Summary of Contents for German pool SH-09
-
Page 3: Table Of Contents
CONTENTS Operation and maintenance .............1 ■ Notices for operation ..............3 ■ Notices for use ..........5 ■ Names and functions of each part ..........6 ■ Operation of Remote Controller ■ ............11 Emergency operation ■ ..............12 Clean and care ■ ..............14 Troubleshooting Installation service... -
Page 4: Operation And Maintenance Notices For Operation
Operation and maintenance-notices for operation ★ ★ ★ Select the most appropriate temper- Be sure to pull out the power plug Earth: The ground be when not using the air conditioner connected! ature. for a long time. Keep room cool- er than outside about 5 degree. - Page 5 Notices for operation ★ The airflow direction can be adjusted appro- ★ If the supply cord is damaged, it must be replaced priately. At operating, adjust the vertical airflow by the manufacturer or its service agent or a direction by adjusting the louvers of upward/do- similarly qualified person in order to avoid a wnward direction.
-
Page 6: Notices For Use
Notices for use Working principle and special functions for cooling Principle: Air conditioner absorbs heat in the room and transmit to outdoor and discharged, so that indoor ambient temperature decreased, its cooling capacity will increase or decrease by outdoor ambient temperature. Anti-freezing function: If the unit is running in COOL mode and in low temperature, there will be frost formed on the heat exchanger, when indoor heat exchanger temperature decreased below 0... -
Page 7: Working Temperature Range
Notices for use Working temperature range Indoor sideDB/WB( Outdoor sideDB/WB( Maximum cooling 32/23 43/26 Maximum heating 27/--- 24/18 The operating temperature range (outdoor temperature) for cooling only unit is 18℃~ 43℃； for heat pump unit is -7℃~ 43℃. -
Page 8: Names And Functions Of Each Part
Names and functions of each part Indoor unit Air in ⑴ ⑶ ⑺ ⑹ ⑷ Air out ⑸ The pattern in displayer： ⑵ ：Cool Blow ：Dry Wireless Power cable ⑴ remote control ：Fan ：Heat Remote control ⑵ ： Front panel ⑶... -
Page 9: Operation Of Remote Controller
Operation of Remote Controller Remote Controller Description ON/OFF Press it to start or stop operation MODE Press it to select operation mode (AUTO/COOL/DRY/FAN/HEAT) : Press it to increase temperature setting : Press it to decrease temperature setting Press it to set fan speed Press it to set swing angle TIMER ON Press it to set auto-on timer... - Page 10 Operation of Remote Controller 17 18 19 LOCK icon: MODE icon: If MODE button is pressed, is displayed by pressing "+" current operation mode icon and “-” buttons simultaneously.Press (AUTO), ( COOL), them again to clear the display. (DRY), (FAN) or (HEAT SET TIME display: is only for heat pump models)
- Page 11 Operation of Remote Controller Remote Controller Description ON/OFF : Press this button to turn on the unit. Press this button again to turn off the unit. MODE : Each time you press this button,a mode is selected in a sequence that goes from AUTO, , as the following: COOL,DRY, FAN, and HEAT HEAT...
- Page 12 Operation of Remote Controller TIMER ON: Press this button to initiate the auto-ON timer. To cancel the auto-timer program, simply press this button again. After pressing this button, disappears and "ON "blinks . 00:00 is displayed for ON time setting. Within 5 seconds, press + or - button to adjust the time value. Every press of either button changes the time setting by 1 minute.
- Page 13 Operation of Remote Controller LIGHT: Press LIGHT button to turn on the display's light and press this button again to turn off the display's light. If the light is turned on , is displayed. If the light is tunrned off, disappears.
-
Page 14: Emergency Operation
Emergency operation Displayer indicator light control of indoor unit It's a special selective button for the users ,who are not accustomed to the light at sleeping. Get the displayer indicator light on: When setting the light function,the mark will ● display on the remote controller screen by pressing this button. -
Page 15: Clean And Care
Clean and care Caution Turn power off and pull out the power plug before cleaning air conditioner, or it may cause electric ● ● shock. Never sprinkle water on the indoor unit and the outdoor unit for cleaning because it can cause an ●... - Page 16 Clean and care Check before use ① Be sure that nothing obstructs the air outlet and intake vents. ② Check that whether ground wire is properly connected or not. ③ Check that whether the batteries of air conditioner are changed or not. ④...
-
Page 17: Troubleshooting
Troubleshooting CAUTION Don't attempt to repair the air conditioner by yourself, it can cause an electric shock or fire. Please check the following items before asking for repair, it can save your time and money. Phenomenon Troubleshooting Not operate immediately when the air Once the air conditioner is stopped, it will ●... - Page 18 Troubleshooting Phenomenon Troubleshooting Has the power been shut down? ● The unit can not run. Is power plug loosed? ● Is the circuit protection device tripped off or not? ● Is voltage higher or lower? ● (Tested by professionals) Breaking off Is the TIMER correctly used? ●...
- Page 19 Troubleshooting Phenomenon Troubleshooting Indoor unit cannot deliver air. In HEAT mode, when the temperature of indoor ● heat exchanger is very low, that will stop deliver air in order to prevent cool air. (Within 2min) In HEAT mode, when the outdoor temperature ●...
-
Page 20: Notices For Installation
After pull out the power plug then make the appliance operation again， to avoid the icing of outdoor unit damage axial flow fan， should electrify the appliance but not operation for 4 hours for warm-up purpose(only for SH-09 model Basic Requirements For Installation Position Install in the following place may cause malfunction. - Page 21 Notices for installation Outdoor Unit Installation Position Selection Select a location from which noise and outflow air emitted by unit will not inconvenience neighbors, animals, plants. Select a location where there should be sufficient ventilation. Select a location where there should be no obstructions cover the inlet and outlet vent. The location should be able to withstand the full weight and vibration of the outdoor unit and permit safe installation.
- Page 22 Notices for installation Earthing requirements 1. Air conditioner is type I electric appliance, thus please do conduct reliable earthing measure. 2. The yellow-green two-color wire in air conditioner is earthing wire and cannot be used for other propose. It cannot be cut off and be fix it by screw, otherwise it would cause electric shock.
-
Page 23: Installation Dimension Diagram
Installation dimension diagram Installation dimension diagram Space to the ceiling 15cm Above Space to the wall 15cm 15cm Above Above Space to the wall 300cm Above Above Air outlet side Space to the floor The dimensions of the space necessary for correct ●... -
Page 24: Install Indoor Unit
Install indoor unit Install the rear panel 1.Always mount the rear panel horizontally. Due to the water tray of indoor unit has been adopted the both-way drainage design, the outlet of water tray should be adjusted slightly down when installing, that is taking the outlet of the water tray as the center of a circle, the included angle between the evaporator and level should be 0 or more, that is good for condensing water drainage. -
Page 25: Install The Indoor Unit
Install indoor unit NOTE: When connecting the electric wire if the wire length is not enough, please contact with the authorized service shop to buy a exclusive electric wire that is long enough and the joint on the wire are not allowed. The electric wiring must be correctly connected, wrong connection may cause spare parts ●... -
Page 26: Install Outdoor Unit
Install outdoor unit Electric wiring Disassemble the handle on the outdoor unit right side plate. Handle Take off cord anchorage. Connect and fix power connect 14 Cool only type 05、 、 09 12、 、 05、07 、09 、12 some mode Heat pump type: cord (for heat pump type,connect and fix power N(1) 2 connect cord and signal control wire)to terminal block. -
Page 27: Check After Installation And Test Operation
Check after installation and test operation Check after installation Items to be checked Possible malfunction Has it been fixed firmly? The unit may drop, shake or emit noise. It may cause insufficient cooling(heating) Have you done the refrigerant leakage test? capacity It may cause condensation and dripping. -
Page 28: Installation And Maintenance Of Healthy Filter
Installation and Maintenance of Healthy Filter Installation Instructions 1. Forcibly pull the panel for a specific angle from the two ends of the front panel according to the arrow direction. Then pull the air filter downwards to remove it. (See Fig.a) Fig. -
Page 29: Configuration Of Connection Pipe And Additional Volume Of Refrigerant
Configuration of connection pipe and additional volume of refrigerant 1. Standard length of connection pipe 5m、7.5m、8m 2. Min length of connection pipe For the unit with standard connection pipe of 5m, there is no limitation for the min length of connection pipe. For the unit with standard connection pipe of 7.5m and 8m, the min length of connection pipe is 3m. - Page 30 Configuration of connection pipe and additional volume of refrigerant Sheet 2. Additional refrigerant charging amount for R22 R407C R410A and R134a Diameter of connection pipe mm Indoor unit throttle Outdoor unit throttle Liquid pipe Gas pipe Cooling only, Cooling only Cooling and cooling and heating (g / m)
- Page 32 電話 Tel: +86 757 2980 8308 傳真 Fax: +86 757 2980 8318 © 版權所有。未獲德國寶授權，不得翻印、複製或使用本說明書作任何商業用途，違者必究。 © All rights reserved. Copying, reproducing or using the contents of this manual is not allowed without prior authorization from German Pool, violators will be prosecuted. ACS-SH-SERIES-M-13(3)
