3. Panel Feature

This specification applies to the 19 inch-wide Color TFT-LCD Module M190PW01.
The display supports the WXGA+ (1440(H) x 900(V)) screen format and 16.7M colors(RGB
6-bits+HiFRC). All input signals are 2-Channel LVDS interface compatible. This module does
not contain an inverter board for backlight.

3.1 General Specifications

3.2 Electrical Absolute Ratings

Item
Power Supply Voltage
Lamp voltage
Lamp Current
Lamp Frequency

3.3 Electrical Characteristics

a) TFT LCD module
Symbol Min
Vcc -0.3
Vblh 666
IL 3.0
FL 40
10
Typ Max
5 +6
700 814
6.5 8.0
50 80
AOCn941Splus
Unit
V
Vrms
mArms
kHz
