- Page 1 Installation Manual DVR4X4 4-port DVI-D Matrix Switch with RS-232, IR, USB and TCP/IP Control (optional) Display Content From Any 4 Computers On Any 4 Screens Independently Up To 30 Feet Away www.smartavi.com...
-
Page 2: What's In The Box
What’s in the Box? PART NO. QTY DESCRIPTION SmartAVI’s non-blocking DVR4X4 digital video matrix switch DVR4X4S DVI-D 4X4 Router. Includes: [DVR4X4 & PS5VD4A] provides an easy and dynamic approach to switching the DVI output User Manual from up to 4 computers, to up to 4 displays. The switching can be... -
Page 3: Installation
Installation COMPUTERS DVI-D DISPLAYS 30 ft. over DVI-D 30 ft. over DVI-D 30 ft. over DVI-D Remote Control over RS-232, IR, USB or TCP/IP (Optional) DVR4X4 Applications Connecting the DVR4X4 FLEXIBLE CONTROL OPTIONS (see page 8) • Wall Displays 1. Power off the computers and displays. • Digital Signage 2. - Page 4 Flexible Control Options DDC Learning DDC provides plug-and-play capability to your displays. When you plug a display into your computer, the DDC table in the display tells the computer the optimal resolution to use. In Switching Between Ports order to preserve this plug-and-play capability, we have integrated DDC learning into all of There are four ways to switch between inputs on the DVR4X4: via the front panel buttons, RS- our DVI Solutions.
-
Page 5: Tcp/Ip Control (Optional)
Flexible Control Options Software Installation & Operation (Continued) Find the Installation CD that came with your DVR4X4 unit. This CD has the SmartControl software that you will need in There are 3 other ways to control your DVR4X4: order to control the unit using a computer. Insert the CD into your CD-ROM. - Page 6 Software Installation & Operation The Main Routing Window enables you to control the router(s) connections by means of the matrix panel, (Continued) the button panel, or with pre-recorded routes called macros. Matrix Panel: This is probably the simplest way to route the connections. Simply click on the cross point itself.
- Page 7 Software Installation & Operation RS-232 Specifications (Continued) How to properly create an RS-232 connection between a PC and most SmartAVI RS-232 compliant devices Smartcontrol Pro is based on RS232 queries with CRC protocol, any software that can send hex or ascii code can control the SuperMatrix. Each box is called a frame and have a special number sending Audio/Video from any source to any remote.
- Page 8 The information contained in this document is subject to change without notice. • The router will send back one byte for each output and the string Smart-AVI makes no warranty of any kind with regard to this material, including but not ends with a <CR>. The first byte sent is Output #1. In the example limited to, implied warranties of merchantability and fitness for any particular purpose.
- Page 9 SmartAVI, Inc. / Twitter: smartavi 11651 Vanowen St. North Hollywood, CA 91605 Tel: (818) 503-6200 Fax: (818) 503-6208 http://www.SmartAVI.com www.smartavi.com...
