Summary of Contents for Kleenmaid IVK61
- Page 1 Cooking c o l l e c t i o n Instructions for fitting and using your mixed induction-ceramic Warranty Details IVK61-600mm Induction-ceramic Cooktop The best you can own. 220-240 V 50Hz REF CONSTRUCTEUR 214...
- Page 2 ongratulations on the purchase of your new appliance. This appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service calls.
-
Page 3: Table Of Contents
List of contents Using your hob in complete safety......4 Containers............6-7 Installing your hob in complete safety......8 Using your hob in all simplicity......10 Preserving and maintaining your hob....12 Small problems and solutions.......13 Cooking ............14-15 In this Manual, displays safety instructions displays tips and hints... -
Page 4: Using Your Hob In Complete Safety
Using your hob in complete safety Overheat sensor • Each unit is equipped with a sensor that continuously monitors the temperature of the bottom of the pan, so that overheating is impossible (empty saucepan, etc.). • A sensor continuously monitors the temperature of the components of your hob. The power output by the hob will automatically be reduced if this temperature becomes excessive. - Page 5 Keypad lock Your cook top is equipped with a child safety feature which locks it during the use: - Either when stopped (for cleaning) - Or during cooking (any operations underway will continue and the displayed settings remain active). this case, for safety reasons only the "STOP" button is still usable. Don't forget to unlock the appliance before reusing it.
- Page 6 Your induction hob in complete safety The principles of induction Induced currents When your induction hob is switched on and a heating power has been selected, the electronic circuits produce induced currents that instantaneously heat the bottom of the pan that transfers this heat to the food.
- Page 7 Induction pan area • aluminium pans with special base. You probably already have some suitable pans. pans which do not have a flat base may be sui- Your induction hob is able to recognize most table, however they must not be badly deformed . types of pans.
- Page 8 Vitroceramic pan area Pans and casseroles must be designed for use with electric hobs. Use pans with flat bases that have good surface contact with the cooking zone surface. They must be made out of: - Stainless steel with a thick tri-metal or "sandwich" bottom. - In aluminium with a thick smooth bottom.
-
Page 9: Installing Your Hob In Complete Safety
Installing your hob in complete safety Always ensure that the air vents beneath the hob are kept clear. Your induction hob must always be adequately ventilated. Above a cupboard or drawer unit Above an oven 4 cm mini MINI 4 mm Ensure that the unit crossbar does not block the air passage, make a bevel if necessary. - Page 10 Installing your hob in complete safety Fitting A seal exists for preventing any humidity getting under the hob. -Stick the seal under the rim of the hob and lower the hob into position on the worktop. -This seal is supplied in the sachet;...
- Page 11 What your hob looks like? Ø 13/20 cm Ø 21 cm 750 W à 1700 W 50 W à 3100 W Ø 18 cm Ø 16 cm 1500 W 50 W à 2000 W TI 315 tart/Stop etting manual power The hob bleeps and a 0 blinks to indicate that the zone concerned has been turned on;...
-
Page 12: Using Your Hob In All Simplicity
Using your hob in all simplicity etting the timer* dditional zone depending on the model To start it up: Turn on your main cooking zone. Press down on the "extra" touch Operates when cooking zones concerned are control, a light will working. -
Page 13: Preserving And Maintaining Your Hob
Preserving and maintaining your hob You must not You must: Leave metal cooking utensils, knives and forks, Avoid any shocks with pans: or metal objects on the hob. They will get hot if The glass surface is highly resistant but not un- left close to any heating zone that is in use. -
Page 14: Cooking
Minor troubleshooting You have doubts about whether your hob is working correctly ..this does not necessarily mean there is a breakdown. Nevertheless, check the following points IF YOU REALIZE THAT POSSIBLE WHAT SHOULD CAUSES YOU DO? NOTHING: see chapter Remarks on When you switch on, the display lights up The hob is working normally connections... - Page 15 maximum power is reserved for frying and quick boiling. slow cooking boil with cover fast cooking add food boil or fry...
- Page 16 maximum power is reserved for frying and quick boiling. boil with cover slow cooking boil or fry add food fast cooking...
- Page 17 Other products available in the Kleenmaid Range of appliances Washers Dryers Dishwashers Ovens Cooktops Outdoor Cooking Centres Built In Espresso Coffee Machines Rangehoods Freestanding Ranges Sinks Waste Disposals Taps Cookware Refrigerators Freezers Wine Cellars Vacuum Cleaners For sales information on the full range of quality appliances...
