  • Page 1 ©2016 AOC. All Rights Reserved.

  • Page 2: Table Of Contents

    Safety ..................................4 National Conventions ............................4 Power ................................5 Installation................................6 Cleaning ................................7 Other .................................. 8 Setup ..................................9 Contents in Box ............................... 9 Setup Stand & Base ............................10 Connecting the Monitor ............................ 11 Adjusting ................................. 12 Setting Optimal Resolution ..........................
  • Page 3 Regulation ................................56 FCC Notice ..............................57 WEEE Declaration ............................58 RoHS Declaration for India..........................58 Service ..................................59 Warranty Statement for Europe........................59 Warranty Statement for Middle East and Africa (MEA) ...................61 AOC International (Europe) B.V........................63 Warranty Statement ...........................64 EASE PROGRAME ............................6...

  • Page 4: Safety

    Safety National Conventions The following subsections describe notational conventions used in this document. Notes, Cautions, and Warnings Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type or in italic type. These blocks are notes, cautions, and warnings, and they are used as follows: NOTE: A NOTE indicates important information that helps you make better use of your computer system.

  • Page 5: Power

    Power The monitor should be operated only from the type of power source indicated on the label. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect the monitor from damage due to power surges.

  • Page 6: Installation

    Installation Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by the manufacturer or sold with this product.

  • Page 7: Cleaning

    Cleaning Clean the cabinet regularly with cloth. You can use soft-detergent to wipe out the stain, instead of strong-detergent which will cauterize the product cabinet. When cleaning, make sure no detergent is leaked into the product. The cleaning cloth should not be too rough as it will scratch the screen surface.

  • Page 8: Other

    Other If the product is emitting a strange smell, sound or smoke, disconnect the power plug IMMEDIATELY and contact a Service Center. Make sure that the ventilating openings are not blocked by a table or curtain. Do not engage the LCD monitor in severe vibration or high impact conditions during operation. Do not knock or drop the monitor during operation or transportation.

  • Page 9: Contents In Box

    A nalog Cable DVI Cable check wit h the Not al l signal cables s (Analog, DV I cables) w ill be provided d for all countries and region ns. Please local dea aler or AOC b ranch office fo or confirmation...

  • Page 10: Setup

    Setup Stand & Base Please setup or remove the base following the steps as below. Setup: Remove:...

  • Page 11: Connecting The Monitor

    Connecting the Monitor Cable Connections In Back of Monitor and Computer: Power D-SUB To protect equipment, always turn off the PC and LCD monitor before connecting. Connect the power cable to the AC port on the back of the monitor. Connect one end of the DVI cable to the back of the monitor and connect the other end to the computer’s DVI port.

  • Page 12: Adjusting

    Adjusting Setting Optimal Resolution Windows 10 For Windows 10: • Right click START. • Click "CONTROL PANEL". • Click "DISPLAY".
  • Page 13 • Click on the "Change display settings" button. • Set the resolution SLIDE-BAR to Optimal preset resolution.

  • Page 14: Windows 8

    Windows 8 For Windows 8: • Right click and click All apps at the bottom-right of the screen. • Set the "View by" to "Category". • Click "Appearance and Personalization".
  • Page 15 • Click "DISPLAY". • Set the resolution SLIDE-BAR to Optimal preset resolution...

  • Page 16: Windows 7

    Windows 7 For Windows 7: • Click START. • Click "CONTROL PANEL". • Click "Appearance". • Click "DISPLAY".
  • Page 17 • Click on the "Change display settings" button. • Set the resolution SLIDE-BAR to Optimal preset resolution...

  • Page 18: Hotkeys

    Hotkeys Sourc e/Auto/Exit Image Ratio/ ∧ /∨ Clear Vision Menu/Enter Power Power Press the Power button to turn on/off the monitor. ∧ When there is no OSD, press hotkey continuously to change 4:3 or wide image ratio. (If the product screen size ∧...
  • Page 19 Clear Vision When there is no OSD, Press the left button to activate Clear Vision. Use the left or right buttons to select between weak, medium, strong, or off settings. Default setting is always “off”. Press and hold left button for 5 seconds to activate the Clear Vision Demo, and a message of “Clear Vision Demo: on”...

  • Page 20: Osd Setting

    OSD Setting Basic and simple instruction on the control keys. Press the MENU button to activate the OSD window. Press left button or right button to navigate through the functions. Once the desired function is highlighted, press the MENU button to activate. Press left button or right button to navigate through the sub-menu.

  • Page 21: Luminance

    Luminance 1 Press (Menu) to display menu. 2 Press left button or right button to select (Luminance), and press to enter. to enter. 3 Press left button or right button to select submenu, and press...
  • Page 22 4 Press left button or right button to adjust. 5 Press to exit Brightness 0-100 Backlight Adjustment. Contrast 0-100 Contrast from Digital-register. Standard Standard Mode. Text Text Mode. Internet Internet Mode. Eco mode Game Game Mode. Movie Movie Mode. Sports Sports Mode.

  • Page 23: Image Setup

    Image Setup 1 Press (Menu) to display menu. 2 Press left button or right button to select (Image Setup), and press to enter. 3 Press left button or right button to select submenu, and press to enter.
  • Page 24 4 Press left button or right button to adjust. 5 Press to exit Clock 0-100 Adjust picture Clock to reduce Vertical-Line noise. Phase 0-100 Adjust Picture Phase to reduce Horizontal-Line noise. Sharpness 0-100 Adjust picture sharpness. H.Position 0-100 Adjust the horizontal position of the picture. V.Position 0-100 Adjust the vertical position of the picture.
  • Page 25 Color Setup 1 Press (Menu) to display menu. 2 Press left button or right button to select (Color Setup), and press to enter. to enter. 3 Press left button or right button to select submenu, and press...

  • Page 26: Color Setup

    4 Press left button or right button to adjust. 5 Press to exit Warm Recall Warm Color Temperature from EEPROM. Normal Recall Normal Color Temperature from EEPROM. Cool Recall Cool Color Temperature from EEPROM. Color setup. sRGB Recall SRGB Color Temperature from EEPROM. Red Gain from Digital-register.

  • Page 27: Picture Boost

    Picture Boost 1 Press (Menu) to display menu. 2 Press left button or right button to select (Picture Boost), and press to enter. 3 Press left button or right button to select submenu, and press to enter.
  • Page 28 4 Press left button or right button to adjust. 5 Press to exit Frame Size 14-100 Adjust Frame Size. Brightness 0-100 Adjust Frame Brightness. Contrast 0-100 Adjust Frame Contrast. H. position 0-100 Adjust Frame horizontal position. V. position 0-100 Adjust Frame vertical position. Bright Frame on or off Disable or Enable Bright Frame.

  • Page 29: Osd Setup

    OSD Setup 1 Press (Menu) to display menu. 2 Press left button or right button to select (OSD Setup), and press to enter. 3 Press left button or right button to select submenu, and press to enter.
  • Page 30 4 Press left button or right button to adjust. 5 Press to exit H. Position 0-100 Adjust the horizontal position of OSD. V. Position 0-100 Adjust the vertical position of OSD. Timeout 5-120 Adjust the OSD Timeout. Transparence 0-100 Adjust the transparence of OSD. Language Select the OSD language.

  • Page 31: Extra

    Extra 1 Press (Menu) to display menu. 2 Press left button or right button to select (Extra), and press to enter. 3 Press left button or right button to select submenu, and press to enter.
  • Page 32 4 Press left button or right button to adjust. 5 Press to exit Input Select Auto / Analog / DVI Select input signal source. Auto Config yes or no Auto adjust the picture to default. Off timer 0-24hrs Select DC off time. Image Ratio wide or 4:3 Select wide or 4:3 format for display.

  • Page 33: Exit

    Exit 1 Press (Menu) to display menu. 2 Press left button or right button to select (Exit), and press to enter. 3 Press to exit Exit Exit the main OSD. LED Indicator Status LED Color Full Power Mode Blue Active-off Mode...

  • Page 34: Driver

    Driver Monitor Driver Windows 10 • Start Windows® 10 • Right click START. • Click "Control Panel". • Click on the "Display" icon.
  • Page 35 Click on the "Change display settings" button • • Click the "Advanced Settings" button.
  • Page 36 • button. Click the "Monitor" tab and then click the "Properties" • Click the "Driver" tab. • Open the "Update Driver Software-Generic PnP Monitor" window by clicking on "Update Driver... “and then click the "Browse my computer for driver software" button.
  • Page 37 • Se lect "Let me pick from a list of device drivers on my computer". • Click the "Have Disk" button. Click on the "Browse" button and navigate to the following directory: X:\Driver\module name(where X is the drive letter designator for the CD-ROM drive). •...

  • Page 38: Windows 8

    • Close all open windows and remove the CD. • Restart the system. The system will automatically select the maximum refresh rate and corresponding Color Matching Profiles. Windows 8 • Start Windows® 8 • Right click and click All apps at the bottom-right of the screen. •...
  • Page 39 • Click on the "Display" icon. • Click on the "Change display settings" button. • Click the "Advanced Settings" button.
  • Page 40 button • Click the "Monitor" tab and then click the "Properties" • Click the "Driver" tab.
  • Page 41 • Open the "Update Driver Software-Generic PnP Monitor" window by clicking on "Update Driver..." and then click the "Browse my computer for driver software" button. • Select "Let me pick from a list of device drivers on my computer". • Click the "Have Disk"...
  • Page 42 • Select the "xxx.inf" file and click the "Open" button. Click the "OK" button. • Select your monitor model and click the "Next" button. The files will be copied from the CD to your hard disk drive. • Close all open windows and remove the CD. •...

  • Page 43: Windows 7

    Windows 7 • Start Windows® 7 • Click on the "Start" button and then click on "Control Panel". • Click on the "Display" icon. Click on the "Change display settings" button. •...
  • Page 44 • Click the "Advanced Settings" button. • button. Click the "Monitor" tab and then click the "Properties" • Click the "Driver" tab.
  • Page 45 • Open the "Update Driver Software-Generic PnP Monitor" window by clicking on “Update Driver... " and then click the "Browse my computer for driver software" button. • Se lect "Let me pick from a list of device drivers on my computer". •...
  • Page 46 • Select the "xxx.inf" file and click the "Open" button. Click the "OK" button. • Select your monitor model and click the "Next" button. The files will be copied from the CD to your hard disk drive. • Close all open windows and remove the CD. •...

  • Page 47: I-Menu

    Welcome to “i-Menu” software by AOC. i-Menu makes it easy to adjust your monitor display setting by using on screen menus instead of the OSD button on the monitor. To complete installation, please follow the installation guide. The software Supported operating systems: Windows 8, Windows 7, Windows Vista, Windows XP.

  • Page 48: E-Saver

    Welcome to use AOC e-Saver monitor power management software! The AOC e-Saver features Smart Shutdown functions for your monitors, allows your monitor to timely shutdown when PC unit is at any status (On, Off, Sleep or Screen Saver); the actual shutdown time depends on your preferences (see example below).

  • Page 49: Screen

    Screen+ Welcome to "Screen+" software by AOC. Screen+ software is a desktop screen splitting tool; it splits the desktop into different panels, and each panel displays a different window. You only need to drag the window to a corresponding panel when you want to access it. It supports multiple monitor display to make your task easier.

  • Page 50: Troubleshoot

    Adjust the maximum resolution and frequency that the monitor can handle properly. Make sure the AOC Monitor Drivers are installed. Adjust the Contrast and Brightness Controls. Press for auto adjust.
  • Page 51 Move electrical devices that may cause electrical interference as far away Picture Bounces, Flickers Or from the monitor as possible. Wave Pattern Appears In The Use the maximum refresh rate your monitor is capable of at the resolution Picture you are using. The Computer Power Switch should be in the ON position.

  • Page 52: Specification

    Specification General Specification Model name I3207VW3 Driving system TFT Color LCD Viewable Image Size 80.1cm diagonal Pixel pitch 0.36375(H)mm x 0.36375(V)mm Panel Video R, G, B Analog lnterface & DVI lnterface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock...

  • Page 53: Preset Display Modes

    Preset Display Modes HORIZONTAL VERTICAL STANDARD RESOLUTION FREQUENCY(kHZ) FREQUENCY(Hz) IBM MODES 640x350@70Hz 31.469 70.087 640x480@60Hz 31.469 59.940 640x480@72Hz 37.861 72.809 640x480@75Hz 37.500 75.00 IBM MODES 640x480@67Hz 35.000 66.667 MAC MODE 720x400@70Hz 31.469 70.087 800x600@56Hz 35.156 56.250 800x600@60Hz 37.879 60.317 SVGA 800x600@72Hz 48.077 72.188...

  • Page 54: Pin Assignments

    Pin Assignments 15-Pin Side of the 15-Pin Side of the Pin Number Pin Number Signal Cable Signal Cable Video-Red Video-Green Ground Video-Blue N.C. N.C. DDC-Serial data Detect Cable H-sync GND-R V-sync GND-G DDC-Serial clock GND-B 24-Pin Color Display Signal 24-Pin Color Display Signal Pin Number Pin Number Cable...

  • Page 55: Plug And Play

    Plug and Play Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.

  • Page 56: Regulation

    Regulation FCC Notice FCC Class B Radio Frequency Interference Statement WARNING: (FOR FCC CERTIFIED MODELS) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 57: Weee Declaration

    Helpline number: 080-6788-6788 / 080-3323-1313 (Monday to Saturday, 10 a.m. to 6 p.m.) Centralized E-waste collection center Address: TPV Technology India Private Limited, 59, Maheswari Nagar, 1st Main Road, Mahadevapura Post, Whitefield Road, Bangalore, Karnataka, PIN: 560048, Tel: 080-3023-1000 E-mail: serviceindia@aoc.com...

  • Page 58: Rohs Declaration For India

    Reduction in the use of hazardous substances (India) This product complies with the “E-Waste (Management) Rules, 2016” CHAPTER V, rule 16, sub-rule (1) . Whereas New Electrical and Electronic Equipment and their components or consumables or parts or spares do not contain Lead, Mercury, Cadmium, Hexavalent Chromium, polybrominated biphenyls and polybrominated diphenyl ethers beyond a maximum concentration value of 0.1% by weight in homogenous materials for lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers and of 0.01% by weight in homogenous...

  • Page 59: Service

    The freight cost for the warranty is pre-paid by AOC for the delivery and return. Please ensure you provide a dated proof of purchase along with the product and deliver to the AOC Certified or Authorized Service Center under the following condition: •...
  • Page 60 If your warranty has expired, you still have access to all available service options, but you will be responsible for the cost of service, including parts, labor, shipping (if any) and applicable taxes. AOC Certified or Authorized Service Center will provide you with an estimate of service costs before receiving your authorization to perform service.

  • Page 61: Warranty Statement For Middle East And Africa (Mea)

    During this period, AOC International (Europe) B.V. offers a Carry-In (return to Service Center) Warranty Support at an AOC’s Authorized Service Center or Dealer and at its option, either repair the defective product with new or rebuilt parts, or replace it with a new or rebuilt product at no charge except as *stated below. As a Standard Policy,...
  • Page 62 • Repair, modification, or installation of options or parts by anyone other than an AOC Certified or Authorized Service Center • Improper environments like humidity, water damage and dusts • Damaged by violence, earthquakes and terrorist attacks • Excessive or inadequate heating or air conditioning or electrical powers failures, surges, or other...

  • Page 63: Aoc International (Europe) B.v

    No manufacturer can guarantee that all panels will be free from pixel defects, but AOC guarantees that any monitor with an unacceptable number of defects will be repaired or replaced under warranty. This Pixel Policy explains the different types of pixel defects and defines acceptable defect levels for each type.

  • Page 64: Warranty Statement

    WARRANTY STATEMENT For AOC Color Monitors Including those Sold within North America as Specified Envision Peripherals, Inc. warrants this product to be free from defects in material and workmanship for a period of three (3) years for parts & labor, one (1) year for the LCD panel, after the original date of consumer purchase.
  • Page 65  Storage or use in improper environments including excessive or inadequate heating or cooling  Electrical power failures, surges, or other electrical irregularities  Shipping damage from store to end user or from end user to AOC authorized service center  Improper handling or installation ...
  • Page 66 RIGHTS. YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE. In the United States of America, this limited warranty is only valid for Products purchased in the Continental United States, Alaska, and Hawaii. Outside the United States of America, this limited warranty is only valid for Products purchased in Canada. For Service in South America, refer to the SA Service Center List included with the product.
  • Page 67 *AOC will need to obtain a credit card number if you would like to get a new AOC monitor advanced shipped to your location, prior to the defective unit arriving at AOC’s service center. If you do not wish to supply a credit card, AOC will only ship the new monitor, once the defective unit arrives at the AOC service center.
