Compressor Specifications - Viking VCSB483D Service Notebook

Also See for VCSB483D

Brochure & specs - 64 pages
Installation instructions manual - 42 pages
Installation manual - 24 pages

The VCC receives one of 3 signals from the adaptor board: OFF, E frequency, and H

frequency.

The VCC control signal is OFF whenever the voltage drive to the compressor relay is off.

H (HIGH COOLING CAPACITY) STATE CRITERIA

The VCC control signal goes to the

detected

The first compressor cycle after power restoration. The high capacity provides a faster

•

initial pull-down to control temperature

• The compressor duty cycle exceeds DCHT, 90%. Once triggered, this mode persists until

the duty cycle drops below DCHX, 50%. A high external ambient increases the duty

cycle.

• Compressor operation for more than 3 hours. The longest normal run time at 90° F is 2.5

to 3 hours. A longer run time implies the user activated the maximum refrigerate or

maximum freeze mode or there is an unusual cooling load. The mode persists until the

duty cycle drops below DCHX.

The VCC control signal assumes the E state when none of the conditions above for the H state

are valid.

Note: Compressor Speed = Frequency x Motor Constant

SPECIFICATIONS AND FEATURES

OFF STATE CRITERION

frequency when any of the following conditions are

E (EFFICIENT COOLING STATE CRITERION
