MIDI: Lights green when a MIDI connection is detected and active; flashes on
incoming or outgoing MIDI data.
• 48V: Lights orange when phantom power is activated.
•
USB: Lights green when the USB port is connected to a computer. Flashing indi-
cates a USB connection problem.
•
Headphones 1/2: Lights orange when there is outgoing signal on the headphone
outputs 1 and 2 (see 5.1 for headphone source settings).
•
Headphones 3/4: Lights orange when there is outgoing signal on the headphone
outputs 3 and 4 (see 5.1 for headphone source settings).
•
MONITOR 1/2: Lights orange when direct monitoring is activated with outputs 1/2
selected (see MONITOR section of chapter 5.1 for further information on direct
monitoring).
•
MONITOR 3/4: Lights orange when direct monitoring is activated with outputs 3/4
selected (see MONITOR section of chapter 5.1 for further information on direct
monitoring).
•
SPDIF SYNC: Lights orange when External Digital Clock Sync is established; does not
light when the internal clock is used (see chapters 6.1.1 and 6.2.1 for further infor-
mation on synchronizing the KOMPLETE AUDIO 6's clock to external equipment).
