NOISE
Noise can cause permanent hearing loss. Plasma arc processes can
cause noise levels to exceed safe limits. You must protect your ears
from loud noise to prevent permanent loss of hearing.
• To protect your hearing from loud noise, wear protective
ear plugs and/or ear muffs. Protect others in the work-
place.
• Noise levels should be measured to be sure the decibels
(sound) do not exceed safe levels.
• For information on how to test for noise, see item 1 in Sub-
section 1.03, Publications, in this manual.
PLASMA ARC RAYS
Plasma Arc Rays can injure your eyes and burn your skin. The
plasma arc process produces very bright ultra violet and infrared
light. These arc rays will damage your eyes and burn your skin if
you are not properly protected.
• To protect your eyes, always wear a welding helmet or shield.
Also always wear safety glasses with side shields, goggles
or other protective eye wear.
• Wear welding gloves and suitable clothing to protect your
skin from the arc rays and sparks.
Welding or Cutting
Operation
Torch soldering
Torch brazing
Oxygen Cutting
Light
Medium
Heavy
Gas welding
Light
Medium
Heavy
Shielded metal-arc
welding
(stick) electrodes
GENERAL INFORMATON
Eye protection fi lter shade selector for welding or cutting
(goggles or helmet), from AWS A6.2-73.
Electrode Size Filter
Metal Thickness Shade
3 or 4
Under 1 in., 25 mm 3 or 4
1 to 6 in., 25-150 mm 4 or 5
Over 6 in., 150 mm 5 or 6
Under 1/8 in., 3 mm 4 or 5
1/8 to 1/2 in., 3-12 mm 5 or 6
Over 1/2 in., 12 mm 6 or 8
Under 5/32 in., 4 mm
5/32 to 1/4 in.,
4 to 6.4 mm
Over 1/4 in., 6.4 mm
• Keep helmet and safety glasses in good condition. Replace
lenses when cracked, chipped or dirty.
• Protect others in the work area from the arc rays. Use protec-
tive booths, screens or shields.
• Use the shade of lens as suggested in the following per
ANSI/ASC Z49.1:
Arc Current
Less Than 300*
300 - 400*
400 - 800*
*These values apply where the actual arc is
clearly seen. Experience has shown that lighter
filters may be used when the arc is hidden by
the workpiece.
LEAD WARNING
This product contains chemicals, including lead, or otherwise
produces chemicals known to the State of California to cause
cancer, birth defects and other reproductive harm. Wash hands after
handling. (California Health & Safety Code § 25249.5 et seq.)
Welding or Cutting
Operation
Gas metal-arc
2
welding (MIG)
Non-ferrous base metal
Non-ferrous base metal
Gas tungsten arc welding
(TIG)
Atomic hydrogen welding
Carbon arc welding
Plasma arc welding
Carbon arc air gouging
10
12 Plasma arc cutting
14
Table 1-1
1-2
Minimum Protective Suggested
Shade No. Shade No.
8
9
10
Electrode Size
Metal Thickness
All
All
All
All
All
All
Light
Heavy
Light Under 300 Amp
Medium 300 to 400 Amp
Heavy Over 400 Amp
June 30, 2009
