3. To reassemble the door, put the hinges in
the relevant slots in the oven, making sure
that grooved sections A are resting
completely in the slots. Lower the door
and once it is in place remove the pins
from the holes in the hinges.

4.4 Cleaning the door glazing

The glass in the door should always be kept
thoroughly clean. Use absorbent kitchen
roll. In case of stubborn dirt, wash with a
damp sponge and an ordinary detergent.
We recommend the use of
cleaning products distributed by
the manufacturer.
4.5 Removing the internal glass
panels
For easier cleaning the door internal glass
panels can be disassembled.
Multifunction oven doors
1. Remove the internal glass panel by
pulling the top part gently, following the
movement indicated by the arrows (1).
Cleaning and maintenance
2. Then, pull the bottom part upwards (2). In
this way, the 4 pins attached to the glass
detach from their housings in the oven
door.
3. Take hold of the intermediate glass panel
and unscrew the screw to remove the
lower plate that blocks it.
Improper use
Danger of cuts and glass crack
• Pay attention to the intermediate glass
panel that could accidentally come out
of its seat during this phase.
25
