A S SE MB LY S T E P 3
HARDWARE BAG FOR STEP 3 CONTENTS :
BOLT (E)
(8 TOTAL)
9
MOUNTING BRACKET
SUPPORT BAR BOOTS
SUPPORT BARS
A Open HARDWARE BAG FOR
STEP 3.
B Slide SUPPORT BARS into side
MOUNTING BRACKETS and
line up with top MOUNTING
BRACKETS.
C Insert 2 BOLTS (E) into the
tops and 2 BOLTS (E) into the
bottoms of each SUPPORT BAR.
D Slide SUPPORT BAR BOOTS
down to cover BOLTS (E).
