AOC n941S/plus Service Manual page 52

Service Manual
C116 065G060322422K
C116 065G060322422K
C439 065G060322515K
C443 065G0805475A2K
C442 065G0805475A2K
C430 065G0805475A2K
FB404 071G 56K121
FB408 071G 56K121
FB404 071G 56K121 M
FB408 071G 56K121 M
FB405 071G 56V301 B
FB407 071G 56V301 B
FB407 071G 56V301 M
FB405 071G 56V301 M
FB407 071G 56V301 TA
FB405 071G 56V301 TA
FB101 071G 59K190 M
FB102 071G 59K190 M
FB103 071G 59K190 M
FB103 071G 59K190 TA
FB102 071G 59K190 TA
FB101 071G 59K190 TA
D101 093G 64 42 L
D101 093G 64 42 P
ZD104 093G 39GA01 T
ZD103 093G 39GA01 T
J33G8B42 1 1C9073
SMTKEPCAJA9
CN001 033G8032 6F X
CN001 033G8032 6F HR
R003 061G0603000 FT
R003 061G0603000 JF
R005 061G06031001FT
R005 061G06031001FY
R004 061G06032001FF
R002 061G06032001FF
R002 061G06032001FT
R004 061G06032001FT
LED01 081G 14501 GP
E715 715G4007K01000004F
E715 715G4007K01000004L
P40GD000813 9A
PWPC921GA3J
GND1 009G6005 1
CN801 033G8021 2E F
CN802 033G8021 2E F
CN801 033G8021 2E L
CN802 033G8021 2E L
CN801 033G8021 2E XY
CN802 033G8021 2E XY
T CAP CHIP0603 220NF K 25V X7R
Y CAP 0603 220N 25V X7R 10%
T CAP 0603 2.2UF 10% 16V X5R
T CAP CHIP 0805 4.7uF K 10V X7R
T CAP CHIP 0805 4.7uF K 10V X7R
T CAP CHIP 0805 4.7uF K 10V X7R
HF CHIP BEAD 0805 120R 25%
HF CHIP BEAD 0805 120R 25%
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
CHIP BEAD 120OHM 6A MGLB2012-120T-LF
CHIP BEAD 0805 300R 25% 700mA
CHIP BEAD 0805 300R 25% 700mA
CHIP BEAD 0805 300R 25% 700mA
CHIP BEAD 0805 300R 25% 700mA
CHIP BD 0805 300R/700mA FCM2012VF-301T07
CHIP BD 0805 300R/700mA FCM2012VF-301T07
CHIP BEAD 0603 19R/500mA
CHIP BEAD 0603 19R/500mA
CHIP BEAD 0603 19R/500mA
CHIP BEAD 0603 19R 25% FCB1608KF-190T05
CHIP BEAD 0603 19R 25% FCB1608KF-190T05
CHIP BEAD 0603 19R 25% FCB1608KF-190T05
DIODE LBAV70LT1G SOT-23 LRC
BAV70 SOT23 BY PAN JIT
RLZ5.6B
RLZ5.6B
KEY PAD
key board for smt
WAFER 6P 1.25MM
CONNECTOR 6P 1.25
NO-SUGGEST 0.01r MAX 1/10W TZAI YUAN
RST CHIPR MAX 0R05 1/10W FENGHUA
RST CHIP 1K 1/10W 1%
RST CHIPR 1KOHM +-1% 1/10W YAGEO
RST CHIP 2KOHM 1% 1/10W FENGHUA
RST CHIP 2KOHM 1% 1/10W FENGHUA
RST CHIP R 2Kohm 1/10W +/-1%
RST CHIP R 2Kohm 1/10W +/-1%
LED GPTD1210YGC3-HB
KEY PCB FR4 DS 106.5X14.5MM T1.6MM
KEY PCB FR-4 106.5X14.5MM T1.6MM
FAMILY SHEET
POWER G2892-4-2-X-25-100824(L)
GND TERMINAL
CONNECTOR
CONNECTOR
INVERT CONN 3.5mm 2P
INVERT CONN 3.5mm 2P
CONNECTOR
CONNECTOR
52
AOCn941Splus
1
2nd source
1
1
1
1
2nd source
2nd source
1
1
2nd source
2nd source
1
1
2nd source
2nd source
1
1
1
2nd source
2nd source
2nd source
1
2nd source
1
1
1
1
1
2nd source
2nd source
1
1
2nd source
1
1
2nd source
2nd source
1
1
2nd source
1
1
1
2nd source
2nd source
1
1
2nd source
2nd source
