3100 Insert ACC
3

Dimensions and Clearances

A. Appliance Dimensions
31"
[787]
Figure 8.2 Front View will Small Steel Surround (SP-31IACC-
STD and TRIMKIT-4331)
20-1/2"
[521]
Figure 8.3 Side View with Steel Surround
8
Figure 8.1 Top View with Steel Surround
43" [1092]
11"
[279]
15-1/8" [384]
8-1/2" [216]
22-1/2"
[572]
21-1/2"
[546]
6"
[152]
4-1/4" [108]
NOTE: Flue Collar size is 6 inch (152mm) diameter (ID)
28-5/8" [727]
23-7/8" [606]
34"
[864]
Figure 8.4 Front View with Large Steel Surround (SP-31IACC-
LRG and TRIMKIT-5134)
Figure 8.5 Side View with Steel Surround and Optional Offset
Adapter (OFFSET-ADAPT)
7044-225I
14-1/4"
[362]
12-1/2"
[318]
51" [1295]
12" [305]
25-3/4"
[654]
August 13, 2018
24-1/4"
[616]
