- Page 1 OLED Monitor As an OLED product, this display needs regular screen maintenance to reduce the risk of image retention (burn-in). User Manual AG276QZD2 www.aoc.com ® 2024 AOC.All Rights Reserved ©...
-
Page 2: Table Of Contents
Safety ....................................1 Notational Conventions ............................. 1 Power ..................................2 Installation ................................. 3 Cleaning ..................................4 Other ..................................5 Setup ....................................6 Contents in Box ................................. 6 Setup Stand & Base ..............................7 Adjusting the monitor ..............................9 Connecting the Monitor ............................10 Wall Mounting................................11 Adaptive-Sync function ............................ -
Page 3: Safety
Safety Notational Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system. -
Page 4: Power
Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. -
Page 5: Installation
Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product. -
Page 6: Cleaning
Cleaning Clean the cabinet regularly with a water-dampened, soft cloth. When cleaning use a soft cotton or microfiber cloth. The cloth should be damp and almost dry, do not allow liquid into the case. Please disconnect the power cord before cleaning the product. -
Page 7: Other
Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the OLED monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation. -
Page 8: Setup
Warranty card Stand Base Screwdriver Bracket Screws USB Cable Power Cable Adaptor DP Cable HDMI Cable Not all signal cables will be provided for all countries and regions. Please check with the local dealer or AOC branch office for confirmation. -
Page 9: Setup Stand & Base
Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:... - Page 10 Wall hanger： 100mm 100mm Specification of wall hanger screws：M4*12mm M=4.0Max M4-P0.7 Dk=8.0 H=2.0 L=12+X Specification for base screw: M6*12 mm (effective thread 5.5 mm)
-
Page 11: Adjusting The Monitor
Adjusting the monitor For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand to steady the monitor, and grasp only the bezel to adjust the monitor’s angle. You are able to adjust the monitor as below: 30°... -
Page 12: Connecting The Monitor
Connecting the Monitor Cable Connections In Back of Monitor: 1. Power 2. HDMI1 3. HDMI2 4. DP1 5. DP2 6. USB3.2 Gen1 upstream 7. USB3.2 Gen1 downstream + fast charging USB3.2 Gen1 downstream x1 8. Earphone Connect to PC 1. Connect the power cord to the back of the display firmly. 2. -
Page 13: Wall Mounting
4. Reconnect the cables. Refer to the user’s manual that came with the optional wall mounting arm for instructions on attaching it to the wall. Noted: VESA mounting screw holes are not available for all models, please check with the dealer or official department of AOC. 0° 90°... -
Page 14: Adaptive-Sync Function
Adaptive-Sync function 1. Adaptive-Sync function is working with DP/HDMI 2. Compatible Graphics Card: Recommend list is as the below, also could be checked by visiting www.AMD.com Graphics Cards • Radeon™ RX Vega series • Radeon™ RX 500 series • Radeon™ RX 400 series •... -
Page 15: Hdr
This monitor is compatible with HDR10 formatted input signals. The display may automatically activate the HDR function if the player and content are compatible. Please contact the device manufacturer and the content provider for information on the compatibility of your device and content. If you have no need for the automatically activated HDR functions, please select “OFF”... -
Page 16: Screen Maintenance
Screen Maintenance To reduce the risk of image retention on the screen, regularly conduct the following maintenance. Not following these ins- tructions may void your warranty. • Avoid displaying a still image for extended periods. A still image refers to an image that does not change over time, such as a photograph. A still image may result in permanent damage to the OLED screen, causing the image to continue to appear when no longer actively being shown. - Page 17 After every 4 hours of cumulative operation, the screen compensation correction and image residue elimination function will automatically run when the display is turned off, or has been in standby for 2 hours. During this operation keep the power on. The monitor will first run the screen compensation correction function which will take about 30 seconds.
-
Page 18: Adjusting
Adjusting Hotkeys Source/Up Dial Point/Down Game Mode/Left Light FX /Right Power/ Menu/Enter Power/Menu/Enter Press the Power button to turn on the monitor. When there is no OSD, Press to display the OSD or confirm the selection. Press about 2 seconds to turn off the monitor. Dial Point/Down When there is no OSD, press Dial Point button to show / hide Dial Point. -
Page 19: Osd Key Guide (Menu)
OSD Key Guide (Menu) Enter Move Exit Enter : Use Enter key to enter the next OSD level Move : Use Left / Up / Down key to move OSD selection Exit : Use Right key to exit OSD Enter Move Exit Enter : Use Enter key to enter the next OSD level... - Page 20 Enter Select Select : Use Up / Down key to adjust OSD setting Enter Select Enter : Use Enter key to exit OSD to previous OSD level Select : Use Left / Right key to adjust OSD setting...
-
Page 21: Osd Setting
OSD Setting Basic and simple instruction on the control keys. PIP Se�ng Color Setup PIP Se�ng Audio Light FX OLED Care/Extra Audio Light FX OSD Setup Enter Move Exit Enter Move Exit 1). Press the MENU-button to activate the OSD window. 2). -
Page 22: Game Setting
Game Setting Game Setting Game Mode Shadow Control Game Color Sniper Scope Adaptive-Sync Low Input Lag Frame Counter Exit Enter Select No optimization by Game Mode. For playing FPS (First Person Shooters) games. Improves dark theme black level details. For playing RTS (Real Time Strategy). Improves the image quality. - Page 23 Shutting down the frame buffer can reduce input delay. Note: Low input delay is disabled by default and unadjust- Low Input lag On / Off able when the field frequency is less than 120 Hz; and it is enabled by default and unadjustable when the field frequen- cy is equal to 120 Hz and in the G-SYNC state.
-
Page 24: Luminance
Luminance Luminance Contrast Brightness Dark Boost ECO Mode Standard Gamma Gamma1 Exit Enter Select... - Page 25 Contrast 0-100 Contrast from Digital-register. Brightness 0-100 Backlight Adjustment Level 1 Dark Boost Level 2 Level 3 Standard Standard Mode Text Text Mode Internet Internet Mode Eco mode Game Game Mode Movie Movie Mode Sports Sports Mode Reading Reading Mode Gamma1 Adjust to Gamma 1 Gamma...
-
Page 26: Pip Setting
PIP Setting Disable or Enable PIP or PIP Setting Off / PIP / PBP PBP. Main Source Select main screen source. Sub Source Select sub screen source. Size Small / Middle / Large Select screen size. Right-up Right-down Position Set the screen location. Left-up Left-down Disable or Enable Audio... -
Page 27: Color Setup
Color Setup Color Setup LowBlue Mode Color Temp. Warm Color Gamut Panel Native Green Blue Exit Enter Select Off / Multimedia Decrease blue light wave by controlling color LowBlue Mode / Internet / Office temperature. / Reading Warm Recall Warm Color Temperature from EEPROM. Recall Normal Color Temperature from Normal EEPROM. -
Page 28: Audio
Audio Audio Volume Exit Enter Select Volume 0-100 Adjust volume setting... -
Page 29: Light Fx
Light FX Light FX Light FX Medium Light FX Mode Static Pattern Rainbow Foreground R Foreground G Foreground B Background R Background G Background B Exit Enter Select Off / Low / Medium / Light FX Select the intensity of Light FX. Strong Audio1 / Audio2 / Static / Dark Point Sweep /... -
Page 30: Extra
Extra OLED Care/Extra Pixel Orbiting Weak Auto Warning Pixel Refresh Screen Saver Logos Protection Resolution: 2560(H)x1440(V) SDR H.Frequency: 97 KHz V.Frequency: 60 Hz Exit Enter Select Orbit will slightly shift the displayed image at the pixel level, once a second to prevent image retention. - Page 31 When a static image is detected for a certain period of time, the screen saver function will dim the screen to protect the panel from sticking. When a moving image is detected, the monitor will recover luminance to previous working Screen Saver status.
-
Page 32: Osd Setup
OSD Setup OSD Setup Language English Timeout DP Capability 1.2/1.4 H.Position V.Position Transparence Break Reminder Exit Enter Select Language Select the OSD language Timeout 5-120 Adjust the OSD Timeout DP Capability 1.1/1.2/1.4 Note: Only DP1.2/DP1.4 support G-SYNC functionality. H. Position 0-100 Adjust the horizontal position of OSD V. -
Page 33: Led Indicator
LED Indicator Status LED Color Full Power Mode White Active-off Mode Orange Pixel Refresh under Flashing White (1 second on/1 second off) process JB under process Flashing White (3 seconds on/3 seconds off) OLED panel malfunction Flashing Orange (1 second on/1 second off) Shutdown mode The indicator is not lit. -
Page 34: Troubleshooting
Refer to the “Screen Maintenance” section. Please refer to Regulation & Service Information which is in the CD manual Regulation & Service or www.aoc.com (to find the model you purchase in your country and to find Regulation & Service Information in Support page. -
Page 35: Specification
Specification General Specification Model Name AG276QZD2 Driving System OLED Panel Viewable Image Size 67.3 cm Diagonal Pixel Pitch 0.2292mm(H) x 0.2292mm(V) Display Color 1.07B Colors 30k~360kHz(DP) Horizontal Scan Range 30k~230kHz(HDMI) Horizontal scan Size(Maximum) 590.42 48~144Hz (HDMI) Vertical Scan Range 48~240Hz (DP) Vertical Scan Size(Maximum) 333.72 Optimal Preset Resolution... - Page 36 Note: 1)The maximum number of display colors supported by this product is 1.07 billion, and the setting conditions are as follows (there may be differences due to the output limitation of some graphics cards): HDMI2.0 DisplayPort1.4 YCbCr422 YCbCr444 YCbCr422 YCbCr444 YCbCr420 YCbCr420 2560x1440 240Hz 10bits...
-
Page 37: Preset Display Modes
Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION (±1Hz) FREQUENCY(kHz) FREQUENCY(Hz) 640×480@60Hz 31.469 59.940 640x480@72Hz 37.861 72.809 Color Bit 640x480@75Hz 37.500 75.000 640x480@100Hz 51.080 99.769 640x480@120Hz 60.938 119.720 800x600@56Hz 35.156 56.250 800×600@60Hz 37.879 60.317 800x600@72Hz 48.077 72.188 SVGA 800x600@75Hz 46.875 75.000 800x600@100Hz 62.760 99.778... -
Page 38: Pin Assignments
Note: According to the VESA standard, different operating systems and graphics cards may have certain errors (+/-1Hz) on resoution. Actual please refer to the actual product. Pin Assignments 19-Pin Color Display Signal Cable Pin No. Signal Name Pin No. Signal Name Pin No. -
Page 39: Plug And Play
Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.
