECTOR Power Settings menu Power Settings PICTURE Standby Power Mode Communication mode Direct Power On Auto Power Off 20 Mins OUTPUT Sleep Timer SETUP OPTION Standby Power Mode Set the standby power mode setting. ‡ 0.5W mode: The projector is in standby mode when connected to AC power. (<0.5W) ‡...
  • Page 51 USING THE PROJECTOR Light Source Settings menu Light Source Settings PICTURE Light Source Mode Constant Power Constant Power Settings Constant Luminance Settings OUTPUT Total Projector Hours SETUP OPTION Light Source Mode Set the light source mode setting. When “Eco Mode” is selected, the projector will adjust to the lowest fan speed and switch the laser diode power to the minimum setting.

  • Page 52: Additional Information

    aDDITIonal InfoRmaTIon Compatible resolutions Timing Table frame rate signal Type Resolution HDmI HDbaseT Component (Hz) 800x600 — 800x600 — 800x600 — 832x624 — 1024x768 — 1024x768 — 1152x870 — 1280x800 — 1280x1024 — 1280x1024 — 1400x1050 — 1440x900 — 1440x900 —...
  • Page 53 InfoRmaTIon EDID Table oPToma WUXGa EDID Table Digital Established Timing: Standard Timing: Detail Timing: 720 x 400 @ 70 Hz 1440 x 900 @ 75Hz 1920 x 1200 @ 60Hz 720 x 400 @ 88 Hz 1280 x 800 @ 75Hz...

  • Page 54: Image Size And Projection Distance

    ADDITIONAL INFORMATION Image size and projection distance Platform WUXGA (16:10) 0.67” Projection Lens Ultra-Long Wide Zoom Standard Long Zoom Short Throw Zoom Throw Ratio 0.95-1.22 1.22-1.53 1.53-2.92 2.90-5.50 0.75-0.95 Zoom Ratio 1.28X 1.25X 1.9X 1.9X 1.26X Throw Distance 1.03~7.88m 1.32~9.88m 1.65~18.86m 3.13~35.53m 0.81-6.14m...

  • Page 55: Projector Dimensions And Ceiling Mount Installation

    InfoRmaTIon Projector dimensions and ceiling mount installation To prevent damage to your projector, please use the Optoma ceiling mount. If you wish to use a third party ceiling mount kit, please ensure the screws used to attach a mount to the projector meet the following specifications: ‡...

  • Page 56: Ir Remote Codes

    aDDITIonal InfoRmaTIon IR remote codes Mode Info Auto Input Enter Menu Exit Gamma Bright Cont. Lens H Focus Lens V Keystone H Zoom Keystone V Shutter Hot Key Pattern (AV Mute) Address Data Repeat Key Legend Description Position Format Byte 1 Byte 2 Byte 3 Byte 4 Press to turn on the projector.
  • Page 57 aDDITIonal InfoRmaTIon Address Data Repeat Key Legend Description Position Format Byte 1 Byte 2 Byte 3 Byte 4 Use as numeric keypad number “6”. Use as numeric keypad number “7”. Use as numeric keypad number “8”. Use as numeric keypad number “9”. Info Press to display source image information.
  • Page 58 aDDITIonal InfoRmaTIon Address Data Repeat Key Legend Description Position Format Byte 1 Byte 2 Byte 3 Byte 4 Press to adjust the horizontal keystone. Keystone Keystone Press to adjust the horizontal keystone. Press to adjust zoom to achieve a desired Zoom ▼...

  • Page 59: Troubleshooting

    aDDITIonal InfoRmaTIon Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image problems No image appears on-screen ‡ Ensure all the cables and power connections are correctly and securely connected as described in the "Installation"...
  • Page 60 aDDITIonal InfoRmaTIon other problems The projector stops responding to all controls ‡ If possible, turn off the projector, then unplug the power cord and wait at least 20 seconds before reconnecting power. Remote control problems If the remote control does not work ‡...

  • Page 61: Warning Indicators

    aDDITIonal InfoRmaTIon Warning indicators lED status indicators The LED status indicators are located on the rear of the projector. Each LED is defined below. lED Type lED status Projector state Laser diode is off Solid Orange Laser diode time has expired Light LED Solid Green Laser diode is on and operating correctly...
  • Page 62 aDDITIonal InfoRmaTIon LAN Control Setting: LAN Control Port 9131 Crestron 41794 PJ-Link 4352 Telnet Http English...

  • Page 63: Specifications

    aDDITIonal InfoRmaTIon Specifications optical Description Resolution WUXGA (1920x1200) Lens Power Zoom/Focus 400W Laser Diode @ Normal operation Laser Diode 240W Laser Diode @ ECO operation Image size (diagonal) 50~300” Projection distance Please refer to “Image size and projection distance” table on page 54 Electrical Description 1 x HDMI (version1.4) (with locking screw)

  • Page 64: Optoma Global Offices

    InfoRmaTIon Optoma global offices For service or support, please contact your local office. Japan 3178 Laurelview Ct. 888-289-6786 東京都足立区綾瀬3-25-18 Fremont, CA 94538, USA 510-897-8601 info@os-worldwide.com 株式会社オーエス www.optomausa.com services@optoma.com 0120-380-495 www.os-worldwide.com コンタクトセンター: Canada Taiwan 3178 Laurelview Ct. 888-289-6786 12F., No.213, Sec. 3, Beixin Rd.,...
