Service Manual

1. LCD Specifications

1.1 Product Features

Monitor
LCD Panel
Input
Power Consumption
Dimensions
Model
Driving system
Active Display Area
Pixel Pitch
Display Colors
Max. Resolution
Video
Separate Sync.
H-Frequency
V-Frequency
Dot Clock
Plug & Play
Connector
USB HUB
OSD
ON Mode
Power Saving Mode
Switch OFF
Power Source
(including stand)
Weight (N. W.):
Environmental
Considerations
Safety
AOC n941S/plus
TFT Color LCD
481mm（19inch） diagpnal
408.24mm (W)×255.15mm(H)
0.2835 mm×0.2835mm
16.7M Colors
1440 x 900@75Hz
R,G,B Analog Interface，75ohm,0.7V
H/V TTL
30kHz—80kHz
55Hz--75Hz
136.75MHz
VESA DDC2B /CI
D-Sub 15pin
No
language
14 OSD menu
<25W
<0.5W
<0.5W
90~264VAC,47~63Hz, 1.5A Max supply current
456.75mm×375.5mm×149.85mm
3.5kg
Operating Temp: 0° to 40°C
Storage Temp.: -25° to 55°C
Operating Humidity : 10% to 85%
Altitude:
Operating ：0~ 3658m (0~ 12000 ft )
Non-Operating：0~ 12192m (0~ 40000 ft )
FCC B CCC IEC950CB etc.
